I-RLU — Interactive Report Layout Utility

A VS Code replacement for IBM i's STRRLU (Report Layout Utility): design printer file (*PRTF) DDS visually, in a live page-grid preview, while the fixed-column DDS source stays the single source of truth.

See docs/REQUIREMENTS.md for the full requirements and architecture write-up this project is being built against, and docs/ROADMAP.md for what's implemented vs. still open.

Status

Parser, writer, layout engine, and webview designer are all in place and tested (see Features below for what's covered). Packaged as a .vsix (Batch K); see the roadmap for what's still open.

Features

• Live, bidirectional page-grid designer for *PRTF DDS source — a webview renders each record format as a real page grid (derived from PAGSIZE/CPI/LPI), stays in sync as the source changes, and writes every edit straight back through the real parser/writer as a normal VS Code WorkspaceEdit (undo/redo works normally; the DDS source stays the single source of truth).
• Click-to-place and drag-to-reposition for fields and constants, plus a properties panel for name, length, data type, decimals, usage, and line/position.
• Copy/duplicate a field or constant — keywords included, not just position/type — with a suggested non-colliding name for fields. Same-record only for now; picks a position via the same click-to-place flow as adding new.
• Record format management — switch, add, rename, delete, and reorder record formats from the designer itself.
• Indicator-based conditioning — toggle indicators to preview conditioned fields/constants showing or hiding, with INDTXT descriptions surfaced in the toggle panel.
• Keyword editing via properties panels (not just raw text) across:
  • General field/record keywords: EDTCDE, EDTWRD, DATE, DATFMT, DATSEP, TIME, TIMFMT, TIMSEP, DFT, MSGCON, COLOR, HIGHLIGHT, UNDERLINE, PAGNBR, PRTQLTY, DRAWER, PAGRTT.
  • Font/sizing: FONT (FGID), CDEFNT, FNTCHRSET, FONTNAME, CHRSIZ, CHRID, CCSID — including program-to-system-field (&NAME) indirection via a shared toggle component.
  • BARCODE — every documented parameter (symbology, height, bar format, HRI position, asterisk, modifier, narrow bar width, ratio, 2D params), real rendered bars (not a placeholder) for 13 linear symbologies, and live mutual-exclusion validation hints.
  • Print/finishing device keywords: DUPLEX, FORCE, OUTBIN, ZFOLD, STAPLE, INVMMAP.
  • Field-level data/edit keywords: ALIAS, BLKFOLD, CVTDTA, DLTEDT, FLTFIXDEC, FLTPCN, TRNSPY, TXTRTT.
  • AFP page-group/resource keywords: OVERLAY, PAGSEG, AFPRSC, STRPAGGRP/ENDPAGGRP, DOCIDXTAG, DTASTMCMD — rendered as labeled placeholders (see Known limitations) with full keyword editing.
  • REF/REFFLD — "Reference a field" / "Use referenced values" toggle pair, a "Browse fields…" picker over Code for i (record-format/field list), and one-click "Resolve Referenced Field" to pull real length/type/decimals from the referenced file.
• LINE/BOX geometry (AFPDS-only, record-level) rendered to scale from physical units via CPI/LPI and a configurable unit-of-measure setting.
• Live validation hints, non-blocking, for documented DDS restrictions (e.g. BARCODE mutual exclusion, ZFOLD/STAPLE PSF-only, file-level SKIPA/SKIPB on *AFPDS) — CRTPRTF remains the real enforcement point.
• CRTPRTF compile command via the Code for IBM i extension, with a library/source-file/member picker (prompted once per file and cached — i-rlu.setCompileTarget to change it; a file opened directly from a Code for i member: URI needs no prompt, its exact target is read from the URI).
• Packaged as a .vsix — installable like any other VS Code extension.

Project layout

Column layout this is built against

The parser/writer implement IBM's documented DDS positional-entry columns for printer files (verified against IBM's DDS reference, not guessed):

1-5    Sequence number
6      Form type
7      Comment ('*' = whole line is a comment)
8-16   Conditioning indicators (three 3-character slots)
17     Type of name/specification ('R' = record format, blank = field/constant)
18     Reserved
19-28  Name
29     Reference ('R')
30-34  Length
35     Data type
36-37  Decimal positions
38     Usage
39-41  Location: line number
42-44  Location: position (column) number
45-80  Keyword area (continues onto following lines via '+'/'-' in column 80)

