CMsoft Viewer for TiaPortal — Viewer and Web Generator

🌐 www.cmsoft.com.pl — all CMsoft extensions, the shop and contact

Graphical viewer for Siemens TIA Portal PLC exports — renders LAD/FBD networks, SCL/STL sources, GRAPH sequential function charts, data blocks, PLC data types, tag tables and watch tables as readable HTML directly inside VS Code or as standalone HTML files. It also generates a web preview of a whole PLC program for reviewing the software in a web browser and analysing online data.

Designed to cooperate with the CMsoft Import for TiaPortal extension, which produces the export folder structure this viewer understands (Program blocks, PLC data types, PLC tags, Watch and force tables, Technology objects, Units) — but any TIA Portal XML/SD export dropped into your workspace works.

💡 Tip: Install the companion CMsoft Import for TiaPortal extension to connect VS Code directly to TIA Portal: export blocks, tag tables and UDTs straight into your workspace (TiaExport/...), then view them here with one right-click — no manual exporting, no intermediate tools. The two extensions are built to work together.

Key Features

Built-in LAD / FBD / SCL / GRAPH viewer

Syntax highlighting in the text editor

The extension ships TextMate grammars (the same mechanism the C/C++ and C# extensions use), so opening a TIA Portal export as text — right-click → Open source file, or Open With... → Text Editor — gives you full syntax highlighting:

Code folding — SCL and s7dcl sources get gutter fold markers (+/…) for whole blocks: IF/FOR/WHILE/REPEAT/CASE, REGION and NETWORK. The matcher is case-insensitive and ignores keywords inside comments and string literals.

Choosing which files are highlighted — the associations above are defaults; override them with the standard VS Code files.associations setting, e.g.:

"files.associations": {
    "*.db": "plain text",   // disable highlighting for .db
    "*.udt": "tia-s7db",    // highlight UDT sources like data blocks
    "*.awlsrc": "tia-scl"   // map your own extension to the SCL grammar
}

Customizing the colors — every token carries a documented TextMate scope (keyword.control.tia.scl, storage.type.tia.scl, comment.line.double-slash.tia.scl, support.constant.attribute.tia.scl, …); restyle any of them via editor.tokenColorCustomizations:

"editor.tokenColorCustomizations": {
    "textMateRules": [
        { "scope": "keyword.control.tia.scl", "settings": { "foreground": "#569CD6", "fontStyle": "bold" } },
        { "scope": "storage.type.tia.scl", "settings": { "foreground": "#4EC9B0" } }
    ]
}

HTML Previews (standalone files)

WinCC dynamic widgets from S7-GRAPH (SVGHMI) — experimental

Experimental. The SVGHMI export is an experimental feature and does not have its full functionality yet — what it does and does not do is described under Generating WinCC SVGHMI widgets from GRAPH sequences below.

FREE and PRO

CMsoft Viewer for TiaPortal is free to use; a CMsoft Viewer for TiaPortal PRO license unlocks the generated previews, unlimited online monitoring and the AI tools:

When the FREE minute of a PLC connection is used up, the preview goes offline — press Go online again to continue.

Activating PRO: run CMsoft Viewer for TiaPortal: Manage License / Subscription (or click CMsoft in the status bar — one item lists the licenses and the manuals of all installed CMsoft extensions). The license panel offers a free 14-day trial, Buy online (one month or one year per license - a license covers one computer - as a subscription that renews automatically — current prices on the purchase page), ordering by e-mail, or activating a license key you already have. An order names the buyer's company and country. Refresh license status fetches this computer's license from the license server — e.g. after a purchase whose panel was closed before the payment was confirmed. With an active license the panel shows Your license, with Extend license for a license that does not renew on its own and Cancel subscription for a renewing subscription (it ends with the paid period). The license is bound to the computer (a hashed hardware ID); deactivating it only removes it from this computer - to move it to another computer, contact the vendor. See TERMS.md and PRIVACY.md.

Requirements

Nothing else needs to be installed — no Node.js, npm or build tools: the extension comes ready to run, and VS Code provides its runtime.

No TIA Portal required. The viewer reads export files from disk only. Use the CMsoft Import for TiaPortal extension (or TIA Portal's built-in export) to produce the files.

