Logic Language Support

A VS Code extension that provides comprehensive language support for Logic DSL files (.logic), designed for defining soft logic constraints in mammography classification and other medical imaging applications.

Features

🎨 Syntax Highlighting

• Keywords: define, constraint, const, expect, weight, transform, as
• Logical operators: | (OR), & (AND), ~ (NOT), >> (IMPLIES), ^ (XOR)
• Comparison operators: >, <, >=, <=, ==
• Arithmetic operators: +, -, *, /
• Tensor operations: | tensor (OR_n), & tensor (AND_n)
• Indexing syntax: tensor[index], tensor[start:end], tensor[i, j]
• Built-in functions: exactly_one, sum, mutual_exclusion, at_least_k, at_most_k, exactly_k, threshold_implication, conditional_probability, greater_than, less_than, equals, threshold_constraint, clamp, threshold
• Comments, strings, numbers, and identifiers

🔍 IntelliSense & Auto-completion

• Context-aware suggestions for built-in functions
• Keyword completion with snippets
• Transform type suggestions (logbarrier, hinge, linear)
• Function parameter hints

📖 Hover Documentation

• Detailed documentation for built-in functions
• Usage examples and parameter descriptions
• Function signatures and return types

🎯 Code Snippets

• Quick templates for common constraint patterns
• Mammography-specific rule templates
• Variable definition shortcuts
• Complete rule file templates

🔧 Language Features

• Document outline view showing variables and constraints
• Basic syntax validation
• Parentheses matching and auto-closing
• Comment toggling support

⚡ Commands

• Validate Logic File: Check syntax and structure of .logic files

Usage

Creating Logic Files

1. Create a new file with .logic extension
2. Start typing rule definitions using the provided snippets
3. Use IntelliSense for function completion and documentation

Example Logic File

# Mammography Constraint Rules
# ============================

# Declare expected variables from model output
expect mass_L, mass_R, mc_L, mc_R
expect birads_L, birads_R, birads_score_L, birads_score_R
expect comp

# Declare expected variables with aliases using 'as' keyword
expect patient_age as age, patient_weight as weight
expect radiologist_1_assessment as senior_assessment, radiologist_2_assessment as resident_assessment

# Define constants for reusable thresholds
const high_risk_threshold = 0.7
const low_risk_threshold = 0.3
const birads_high_cutoff = 4

# Feature definitions - combine findings per breast
define findings_L = mass_L | mc_L
define findings_R = mass_R | mc_R

# Feature definitions using aliased variables
define high_risk_patient = (age > 50) & (weight > 70)
define assessment_agreement = equals(senior_assessment, resident_assessment)

# Multiple statements on one line using semicolons
expect confidence; const threshold = 0.8; define high_conf = confidence > threshold

# BI-RADS probability groups using constants
define high_birads_L = sum(birads_L, [4, 5, 6])
define high_birads_R = sum(birads_R, [4, 5, 6])

# Threshold-based risk assessments
define high_risk_L = birads_score_L > high_risk_threshold
define high_risk_R = birads_score_R > high_risk_threshold

# Consensus patterns with tensor operations
define radiologist_consensus = & radiologist_assessments
define any_concern = | radiologist_assessments

# Multi-dimensional indexing
define patient_subset = patient_data[:3]
define senior_opinions = assessments[:, :, 0]

# Range constraints using comparison operators
define valid_range_L = (birads_score_L >= 0.0) & (birads_score_L <= 1.0)

# Categorical exclusivity constraints
constraint exactly_one(birads_L) weight=1.0 transform="logbarrier"
constraint exactly_one(birads_R) weight=1.0 transform="logbarrier"

# Multiple constraints on one line
constraint high_risk_L >> findings_L weight=0.8; constraint high_risk_R >> findings_R weight=0.8

# Advanced constraint types
constraint at_least_k(findings_combined, 2) weight=0.6 transform="logbarrier"
constraint conditional_probability(high_birads_L, findings_L, 0.85) weight=0.8
constraint equals(left_assessment, right_assessment) weight=0.4 transform="hinge"

Available Snippets

Type the following prefixes for quick templates:

Basic Constructs:

• define - Variable definition
• const - Constant definition
• expect - Variable expectation declaration
• expect_as - Variable expectation with alias
• expect_multi_as - Multiple variables with aliases
• expect_section_as - Complete expected variables section with aliases
• constraint - Basic constraint
• comment - Comment block

Constraint Types:

• exactly_one - Categorical constraint
• at_least_k - At-least-k constraint
• at_most_k - At-most-k constraint
• exactly_k - Exactly-k constraint
• implies - Implication constraint
• threshold_implication - Threshold-based implication
• conditional_probability - Conditional probability constraint
• mutual_exclusion - Mutual exclusion constraint