Settings

AFPDS font metrics

FONT's parameter is a Font Global Identifier (FGID) — a different DDS mechanism from CDEFNT ("coded font"), FNTCHRSET (host font character-set + code page), or FONTNAME (TrueType/OpenType by name). src/afpFontMetrics.js resolves FONT/FGID against a table verified against IBM's own FGID/typeface documentation (Printer Device Programming, the AFP Font Collection reference, and IBM support pages), covering the common Courier/Gothic (fixed-pitch) and Helvetica/Times New Roman (proportional) families, plus point-size-to-CPI conversion for scalable monospace fonts. One correction worth calling out: an early reference this project drew on mislabeled FGID 416 as "Times Roman" — it's actually Courier Roman Medium; real Times New Roman Medium is FGID 2308. There's a regression test (FGID 416 correctly resolves to Courier Roman Medium...) guarding against that mistake resurfacing.

What's still an approximation vs. what's now real: FONTNAME (TrueType/ OpenType by name) resolves completely — its value already IS the real font family name, no lookup needed. CDEFNT (coded font) and FNTCHRSET (host font character set + code page) resolve their documented X0/XZ/C0/CZ raster-vs-outline naming prefix plus a small number of IBM-verified example names (e.g. X0GT10 = Gothic Text 10 pitch), but a specific coded font's real typeface is, by IBM's own documented design, per-system data with no universal decode table — resolving it fully would need a live connection to query WRKFNTRSC on that exact system, which isn't implemented; anything not recognized gets an honest note saying so, not a guess. Proportional-font (Helvetica/Times New Roman) character widths use the real published Adobe Font Metrics (AFM) values for the metric-compatible PostScript substitute fonts (Helvetica, Times-Roman/Bold/Italic/BoldItalic) — stable, industry-standard data used in every PDF library and PostScript RIP since 1985, a genuine improvement over an earlier flat placeholder table. The one remaining honest caveat: these are the substitute font's published metrics, applied as the best available proxy for IBM's own FGID-named fonts — not a verified byte-for-byte extraction of IBM's own FGID resource data (which this tool has no access to), so don't treat this as guaranteed pixel-identical to what a specific target printer actually renders. See docs/TASKS.md Batch L for the full sourcing behind every resolution rule above.

Building and testing

npm install
npm test        # compiles, builds the webview template, runs the test suite
npm run compile # compile + build webview template without running tests

Known limitations (v1)

Each bullet below is tracked as a batch (or explicitly marked permanent) in docs/TASKS.md's "Known limitations → task mapping" section — see there for dependencies and status; don't let this list and that mapping drift apart. Anything already resolved (keyword editing coverage, BARCODE symbol rendering, packaging, etc.) has been moved to Features above rather than kept here.

• LINE/BOX/BARCODE parameters given as a program-to-system field (&NAME) can't be resolved to a real position/value without a live compile/run — shown at a default position, flagged in the preview. Permanent by design, not a task.
• AFP font metrics remain an approximation for the proportional families (Helvetica/Times New Roman): real, published Adobe AFM data for the metric-compatible substitute fonts, not a verified byte-for-byte extraction of IBM's own FGID resource data. CDEFNT, FNTCHRSET, and FONTNAME (host/IFS font references) aren't resolved at all — see "AFPDS font metrics" above. (Batch L, mostly done)
• Real pixel content for page segments (PAGSEG), overlays (OVERLAY), and other AFP resources isn't rendered — these show as labeled placeholder boxes (resource name + keyword), since the actual scanned-logo/form content lives in external IFS/host AFP objects this tool has no access to. (Batch O, blocked — needs external resource file access; see docs/REQUIREMENTS.md §8)
• REF/REFFLD live resolution over Code for i (both the single-field "Resolve Referenced Field" and the "Browse fields…" picker) is written and unit-tested wherever the logic is pure, but the actual DSPFFD/SQL network round-trip has not been exercised against a real connected IBM i. (Batch H, part 2)
• CRTPRTF can't compile directly from an IFS stream file — verified against IBM's own CRTPRTF parameter reference, there's no SRCSTMF-equivalent parameter (unlike CRTBNDRPG/CRTBNDCL, which have one). Opening one and compiling shows a clear error rather than guessing a library/source-file target for it. Permanent by design, a real IBM i command limitation, not a gap in I-RLU.
• Numeric edit-code/edit-word formatting is approximate-width only, with no live-system verification against a real CRTPRTF compile. Explicit non-goal, not a task — see Batch A's detail in docs/TASKS.md.

License

Not yet chosen — add one before any public release.