Installation

1. Install the extension from VS Code Marketplace (or code --install-extension MariuszCzyrnek.tia-viewer)
2. Recommended: install the companion CMsoft Import for TiaPortal extension (code --install-extension MariuszCzyrnek.tia-import) to export PLC programs directly from TIA Portal into your workspace
3. Open a workspace containing TIA Portal exports (e.g. a TiaExport/Projects/... tree created by CMsoft Import for TiaPortal)
4. Double-click a block file in the Explorer — by default it opens in the text editor; set tiaViewer.editor.openOnClick to preview to open the graphical viewer on click instead (or right-click a file / a PLC folder and pick a preview command)

Usage

Previewing a block (interactive webview)

Double-click (or single-click preview) a SimaticML XML block, a .s7dcl source document (the matching .s7res is picked up automatically), or a .scl / .db / .udt source in the VS Code Explorer to open it. What a click opens is controlled by the tiaViewer.editor.openOnClick setting: source (the default) opens the block source in the regular text editor, preview opens the graphical viewer. Alternatively, right-click the file and choose Graphical preview LAD/FBD. XML files that are not TIA Portal exports always open in the regular text editor, and for any supported file the other option stays available via right-click → Open source file / Graphical preview LAD/FBD (or Open With...).

The viewer renders the block interface (resizable, collapsible columns), LAD rungs, FBD networks, syntax-highlighted SCL/STL and GRAPH sequence flowcharts — all following the active VS Code theme. Networks and the interface panel are collapsible (including Expand all / Collapse all), operand labels and call-box pins show comments as tooltips, and the toolbar zooms the page with − / % / + (25–400 %). In a GRAPH flowchart, clicking a transition opens a popup with its LAD/FBD logic network, clicking a step opens its action table, and hovering a step or a transition shows its comment.

Right-click inside the preview for Open block (on a call box) and Go to Source Line (on networks and parts, GRAPH steps/transitions and interface variables).

Generating a standalone HTML preview file (PRO)

1. Right-click one or more block sources (.xml / .s7dcl / .db / .scl / .udt).
2. Choose Generate HTML preview file.
3. The preview is written as <source-file>.preview.html next to the source; the notification offers an Open File button.

Generating a whole-PLC web preview (PRO)

1. In VS Code Explorer, right-click the PLC folder (the one containing Program blocks / PLC data types / PLC tags / Watch and force tables / Technology objects / Units).
2. Choose Generate Web Preview and pick the output folder in the dialog. The progress notification can be cancelled — the navigator is then built from the pages generated so far.
3. Open the generated index.html in a browser (the notification offers an Open Preview button).

Every block source under Program blocks, PLC data types and Technology objects — at the PLC root and inside every Units/<unit> folder — is rendered into a mirror folder tree of standalone previews (with clickable cross-block navigation links), every tag table under PLC tags gets a table page sorted by PLC address, and every watch table under Watch and force tables a table page with a Monitor value column. The index.html navigator provides a collapsible sidebar tree mirroring the TIA folder structure, a block filter, expand/collapse all, a split view for comparing two blocks side by side and a dark/light theme toggle. A logo sits in its top-left corner, above the PLC name — the CMsoft logo, or your own PNG image set in tiaViewer.webPreview.logoFile (a missing file or one that is not a PNG is reported, and the CMsoft logo is shown instead). The viewer CSS/JS is written once to _assets/ and shared by all pages, so the output stays compact even for large PLCs.

PLC Online (live values)

The navigator sidebar contains a collapsible PLC Online panel that connects the preview directly to a SIMATIC S7 CPU (S7-1500 / S7-1200 G2) through its built-in web server (JSON-RPC API — see .github/SimaticWebApi.md):

1. Expand PLC Online, enter the CPU address, a user and password (a user with read access configured in TIA User Management; the page keeps the password in memory only — the login fields are a regular form, so your browser's password manager may offer to save it).
2. Pick the read interval (ms) and the update mode — Every interval rewrites all values each cycle, Only on change updates the table only when a value actually changes.
3. Press Test connection to verify HTTPS reachability and the credentials without going online (the status line reports the result and the CPU operating mode, or a missing-permissions hint).
4. Press Go online. The status line shows the connection state and the CPU operating mode (run/stop). Press Go offline to disconnect and log out.

