📊 STDF Record Viewer - VS Code Extension

A powerful and modern VS Code extension for viewing and analyzing STDF (Standard Test Data Format) files with zero external dependencies. Features a pure TypeScript/Node.js parser with complete STDF V4 support - no Python required!

🎯 v1.0.2: Complete STDF V4 Implementation

✅ All 26 Record Types - 100% STDF V4 specification coverage
✅ 120+ Fields - Every field from the STDF V4 spec
✅ Header Fields Visible - REC_LEN, REC_TYP, REC_SUB, REC_NAME
✅ Pure TypeScript/Node.js - No Python, no system dependencies
✅ Streaming Parser - Handle GB-size files efficiently
✅ Multi-Column DTR - Intelligent parsing with axis support
✅ Vendor Extensions - PRR.WAFER_ID, DTR axis fields
✅ Gzip Support - Built-in .stdf.gz decompression

📚 Documentation

🚀 Quick Start Guide - Get started in 5 minutes
🏗️ Architecture Guide - Deep dive into the system
📖 Parser README - Complete parser documentation
✅ Implementation Summary - What's been built

🆕 What's New in v1.0.2

🎉 Complete STDF V4 Implementation

All 26 Record Types - Complete coverage of STDF V4 specification
- FAR, ATR, VUR, MIR, MRR, PCR, HBR, SBR, PMR, PGR, PLR, RDR, SDR
- WIR, WRR, WCR, PIR, PRR, TSR, PTR, MPR, FTR, BPS, EPS, GDR, DTR
120+ Fields - Every field defined in the STDF V4 spec
Header Fields - REC_LEN, REC_TYP, REC_SUB, REC_NAME now visible in UI
Smart Column Ordering - Header fields always appear first

🔧 Enhanced DTR Parser

Multi-Column Support - Parse delimited data (tab, pipe, comma, space, semicolon)
Intelligent Axis Parsing - Automatic extraction of value/unit pairs
Vendor Extensions - dtr_id, axis_1_value, axis_1_unit, axis_2_value, axis_2_unit, axis_3_value, axis_3_unit
Pattern Recognition - Detects formats like "123.45 mV" automatically

📊 PRR Enhancements

Vendor Extensions - Added WAFER_ID and WAFER_NUMBER fields
Complete Field Set - All standard + vendor-specific fields visible

🎨 UI Improvements

Column Ordering - Header fields (REC_LEN, REC_TYP, REC_SUB, REC_NAME) always first
Zero Value Support - Correctly handles fields with value 0
Complete Data Display - All fields from all record types visible

🏗️ Architecture

Pure TypeScript/Node.js - No Python, no external dependencies
Streaming Parser - Memory-efficient for GB-size files
Built-in Gzip - Native .stdf.gz support via zlib
Array Bounds Checking - Prevents buffer overruns
Type Safety - Full TypeScript implementation

🔍 Enhanced SQL Engine

SELECT specific columns - No longer returns all data
GROUP BY support - Group and aggregate data
Aggregate functions - COUNT, SUM, AVG, MIN, MAX
Multiple column ORDER BY - Sort by multiple fields
Better error messages - Clear validation feedback

✨ Features

🚀 Core Features

🎯 View STDF Records - View records from .stdf and .stdf.gz files
🗜️ Gzip Support - Automatically decompresses .stdf.gz files
📑 24 Record Types Supported - FAR, ATR, MIR, MRR, PCR, HBR, SBR, PMR, PGR, PLR, RDR, SDR, WRR, WCR, PIR, PRR, TSR, PTR, MPR, FTR, BPS, EPS, GDR, DTR, WIR
📄 View Complete File - Stream all record types in one view with organized sections
🎨 Modern UI - Beautiful gradient design with dark theme
⚡ Fast Loading - Efficient streaming for large files
⏹️ Stop Button - Cancel long-running operations anytime

🔍 Advanced Features

📊 Interactive Table - Resizable columns with text wrapping
🔎 Enhanced SQL Query Support - Full-featured SQL engine with:
- SELECT specific columns
- GROUP BY clause with aggregates
- COUNT, SUM, AVG, MIN, MAX functions
- Multiple column ORDER BY
- WHERE, LIKE, IS NULL, operators
📄 Pagination - Navigate through large datasets (100 records per page)
💾 CSV Export - Export filtered/grouped results with timestamp
⌨️ Query History - Undo/Redo with Ctrl+Z / Ctrl+Y
🎯 Smart Filtering - Case-insensitive search with pattern matching

💻 SQL Query Examples

-- Get all records
SELECT * FROM data

-- Select specific columns
SELECT REC_TYP, REC_LEN FROM data WHERE TEXT_DAT = 'Test'

-- Group by with aggregates
SELECT REC_TYP, COUNT(*) FROM data GROUP BY REC_TYP

-- Advanced grouping
SELECT REC_TYP, REC_LEN FROM data
WHERE TEXT_DAT = 'TCCT Input Decision Variables'
GROUP BY REC_TYP, REC_LEN

-- Pattern matching
SELECT * FROM data WHERE TEXT_DAT LIKE '%Status%'

-- Aggregate functions
SELECT AVG(REC_LEN), MIN(REC_LEN), MAX(REC_LEN) FROM data

-- Complex query with sorting and limit
SELECT REC_TYP, COUNT(*), AVG(REC_LEN)
FROM data
WHERE REC_LEN > 10
GROUP BY REC_TYP
ORDER BY COUNT(*) DESC
LIMIT 5

📦 Installation

Prerequisites

No external dependencies required! 🎉

This extension uses a pure TypeScript/Node.js parser that runs entirely within VS Code.