Functions & Comparisons:

• sum - Sum function
• greater_than - Soft greater than comparison
• less_than - Soft less than comparison
• equals - Soft equality comparison
• threshold_constraint - Threshold constraint with operators
• clamp - Clamp function
• threshold - Threshold function

Arithmetic Operators:

• + - Addition
• - - Subtraction
• * - Multiplication
• / - Division

Comparison Operators:

• greater - Greater than comparison (>)
• less - Less than comparison (<)
• equal - Equality comparison (==)
• range - Range constraint with min/max

Tensor Operations:

• index - Tensor indexing
• slice - Tensor slicing
• multi_index - Multi-dimensional indexing
• and_tensor - AND across tensor (& tensor)
• or_tensor - OR across tensor (| tensor)
• consensus - Consensus definition
• any_evidence - Any evidence definition

Advanced Domain Templates:

• findings - Findings definition template
• high_birads - High BI-RADS definition
• risk_assessment - Risk assessment with threshold
• constants - Constants section template
• mammo_template - Complete mammography rule template
• advanced_template - Advanced template with tensor operations

Semicolon Patterns:

• multi_statements - Multiple statements on one line using semicolons
• const_multi - Multiple constants and definition using semicolons
• expect_define - Expect variable and define result using semicolon
• quick_setup - Quick setup with constant, expect, define, and constraint

Language Syntax

Statement Separation

Line-based Separation (Traditional):

expect variables
define result = expression
constraint result

Semicolon Separation:

# Multiple statements on one line
expect a, b; define c = a | b; constraint c

# Mix of semicolons and newlines
const threshold = 0.5; expect risk_score
define high_risk = risk_score > threshold
constraint high_risk weight=0.8

# Trailing semicolons are optional and ignored
expect variables;
define result = expression;

String-aware Parsing: The semicolon parser correctly handles semicolons inside strings:

define msg = "Hello; World"; constraint some_condition  # Only the last semicolon separates

Keywords

• define - Define variables and expressions
• const - Define constants for reusable values
• expect - Declare which variables the script expects to be provided
• as - Used with expect to provide aliases for variables (e.g., expect var1 as alias1)
• constraint - Create constraint rules
• weight - Set constraint importance (default: 1.0)
• transform - Choose penalty function (logbarrier, hinge, linear)

Operators

Logical Operators:

• | - Logical OR (binary and n-ary: | tensor)
• & - Logical AND (binary and n-ary: & tensor)
• ~ - Logical NOT
• ^ - Logical XOR
• >> - Logical IMPLIES
• = - Assignment

Arithmetic Operators:

• + - Addition
• - - Subtraction
• * - Multiplication
• / - Division

Comparison Operators:

• > - Greater than
• < - Less than
• >= - Greater than or equal
• <= - Less than or equal
• == - Equal

Indexing Operations:

• tensor[index] - Single element indexing
• tensor[start:end] - Slicing
• tensor[i, j] - Multi-dimensional indexing
• tensor[:2] - Slice from beginning
• tensor[::2] - Step slicing

Built-in Functions

Basic Constraints:

• exactly_one(probabilities) - Exactly-one constraint for categorical data
• sum(probabilities, [indices]) - Sum specific class probabilities
• mutual_exclusion(prob1, prob2, ...) - Mutual exclusion constraint

Counting Constraints:

• at_least_k(probabilities, k) - At least k elements must be true
• at_most_k(probabilities, k) - At most k elements can be true
• exactly_k(probabilities, k) - Exactly k elements must be true

Advanced Constraints:

• threshold_implication(antecedent, consequent, threshold) - Threshold-based implication
• conditional_probability(condition, event, target_prob) - Conditional probability constraint

Comparison Functions:

• greater_than(left, right) - Soft greater than comparison
• less_than(left, right) - Soft less than comparison
• equals(left, right) - Soft equality comparison
• threshold_constraint(tensor, threshold, operator) - Threshold with operator

Utility Functions:

• clamp(tensor, min, max) - Clamp values to range
• threshold(tensor, threshold) - Apply threshold

Data Types

• Numbers: 1.0, 0.5, 2, 0.85
• Strings: "logbarrier", 'hinge', ">", "=="
• Lists: [1, 2, 3], [4, 5, 6]
• Identifiers: mass_L, birads_R, findings_L
• Constants: User-defined reusable values

Requirements

• Visual Studio Code version 1.103.0 or higher
• No additional dependencies required

Extension Commands

This extension contributes the following commands:

• rule-logic-language-support.validateLogicFile: Validate the current .logic file for syntax errors

Access commands via:

• Command Palette (Ctrl+Shift+P): Search for "Validate Logic File"
• Right-click context menu in .logic files

Installation

From VS Code Marketplace

1. Open VS Code
2. Go to Extensions view (Ctrl+Shift+X)
3. Search for "Rule Logic Language Support"
4. Click Install

From VSIX Package

1. Download the .vsix file
2. Open VS Code
3. Run command: Extensions: Install from VSIX...
4. Select the downloaded file

Development

Building the Extension

npm install
npm run compile

Testing

npm test

Packaging

npm install -g vsce
vsce package

Related Projects

This extension is designed to work with the Rule Logic DSL framework for mammography constraint definitions. For more information about the underlying language and framework, see the main project documentation.

Known Issues

• Advanced semantic validation is not yet implemented
• Error recovery could be improved for malformed syntax
• No language server protocol implementation yet

Release Notes

1.4.0

Added variable aliasing support with the as keyword:

• Variable Aliasing: Support for the as keyword in expect statements to provide alternative names for variables
• Alias Syntax: Use expect variable_name as alias_name to create more descriptive or shorter variable names
• Mixed Aliasing: Support for mixing aliased and non-aliased variables in the same expect statement
• Enhanced Syntax Highlighting: The as keyword is properly highlighted in the editor
• Updated Validation: Parser correctly validates expect statements with alias syntax
• Improved IntelliSense: Completion and hover documentation for the as keyword
• New Code Snippets: Added snippets for variable aliasing patterns:
  • expect_as: Single variable with alias
  • expect_multi_as: Multiple variables with mixed aliases
  • expect_section_as: Complete expected variables section with aliases
  • expect_define_as: Expect with alias and define using the alias
• Enhanced Documentation: Updated example files and documentation to demonstrate aliasing

1.3.0

Added comprehensive semicolon statement separation support:

• Semicolon Statement Separation: Support for using semicolons (;) to separate multiple statements on a single line
• Mixed Separation Styles: Combine traditional line-based and semicolon-based statement separation
• Enhanced Syntax Highlighting: Semicolons are properly highlighted as statement separators
• Improved Validation: Parser correctly handles semicolon-separated statements with accurate error reporting
• Updated Document Outline: Individual statements from semicolon-separated lines appear in outline view
• New Code Snippets: Added snippets demonstrating semicolon usage patterns
• String-aware Parsing: Semicolons inside string literals are correctly ignored
• Trailing Semicolon Support: Optional trailing semicolons are supported and ignored

1.2.0

Added support for variable expectations:

• New expect Keyword: Declare which variables (features) the script expects to be provided
• Variable Declaration Syntax: Support for both single (expect variable) and multiple (expect var1, var2, var3) variable declarations
• Enhanced Validation: Recognition and validation of expect statements
• Updated Snippets: New snippets for expect declarations including expect, expect_multi, and expect_section
• Improved IntelliSense: Completion and hover documentation for expect keyword
• Document Outline: Expect statements appear in document outline for better navigation
• Updated Templates: Mammography template now includes proper expect declarations

1.0.0

Major update with comprehensive Rule Language support:

• Enhanced Syntax Highlighting: Added support for const keyword, arithmetic operators (+, -, *, /), comparison operators (>, <, >=, <=, ==), tensor operations (| tensor, & tensor), and indexing syntax
• Expanded Built-in Functions: Added at_least_k, at_most_k, exactly_k, threshold_implication, conditional_probability, greater_than, less_than, equals, threshold_constraint
• Constant Definitions: Support for const statements and reusable constants
• Tensor Operations: AND_n and OR_n operations across tensors, multi-dimensional indexing with numpy/pytorch syntax
• Arithmetic & Comparison Operators: Native support for arithmetic operators (+, -, *, /) and comparison operators (>, <, >=, <=, ==) with proper syntax highlighting
• Advanced Snippets: 40+ new code snippets covering all language features including tensor operations, consensus patterns, and medical domain templates
• Enhanced IntelliSense: Completion for all new functions and operators
• Improved Documentation: Comprehensive hover help for all built-in functions
• Better Validation: Recognition of const statements and expanded syntax validation

0.0.1

Initial release of Rule Logic Language Support:

• Basic syntax highlighting for .logic files
• IntelliSense with function completion
• Code snippets for common patterns
• Hover documentation for built-in functions
• Document outline support
• Basic syntax validation

Contributing

Contributions are welcome! Please feel free to submit issues and enhancement requests.

License

This extension is released under the MIT License.

---

Enjoy using Rule Logic Language Support!