While online, opening a watch table from the tree shows a Monitor value column with live values of the watched tags, refreshed at the configured interval.

The same live monitoring works on data block pages (global DBs and instance DBs, including technology object instance DBs): the interface table gains a Monitor value column right after the variable name. Only variables with the Accessible from HMI/OPC UA attribute (ExternalAccessible) are monitored — the flag is inherited down the member tree, so expanding a struct, UDT or multi-instance FB reveals live values for its elements. Arrays of elementary types are monitored per element ("DB"."arr"[0]; arrays over 256 elements, arrays of Struct/UDT and whole structs cannot be read through the web API — use a watch table for those). The attribute flags shown in the expanded rows are filled in from the UDT/FB type export when the DB export omits them.

FB pages monitor the data of a picked instance instead: an Instance selector in the toolbar lists the block's instance DBs and multi-instance paths, the interface table gains the same Monitor value column (paths relative to the picked instance) and network operand labels get live values next to them. On GRAPH function blocks the flowchart itself goes online too: every active step is highlighted green (the step's X flag — in simultaneous branches several steps are active at once), and a transition popup shows the transition's criteria bits — the CRIT value (hex + decimal) plus a TRUE (green) / FALSE (blue) state under every condition operand, decoded from the single polled CRIT value (bit N = N-th condition operand; the operand variables themselves are not read). The same online view is available in the VS Code graphical preview panel (PLC Online panel on the right side of the preview — it closes automatically when you click outside it). There the connection runs through the extension over TLS 1.2 and needs no browser exception: the first connection to a CPU shows the fingerprint of its certificate and asks you to trust it (a certificate Windows trusts — e.g. one issued by the TIA Portal project CA whose root you installed — is accepted without asking), and a CPU that later presents a different certificate is refused with a warning until you trust the new one. CMsoft Viewer for TiaPortal: Manage Trusted PLC Certificates forgets trusted certificates. Several preview panels on the same PLC share one web API session, and the password is kept in the VS Code secret storage, separately for every PLC address and user — a remembered password is never offered to another PLC.

While online, clicking the monitor value of a variable with the Writable from HMI/OPC UA attribute (ExternalWritable) — in the interface table or next to a network operand — opens a write popup (value input, or TOGGLE for Bool) that writes the value through PlcProgram.Write. GRAPH sequencer FBs with the standard INIT_SQ / OFF_SQ / ACK_EF inputs additionally get a floating Sequence control panel (Initialize, Deactivate all, Acknowledge, mode selection, Next, manual step selection) that writes through the variables wired to the pins of the sequence call.

Prerequisites on the PLC/TIA side: the web server must be enabled on the CPU, CORS must be allowed in the web server settings, and — because S7 CPUs use a self-signed certificate by default — open https://<cpu-address>/ in the browser once and accept the certificate exception before going online.

Online trend chart

While online, right-click any monitored variable row on a data block or FB page (or a live network operand label on an FB page) and choose Add to chart to open a live trend in the split view (uPlot-based, up to 10 series, BOOL charted as 0/1). The menu also lets you assign the series to an existing Y axis or create a New Y axis for it (up to 5 axes; extras stack on the right with their own scale, and disappear when their last series is removed). The chart records a timestamped sample on every poll and keeps a ring buffer trimmed to the Max recording time from the Trend panel in the navigator sidebar (default 10 min — retention only; the panel also has an Open chart button); in the VS Code preview the same setting sits under a settings gear on the chart toolbar and is remembered across sessions. The visible time window auto-scrolls with the live edge and is set independently on the chart toolbar (default 30 s, clamped to the retention); pan back with ◀ ▶ to freeze it (recording continues) and press Follow to re-attach. Drag-select a range on the chart to zoom into it (the window field shows the dragged span); double-click returns to live follow. Hover the chart for cursor values in the legend; click a legend label to hide/show a series (ctrl-click isolates it). The toolbar also offers pause (redraws only), clear, CSV export and saving/loading the chart configuration as JSON (in VS Code through its save / open dialog). Going offline stops the recording and keeps the samples — the chart shows the pause as a gap, CSV export still works, Clear removes them.

