MTAX — Lua Modding

Write Lua 5.4 mods for MTAX without leaving the editor.

Two layers sit behind everything here.

A Lua 5.4 parser with scope resolution, written for this extension, drives navigation, the outline, rename and semantic highlighting — so clicking a name finds the binding, not other text that happens to match.

An API snapshot knows the 1,059 native functions, the 172 events, the OOP API (26 classes plus 14 static classes), the sandbox and the mtaxmanifest.lua format — all extracted straight from the engine source and the wiki, never typed by hand.

Features
- Language support
- The MTAX API
Commands
lua-language-server
Configuration
Where the data comes from
Developing the extension
License

Features

Language support

Everything a Lua editor is expected to do, answered from the syntax tree:


Go to definition `F12`	A local jumps to its own declaration — the one actually in scope, so `local x = x` resolves the two `x` apart. A global or a table field jumps to wherever the resource assigns it, in any of its files. A native jumps to its signature in the generated definitions.
Find all references `Shift+F12`	Every use across the resource. Works on locals, globals, table fields, natives and event names.
Rename `F2`	Locals within their scope, globals and fields across the resource. Renaming the MTAX API is refused.
Outline / breadcrumbs `Ctrl+Shift+O`	Functions, methods, tables and their fields — including what sits inside a top-level `if ... then`, which is where half of a typical resource lives.
Workspace symbols `Ctrl+T`	Search across every resource in the folder.
Highlight occurrences	Every read and write of the name under the cursor, writes marked apart.
Syntax errors	Reported as you type, with recovery: an unfinished `if` at the bottom of the file does not cost you the outline of everything above it.

Scope stops at the resource. Each MTAX resource runs in its own Lua VM, so a global defined in resource A genuinely does not exist in resource B — and navigation refuses to jump across that line, unlike a general-purpose Lua server that would treat the whole folder as one scope.

Colour

Names are coloured for what they are — native, event, OOP class, local, parameter, property, method, label — rather than all alike. A native called from the wrong side is marked deprecated, so the theme strikes it through before you even read the warning.

Two layers share the work, and they do not overlap. A TextMate injection grammar generated from the API owns the MTAX identity — natives, engine globals, OOP classes and event names get their own support.*.mtax.lua scopes, which every theme already styles and which keep working with semantic highlighting switched off. Semantic tokens own what only scope analysis knows: local, parameter, property, method, label, and which occurrence is the declaration.

The split matters, because a semantic token silently replaces the scope underneath it: claiming self would trade the Lua grammar's variable.language blue for a plain variable colour, and claiming a native would trade its MTAX scope for a generic function. So neither is claimed. The one deliberate override is a native called from the wrong side, emitted as deprecated so the theme strikes it through.

The MTAX API

Completion that knows which side the file runs on

As you type in a script, natives show up with their signature, description and example. The ones that do not exist on that side are still offered — flagged with ⚠ server only and sorted last — instead of being hidden, because knowing the function exists on the other side is usually the missing piece of information.

The side comes from the manifest: a file listed in server_files is server code, full stop. With no manifest, the extension infers it from the folder (server/, client/) and from the file name (main_s.lua, _c.lua), and the status bar reads MTAX server? — the question mark telling you it was a guess. Clicking the status bar pins the side by hand.

Event names where event names belong

Inside the eventName argument of addEventHandler, triggerClientEvent, triggerServerEvent and friends, completion swaps the natives for events — along with the parameters the handler will receive, the source element and whether the event can be cancelled. Events the resource registers itself with addEvent("...") join the list.

Hover and signature help

Hovering shows the signature, parameters with type and default, the return value, the OOP equivalent and a link to the wiki. While you type the arguments, the current parameter is highlighted — and when a native has both a server and a client variant (createVehicle), the variant for the current side is the one already selected.

All of it in English or Portuguese, following the VS Code display language or the mtax.docsLanguage setting.

Problems the server would reject

Problem	Example
Native from the wrong side	`bindKey` (client) called from a server script
Function that does not exist in MTAX	`outputChatBox`, `guiGetText`, `getPlayerMoney` — MTA natives MTAX does not have
Typo	`setElemenPosition` → did you mean `setElementPosition`?
Event from the wrong side	`onClientRender` registered in a server script
Sandbox	`require`, `dofile`, `io.open`, `package`, `debug`, `os.execute`
Syntax error	anything the parser cannot read, at the exact token
Script missing from the manifest	a `.lua` in the folder that no list declares — it will never run

Every rule carries its own severity and can be turned off. The ones worth fixing automatically offer a quick fix (Ctrl+.).

Run over 140,000 lines of real server resources, this rule set flagged 38 wrong-side calls, 90 non-existent functions, 2 typos and 3 sandbox uses — without a single false positive. One-sided calls inside a shared script are off by default, because a shared script tends to branch on localPlayer and call both sides on purpose.

A real `mtaxmanifest.lua`

The manifest is validated with the same rules the server uses (Server/src/modules/resources/manifest.cpp):

relative path, with /, no .., no \, no :;
.lua only in server_files / client_files / shared_files, assets only in files;
declared file that does not exist in the folder;
ui_page that is not a page, or that is not listed in files;
map_files trying to borrow from another resource;
exports that is not a function name;
loadscreen_manual_shutdown without loadscreen;
escrow_files (read by the portal) pointing at a file the build does not protect;
globals the manifest sandbox does not have (print, os, require…).

On top of that: completion for the keys, path completion inside the lists (only .lua in a script list, only assets in files), and Ctrl+click on a path opens the file — including cross-resource borrows such as ":other-resource/file.lua".

