MatrixSpy

A powerful VS Code extension for exploring, visualizing, and exporting MATLAB .mat files with image mat data support and beautiful matrix visualization.

Features

• ✅ Support all MAT file versions (v4, v5, v6, v7, v7.3)
• ✅ Interactive visualization with Plotly.js
• ✅ Tree view for variable navigation
• ✅ Multiple data types support:
  • Scalars, vectors, matrices, tensors
  • Complex numbers
  • Structs and cell arrays
  • Sparse matrices
• ✅ Image mat data-specific features:
  • k-space visualization
  • FFT transform
  • Magnitude/Phase display
  • Multi-slice viewer
• ✅ Performance optimized:
  • Lazy loading for large files
  • WebGL acceleration
  • Downsampling for big datasets
• ✅ Export capabilities:
  • CSV export
  • JSON export
  • NumPy format

Installation

Prerequisites

1. Python 3.8+ with the following packages:

   pip install scipy numpy h5py mat73


2. Node.js 16+ and npm

Build from Source

1. Clone the repository:

   git clone https://github.com/MaiwulanjiangMaiming/MatrixSpy.git
   cd MatrixSpy


2. Install Python dependencies:

   cd python
   pip install -r requirements.txt


3. Install Extension dependencies:

   cd ../extension
   npm install


4. Install Webview dependencies:

   cd ../webview
   npm install


5. Build the webview:

   npm run build


6. Compile the extension:

   cd ../extension
   npm run compile


7. Package the extension:

   npm run package


8. Install in VSCode:
   • Open VSCode
   • Go to Extensions (Cmd+Shift+X)
   • Click "..." menu → "Install from VSIX"
   • Select the generated .vsix file

Usage

Opening MAT Files

1. Method 1: Right-click on a .mat file in Explorer → "Open MAT File"
2. Method 2: Command Palette (Cmd+Shift+P) → "MatrixSpy: Open MAT File"
3. Method 3: Double-click on a .mat file

Navigation

• Tree View: Browse variables in the sidebar
• Click on a variable to view its data
• Expand structs to see nested fields

Visualization

• 1D arrays: Line plot
• 2D matrices: Heatmap or table view
• 3D tensors: Slice viewer with navigation
• Complex numbers: Magnitude/Phase display

Image Mat Data Features

For image mat data with k-space:

1. View k-space magnitude and phase
2. Apply FFT to convert to image space
3. Navigate through slices
4. Generate mosaic view

Export Data

• Right-click on a variable → "Export to CSV" or "Export to JSON"
• Use Command Palette → "MatrixSpy: Export..."

Configuration

Configure in VSCode settings:

{
  "matrixspy.pythonPath": "python3",
  "matrixspy.maxDataSize": 10000,
  "matrixspy.enableImage": true
}

Test Files

Generate test files:

cd test-files/generators
python generate_test_mats.py
python generate_mri_data.py

This creates:

• test-files/v5/ - v5 format files
• test-files/v7/ - v7 format files
• test-files/v7.3/ - v7.3 HDF5 format files
• MRI test data

Architecture

MatrixSpy/
├── extension/          # VSCode Extension (TypeScript)
│   ├── src/
│   │   ├── extension.ts
│   │   ├── providers/  # Custom Editor, Tree View
│   │   ├── ipc/        # Python Bridge
│   │   └── commands/   # User commands
│   └── webview-dist/   # Compiled webview
│
├── python/             # Python Backend
│   ├── mat_parser.py   # Main parser
│   ├── parsers/        # v4-v7.3 parsers
│   ├── serializers/    # JSON serialization
│   └── utils/          # Lazy loader, MRI tools
│
├── webview/            # React Webview UI
│   ├── src/
│   │   ├── components/ # UI components
│   │   ├── hooks/      # React hooks
│   │   └── types/      # TypeScript types
│   └── dist/           # Compiled bundle
│
└── test-files/         # Test MAT files
    ├── v5/
    ├── v7/
    └── v7.3/

Supported Data Types

Large files slow

• Files >1GB use lazy loading
• Adjust matrixspy.maxDataSize for threshold

Contributing

Contributions welcome! Please read our contributing guidelines.

License

MIT License

Versioning

This project follows semantic versioning:

• z (patch): Bug fixes
• y (minor): New features
• x (major): Major version updates (breaking changes)

Changelog

v1.0.1 (2026-04-05)

• Fixed configuration namespace from 'matViewer' to 'matrixspy'
• Updated terminology from 'MRI data' to 'image mat data'
• Translated all Chinese comments to English
• Improved extension description for better user onboarding
• Added README.md to extension directory for proper marketplace display

v1.0.0 (2026-04-05)

• Initial release
• Support for all MAT file versions (v4, v5, v6, v7, v7.3)
• Interactive visualization with Plotly.js
• Tree view for variable navigation
• Multiple data types support: scalars, vectors, matrices, tensors, complex numbers, structs, cell arrays, sparse matrices
• Image mat data-specific features: k-space visualization, FFT transform, magnitude/phase display, multi-slice viewer
• Performance optimization: lazy loading, WebGL acceleration, downsampling
• Export capabilities: CSV, JSON, NumPy format

Contact

If you want to add new features or report bugs, please contact: Maiwulanjiang Maiming

Credits

• Python parsing: scipy.io, mat73, h5py
• Visualization: Plotly.js
• UI: React, TypeScript

Enjoy viewing your MAT files! 🎉