Copilot tools (PLC online, PRO)

While a preview panel is online, GitHub Copilot (agent mode / chat participants) can access the PLC through the extension's language model tools — they reuse the panel's online session and never ask for credentials:

The Accessible/Writable attributes are verified against the exported block sources in the workspace (found anywhere — Program blocks, Units/<unit>, Technology objects or loose PLC folders) by the same code that marks the interface table, so the tools follow exactly its inheritance rules. Whole structures and arrays are refused with a reason — read or write their members and elements one by one. This enables agentic workflows such as PID tuning: Copilot records the controller's setpoint / process value / output into the trend, reads the step response, writes adjusted parameters and repeats — you only go online once and confirm the writes. Writes are confirmed per call unless you enable tiaViewer.lmTools.autoConfirmPlcWrites (use only in safe setups — writing to a running PLC affects the controlled process).

MCP server (PLC online for external agents, PRO)

The extension also runs a localhost-only MCP server (Streamable HTTP, http://127.0.0.1:<port>/mcp) that exposes the same four tia_viewer_* tools to any MCP client — Claude Desktop, coding agents, your own scripts. With a PRO license it starts with the extension (disable via tiaViewer.mcp.enabled); clients read the connection info from the state file .tia/mcp-viewer.json. VS Code's own Copilot uses the language model tools above, so the server is not offered to VS Code as an MCP server (it would list every tool twice):

{ "version": 1, "host": "127.0.0.1", "port": 58470, "token": "…", "endpoint": "/mcp", "transport": "streamable-http" }

The file is always written to the extension's global storage, and to the workspace as well once the workspace is used for TIA work (unless tiaViewer.mcp.writeWorkspaceStateFile is disabled); the workspace copy is listed in .tia/.gitignore, so the token does not end up in the project's repository. The port and the per-start Bearer token change on every activation, so clients must read the file each session; GET /health (no auth) returns the tool list. The server answers only requests addressed to the loopback interface — a Host or browser Origin naming another host is refused (DNS rebinding protection). PLC writes requested by an MCP client are confirmed by you with a modal VS Code dialog unless tiaViewer.lmTools.autoConfirmPlcWrites is enabled. Command Palette: CMsoft Viewer for TiaPortal: Start MCP Server re-enables the server when it was disabled.

Generating WinCC SVGHMI widgets from GRAPH sequences (PRO, experimental)

Experimental — not the full functionality yet. The export writes the sequence chart, the step and transition views and the Sequence control station, but:

• a dynamic SVG cannot connect itself to tags: on WinCC Unified, CMsoft Import for TiaPortal (4.3 or newer, PRO) places the widget and binds its parameters from <widget>.bindings.json (Bind SVGHMI Widget to WinCC Unified); for WinCC V8 the file is the checklist for binding by hand;
• the views and the station use the event model of the WinCC Unified controls, which Siemens does not document for custom widgets: they are meant for the WinCC Unified PC Runtime; for WinCC V8 and the Unified Comfort Panels use the display-only chart;
• the widgets were checked against the Siemens SVGHMI rules and in the SVGHMI preview of this extension, and placed and bound in TIA Portal V21 with CMsoft Import for TiaPortal — not run in every WinCC runtime.

Test every widget in your target runtime before you use it on a plant.

1. Right-click an S7-GRAPH block export (SimaticML .xml) — or a folder, which is searched recursively for GRAPH blocks — and choose Generate WinCC SVGHMI (GRAPH). While the graphical preview shows a GRAPH block, the same command sits as a button in the editor title bar.
2. One widget file is written per sequence: GRAPH_<block>.svghmi (GRAPH_<block>_Seq<n>.svghmi for blocks with several sequences), next to the export — or into the folder set in tiaViewer.svghmi.outputFolder. Point that setting at the project's UserFiles\SVGControls folder to write the widgets straight where WinCC picks them up.
3. WinCC Unified with CMsoft Import for TiaPortal: right-click the widget → Bind SVGHMI Widget to WinCC Unified — it copies the widget into UserFiles\SVGControls, places it on a screen (in a screen window, at its own size), creates the HMI tags on the connection to the PLC and binds every parameter; step 4 is then done. By hand — WinCC Unified (TIA Portal): copy the files into <TIA project folder>\UserFiles\SVGControls (create the folder if needed), open a screen and refresh the Dynamic widgets of the toolbox — the widget appears under its name (GRAPH_<block>). WinCC V8: copy the file into the GraCS folder of the project, insert it in the Graphics Designer as an SVG object and dynamize its properties in the object properties; its file name and widget name must be unique among the project's dynamic widgets.
4. Place the widget on a screen and bind its parameters to the members of the GRAPH FB's instance DB (unbound parameters keep their default, so binding only _X already shows the active steps). The export writes <widget>.bindings.json next to the GRAPH export: for every instance of the FB found among the exported blocks (instance DBs and multi-instances) the exact tag of each parameter — e.g. Step1_X → "SEQ_IDB".Step1.X, INIT_SQ → the variable wired to the INIT_SQ pin of the FB call. The CMsoft Viewer for TiaPortal log shows the same table.

