FPGA Pin Planner - VS Code Extension

Advanced FPGA Pin Assignment and Management Tool with Voltage/IO Standard Selection for VS Code.

Features

• 📥 CSV Import: Import pin data from CSV files with intelligent parsing
• 📤 Multi-Format Export: Export constraints in XDC (Xilinx), SDC (Synopsys), and QSF (Intel Quartus) formats
• ⚡ Voltage & I/O Standards: Comprehensive voltage level and I/O standard management
• 🔍 Pin Validation: Real-time constraint validation and error detection
• 📊 Interactive Interface: User-friendly webview interface with resizable panels
• 🎯 Context Integration: Right-click context menus for CSV and constraint files
• 📊 Bank Analysis: Dynamic bank statistics and differential pair management
• 🚀 Optimized Performance: Streamlined codebase with enhanced performance and stability

Quick Start

1. Install the extension from the VS Code Marketplace
2. Open the Command Palette (Ctrl+Shift+P)
3. Search for "FPGA" to see all available commands
4. Use FPGA: Open Pin Planner to start the main interface

Development Build

Prerequisites

• Node.js (v16 or later)
• npm
• TypeScript
• vsce (VS Code Extension Manager)

Clean Build Process

For developers who want to build the extension from source:

# Option 1: Use the automated PowerShell script
.\clean-build.ps1

# Option 2: Use the batch file
.\clean-build.cmd

# Option 3: Manual step-by-step build
cd .. && npm run build && cd vscode-extension
npm install
npm run package

Important: Always build the main application first (npm run build in root directory) before building the extension to ensure the latest webview content is included.

Installation

After building, install the generated .vsix file:

code --install-extension fpga-pin-planner-1.0.9.vsix --force

Commands

• FPGA: Open FPGA Pin Planner - Open the main pin planner interface with WebView
• FPGA: Load Sample Data - Load sample pin data for testing and demonstration

New in v1.0.9

✨ I/O Configuration GUI (Issue #34)

• Dual-Dropdown Layout: Intuitive voltage and I/O standard selection
• Real-Time Validation: Automatic compatibility checking between voltage and I/O standards
• Collapsible Advanced Settings: Expandable panel for detailed pin configuration
• Enhanced Visual Feedback: Improved placeholder text and visual indicators

📊 Extended I/O Standards Support (38 Total)

• High-Speed Standards: LVDS_18, LVDS_25, LVDS_33, LVDS_E_25, LVPECL_25, LVPECL_33
• DDR Memory Standards: DDR3_1_35V, DDR3_1_5V, DDR4_1_2V, DDR5_1_1V, MOBILE_DDR_1_8V
• Display Standards: TMDS_33
• Bus Standards: PCI33_3, PCI66_3, PCIX_3
• Plus 7 additional specialized standards

🔧 Advanced List Mode

• Column Header Sorting: Click any column header to sort with visual indicators (▲▼↕)
• Enhanced Bulk Editing: Comprehensive bulk assignment for Direction, Voltage, and I/O Standard
• Advanced BANK Filtering: Interactive toggle buttons with Show All/Hide All functionality
• Improved Workflow: Clear Selection button and better state management

Supported File Formats

Import

• CSV: Pin number, signal name, direction, voltage, I/O standard, package, bank, comments

Export

• XDC: Xilinx Design Constraints for Vivado
• SDC: Synopsys Design Constraints for various tools
• QSF: Quartus Settings File for Intel Quartus Prime

CSV Format

The extension supports flexible CSV formats with the following columns:

Pin Number, Signal Name, Direction, Voltage, IO Standard, Package, Bank, Comments
A1, clk_100mhz, input, 3.3V, LVCMOS33, BGA484, 15, Main clock input
B2, reset_n, input, 3.3V, LVCMOS33, BGA484, 15, Active-low reset
C3, led[0], output, 3.3V, LVCMOS33, BGA484, 16, Status LED

Configuration

Access extension settings via File > Preferences > Settings and search for "FPGA Pin Planner":

• Default Voltage: Set default voltage level for new pins
• Default I/O Standard: Set default I/O standard
• Auto Save: Enable automatic saving of changes
• Validation Level: Set validation strictness (strict/moderate/relaxed)
• Export Format: Set default export format

Requirements

• VS Code 1.74.0 or later
• No additional dependencies required

Release Notes

1.0.9 (Latest)

• ✨ I/O Configuration GUI: Complete I/O management interface with dual-dropdown layout
• 📊 Extended I/O Standards: Support for 38 I/O standards including LVDS, DDR, TMDS, PCI
• 🔧 Advanced List Mode: Column header sorting with visual indicators
• 🛠️ Enhanced Bulk Editing: Comprehensive bulk assignment for Direction, Voltage, I/O Standard
• 🔍 Advanced BANK Filtering: Interactive toggle buttons with Show All/Hide All
• 🐛 Bug Fixes: Fixed Apply Comment button, POWER/GROUND validation exclusion
• ⚡ Performance: Optimized state management and virtual list rendering

1.0.8

• 🔧 Core Foundation: Enhanced I/O configuration foundation and List mode improvements

Contributing

This extension is part of the larger FPGA Pin Planner project. Contributions are welcome!

License

MIT License - see LICENSE file for details.

Support

For issues, feature requests, or questions:

• Create an issue on the GitHub repository
• Check the documentation for detailed usage instructions

Enjoy managing your FPGA pins with VS Code! 🚀