Install Extension

You can install this extension via:

VS Code Marketplace (search for "STDF Viewer")
Or install the .vsix file locally

🎯 Usage

Method 1: Right-Click

Right-click any .stdf or .stdf.gz file
Select "Open With..."
Choose "STDF Record Viewer"

Method 2: Command Palette

Press F1 or Ctrl+Shift+P
Type "Open STDF Record Viewer (Select File)"
Browse and select your STDF file

🎨 Interface Overview

1. Header Section

File name display with 🗜️ Decompressed badge for .gz files
Gradient purple theme

2. Control Panel

Record Type Dropdown - Choose from 24 record types or "View Complete File"
Load Records Button - Fetches selected record type
Stop Loading Button - Cancel long-running operations (appears during loading)
Export CSV Button - Exports current filtered data

3. SQL Query Panel

Query Input - Multi-line SQL editor
Execute SQL Button - Run query on loaded data
Clear & Show All Button - Reset filters
Query History - Ctrl+Z to undo, Ctrl+Y to redo

4. Data Table

Resizable Columns - Drag column edges to resize
Text Wrapping - Long text automatically wraps
Sticky Header - Header stays visible while scrolling
Row Hover Effect - Highlights row on hover

5. Pagination

Navigate large datasets
Shows: First, Previous, Page Numbers, Next, Last
Displays current page info (e.g., "Showing 1 to 100 of 500 records")

🔧 Keyboard Shortcuts

Shortcut	Action
`Ctrl+Z`	Undo last SQL query
`Ctrl+Y`	Redo SQL query
`Ctrl+Shift+P`	Open command palette

📊 Supported STDF Record Types

Test Data Records

PTR (Parametric Test)
MPR (Multiple Result Parametric)
FTR (Functional Test)
STR (Scan Test)

Datalog Records

MIR (Master Info)
MRR (Master Result)
PCR (Part Count)
HBR (Hardware Bin)
SBR (Software Bin)

Audit Records

FAR (File Attributes)
ATR (Audit Trail)
DTR (Datalog Text)
GDR (Generic Data)

And more: PIR, PRR, TSR, PMR, PGR, PLR, RDR, SDR, WRR, WCR, BPS, EPS

🐛 Troubleshooting

Extension doesn't open for .stdf files

Right-click the .stdf or .stdf.gz file
Select "Open With..."
Choose "STDF Record Viewer"
Check "Configure default editor for '*.stdf'..."

Parsing Error

Check VS Code's Output panel (select "STDF Viewer" from dropdown)
Verify the file is a valid STDF V4 file
Try with a smaller file first to isolate the issue

Gzipped file fails to open

Ensure the .gz file is valid (not corrupted)
Check disk space for temporary decompression
Try opening the original .stdf file if available

No records displayed

Check if the selected record type exists in your STDF file
Try different record types (MIR, DTR, PTR are commonly present)
Use "View Complete File" to see all record types
Check VS Code's Output panel for parsing errors

SQL Query not working

Make sure to use FROM data (lowercase)
Enclose string values in single quotes: 'value'
Use uppercase for column names: TEXT_DAT, REC_LEN
For aggregates with GROUP BY, include columns in SELECT or as aggregates
Check syntax: SELECT columns FROM data WHERE condition GROUP BY columns

Stop button doesn't appear

Stop button only shows when loading "View Complete File"
For single record types, loading is usually fast and stop isn't needed

📝 Technical Details

Architecture

Language: TypeScript (Pure)
Framework: VS Code Extension API
UI: Custom Webview with HTML/CSS/JavaScript
Parser: Pure TypeScript/Node.js STDF V4 Parser (14 record types)
Streaming: Memory-efficient with backpressure support
Compression: Node.js zlib module for gzip support
Data Processing: Optional DuckDB WASM for SQL queries

File Structure

Extension/
├── src/
│   └── extension.ts          # Main extension logic (TypeScript)
├── out/                       # Compiled JavaScript
├── dist/                      # Distribution files
├── media/                     # Extension icons
├── package.json              # Extension manifest
├── language-configuration.json # STDF language config
├── tsconfig.json             # TypeScript config
└── README.md                 # This file

📄 License

This project is licensed under the MIT License - see the LICENSE file for details.

🙏 Acknowledgments

STDF V4 Specification - Industry standard for test data format
VS Code Team - For the powerful extension API
TypeScript Community - For excellent tooling and ecosystem
Community - For feedback and contributions

Made with ❤️ for the semiconductor testing and data community

⭐ Star this repo if you find it useful!