The notification after the export offers Open Preview — see the next section — and Open Bindings.

Step and transition views, sequence control. A tap on a step opens its view next to it — S<n> - <name>: <action title> with the Interlock -(c)- network (live TRUE/FALSE per operand from CRIT_LOC), the Supervision -(v)- network, the action table and, with the station, Enable step / Disable step (S_SEL := n + S_ON/S_OFF, manual mode only); a tap on a transition opens its condition network with the live CRIT bits. A tap on the same element or × closes the view; the open element is outlined. The Sequence control button of the header strip (FBs with the standard INIT_SQ / OFF_SQ / ACK_EF inputs) opens the station of the web preview: Initialize, Deactivate all, Acknowledge, the mode radios (Automatic / Semiautomatic with Ignore transition / Manual), Next (step with transition) and the manual step selection (− S + or a tap on a step, Enable / Disable); the mode-bound buttons are dimmed and inactive outside their mode, like in the web preview. The header also shows the active mode and a red ERR_FLT badge.

The widget only shows and writes its parameters — WinCC connects them to tags when the widget is placed on a screen; a dynamic SVG cannot bind itself. For WinCC Unified, CMsoft Import for TiaPortal does that through TIA Portal Openness (Bind SVGHMI Widget to WinCC Unified: the screen item and its tag dynamizations in the project); otherwise <widget>.bindings.json is the checklist. The views and the station use hmi:action / hmi-event with two-way parameters — the event model of the WinCC Unified controls, which Siemens does not document for custom widgets: they run in the WinCC Unified PC Runtime; for WinCC V8 or Unified Comfort Panels turn tiaViewer.svghmi.detailViews and tiaViewer.svghmi.sequenceControl off to get the display-only chart. Bind the commands to the variables wired at the FB call when there are any: the call overwrites the instance DB inputs every cycle.

GRAPH names the instance DB members after the steps and transitions, so Step1_X belongs to "SEQ_IDB".Step1.X. Names that are not plain identifiers are sanitized (Branch A → Branch_A_X); the header comment of the file and the CMsoft Viewer for TiaPortal log list every parameter with the member it belongs to. tiaViewer.svghmi.stepFaultStates / tiaViewer.svghmi.transitionStates drop the _LA/_VA resp. _TT parameters for a shorter parameter list; _CRIT_LOC / _CRIT exist only for networks with operands (S7-1500 GRAPH has no supervision criteria, so the supervision network shows no live bits). The widget scales with its size on the screen (keep the aspect ratio); very long sequences are best placed in a scrollable screen window.

Previewing SVGHMI widgets

Double-click a .svghmi file in the Explorer (or right-click → Open SVGHMI Preview) — any dynamic SVG widget, generated by CMsoft Viewer for TiaPortal or taken from a widget library:

• The widget is drawn the way the WinCC runtime draws it: every hmi-bind expression ({{Converter.RGBA(ParamProps.Color)}}, {{ParamProps.On ? 'inline' : 'none'}}, translate({{…}}), local tags, dynamic hmi:text) is evaluated with the parameter values of the panel on the right — Boolean parameters as checkboxes, numbers as fields, HmiColor parameters as color pickers. Values differing from the default are highlighted; Reset restores the defaults.
• Click a shape to list only its parameters; double-click toggles its first Boolean parameter — on a generated GRAPH widget, double-clicking a step switches the step active.
• The widget's own actions (hmi:action with hmi-event:tapped / down / up / mouseLeave) run like in WinCC Unified: on a generated GRAPH widget a tap opens the step/transition views and the station buttons pulse their commands. Values the widget writes to two-way parameters (marked ⇄) update the panel and are listed under Widget writes; enum parameters get a drop-down.
• Zoom with the toolbar buttons or Ctrl+wheel, Fit fits the widget into the window; the background imitates a light or dark WinCC screen, a transparency grid or the editor theme. A widget with a Boolean DarkTheme parameter — the generated GRAPH widgets — follows the background: the dark screen (or the editor theme of a dark VS Code theme) sets it, the light screen clears it.
• Findings check the file against the Siemens SVGHMI rules: missing DOCTYPE or <hmi:self>, a name without extended., preserveAspectRatio other than none, CSS styles, scripts, animations, foreignObject, parameters or local tags used but not declared, events pointing at missing actions, actions writing parameters that are not two-way, and every expression that fails to evaluate. What WinCC would not render (CSS, scripts, external references) is not rendered by the preview either.
• Open source file in the editor title shows the XML; edits re-render the preview live, keeping the parameter values.

Supported input formats

Expected folder layout

The viewer works on any single file, but unlocks its full power (UDT expansion, tag tooltips, Open block navigation) when the exports follow the structure produced by CMsoft Import for TiaPortal:

<PLC folder>/
├── Program blocks/           # OB / FB / FC / DB exports
├── PLC data types/           # UDT exports
├── PLC tags/                 # tag tables (.xlsx / .xml)
├── Watch and force tables/   # watch / force tables (.xml)
├── Technology objects/       # technology object instance DBs (PID, motion, …)
└── Units/<unit>/             # software units — each with its own Program blocks / PLC data types / …

Sibling folders are located by walking up to 6 parent directories from the viewed file.

Commands

Settings

How it works

The viewer reads the export files from disk and draws them with its own .NET Framework 4.8 library, which runs inside VS Code — it needs neither TIA Portal nor any other Siemens software. PLC Online and the online values of the web preview come from the web server of the PLC, over HTTPS (the user manual describes how to prepare the PLC).

Documentation

• User manual — in VS Code: CMsoft Viewer for TiaPortal: Open User Manual (or the CMsoft status bar item → Manuals); installation, the PLC preparation, every function with screenshots, a worked example, troubleshooting
• THIRD_PARTY_NOTICES.md — third-party components and redistribution notes
• LICENSE.md / TERMS.md / PRIVACY.md / SECURITY.md — license agreement, terms of sale, privacy policy, security policy
• CHANGELOG.md — release history

Third-Party Licensing & Redistribution

• This extension is proprietary commercial software licensed under the End User License Agreement. Versions 1.1.104 and earlier were released under the MIT License and remain MIT-licensed; version 2.0.0 and later are not.
• Redistribution of the extension package by anyone other than the Visual Studio Marketplace and the Open VSX Registry is not permitted.
• Third-party notices for the packaged npm components (electron-edge-js, edge-js, edge-cs) are listed in THIRD_PARTY_NOTICES.md; those components keep their own (open-source) licenses.
• This package contains no Siemens components — it neither uses nor redistributes Siemens.Engineering.* assemblies, and no TIA Portal installation or license is required to view export files.

Known Issues & Limitations

• Windows only — the .NET viewer assembly is loaded through edge-js (net48, win32/x64 native binaries)
• Know-how protected blocks — protected blocks cannot be exported by TIA Portal, so there is nothing to view
• First connection to a PLC — S7 CPUs use a self-signed certificate by default, so on the first connection only you can tell that it is the right PLC: compare the fingerprint the dialog shows with the CPU certificate in TIA Portal before trusting it. With a certificate of the TIA Portal project CA on the CPU and that CA's root installed in Windows, no dialog appears. Every CPU with the web API speaks TLS 1.2; older TLS versions are not offered.
• SVGHMI export is experimental — it does not have its full functionality yet: the widgets do not connect themselves to tags (on WinCC Unified, CMsoft Import for TiaPortal binds them from <widget>.bindings.json; elsewhere the file is the checklist), and the step/transition views and the Sequence control station use the event model of the WinCC Unified controls, which Siemens does not document for custom widgets. Test the generated widgets in your target runtime before using them on a plant; turn tiaViewer.svghmi.detailViews / tiaViewer.svghmi.sequenceControl off for a display-only chart.