Commands

Command	Shortcut	What it does
`MTAX: New Resource…`	—	Creates the folder with a manifest and scripts. Five layouts: server + client, server only, client only, with NUI, loading screen
`MTAX: New Script…`	—	Creates the script and declares it in the right manifest list
`MTAX: Search the API…`	`Ctrl+Alt+M`	Searches the 1,059 natives; inserts the call or opens the documentation
`MTAX: Open documentation…`	`Ctrl+Alt+D`	Opens the wiki page for the symbol under the cursor
`MTAX: Convert meta.xml…`	—	Converts a legacy MTA resource to `mtaxmanifest.lua`
`MTAX: Set up lua-language-server`	—	Points sumneko at the MTAX definitions
`MTAX: Set the side of the current file`	—	Pins client / server / shared when inference gets it wrong
`MTAX: Regenerate the API…`	—	Regenerates everything from the local `MTAX-Purple/` and `wiki/`

On macOS the shortcuts are Cmd+Alt+M and Cmd+Alt+D.

lua-language-server (optional)

The extension ships generated LuaCATS files (definitions/) with the 1,059 natives annotated, the OOP classes with their inheritance, and Vector2/3/4 and Matrix. If sumneko.lua is installed, the extension offers to point it at those definitions — giving you real type inference layered on top of everything described above. It also disables io, package and debug in sumneko's completion, since the MTAX sandbox does not have those libraries.

None of this is required: without sumneko, the extension works on its own.

Configuration

Key	Default	What it controls
`mtax.enable`	`true`	Turns the whole language layer on or off
`mtax.docsLanguage`	`auto`	`auto`, `en` or `pt` in hovers and completion
`mtax.semanticHighlighting`	`true`	Colour names for what they are, not all alike
`mtax.diagnostics.enable`	`true`	Turns problem reporting on
`mtax.diagnostics.syntax`	`error`	Lua syntax errors from the built-in parser
`mtax.diagnostics.wrongSide`	`warning`	Native from one side called from the other
`mtax.diagnostics.sharedSideCalls`	`off`	The same, but inside a `shared` script
`mtax.diagnostics.unknownNative`	`warning`	Function shaped like a native that does not exist in MTAX
`mtax.diagnostics.typos`	`warning`	Name one or two characters away from a real native
`mtax.diagnostics.sandbox`	`error`	`require`, `io`, `package`, `os.execute`…
`mtax.diagnostics.manifest`	`true`	Validation of `mtaxmanifest.lua`
`mtax.diagnostics.deprecatedMeta`	`true`	Points out `meta.xml` files and offers to convert them
`mtax.completion.oop`	`true`	Suggest the OOP API alongside the plain natives
`mtax.completion.snippets`	`true`	Expand a native into a call with its arguments as tab stops
`mtax.luals.autoConfigure`	`ask`	`ask`, `always` or `never` for configuring sumneko
`mtax.statusBar`	`true`	Show the file side in the status bar
`mtax.author`	`""`	Name written to `resource_author` when scaffolding a resource
`mtax.sourceRoot`	`""`	Folder holding `MTAX-Purple/` and `wiki/`, used to regenerate the API

Where the data comes from

data/api.json, definitions/*.lua and syntaxes/*.json are generated, never edited by hand:

Source	What comes out of it
`Shared/src/lua_api/catalog/functions.h`	the 1,059 natives, with side and confidence level
`Shared/src/lua_api/oop/oopclasses.h`	OOP classes, methods, properties, inheritance
`Shared/src/lua_api/sandbox/policy.h`	open libraries, removed globals, restricted `os` fields
`Shared/src/lua_api/prelude/prelude.h`	pure-Lua helpers (`bit`, `utf`, `split`, `inspect`, `ref`…)
`Server/src/modules/resources/manifest.cpp`	the manifest keys and the validation rules
`wiki/src/content/docs/{en,pt}`	descriptions, signatures, parameters, returns, examples and events

Out of those come the API snapshot the extension reads at runtime, the LuaCATS definition files, and the TextMate injection grammars that colour the API.

To regenerate after changing the engine or the wiki:

npm run generate          # searches upwards for MTAX-Purple/ and wiki/
npm run generate -- --root "D:/Projetos MTAX"

Or, from inside VS Code, run MTAX: Regenerate the API from local MTAX sources.

Current coverage: 1,059 / 1,059 signatures and 1,058 / 1,059 descriptions.

Developing the extension

npm install
npm run generate     # data/api.json + definitions/
npm run compile      # bundle into dist/
npm run watch        # rebuild on save
npm test             # 67 tests: parser, scopes, manifest, API, grammar and end-to-end activation
npm run package      # produces the .vsix

F5 in VS Code opens a window with the extension loaded.

The tests run against the real bundle with a stub of the VS Code API, so a hang on activation or a broken provider shows up before packaging. The colouring is checked against the actual TextMate engine layered over VS Code's own Lua grammar, because an injection selector is easy to get subtly wrong and impossible to eyeball.

Project layout

tools/generate-api.mjs     reads engine + wiki, writes data/, definitions/ and syntaxes/
src/lua/lexer.ts           Lua 5.4 tokens, long brackets, escapes, BOM and shebang
src/lua/parser.ts          error-tolerant recursive descent -> syntax tree
src/lua/analyze.ts         scopes, bindings, references, dotted paths, the outline
src/lua/index.ts           per-file and per-resource caches
src/api/model.ts           loads and indexes the API snapshot
src/manifest/              parsing, path rules, globs, side resolution
src/features/              completion, hover, signature help, diagnostics, quick fixes,
                           navigation, semantic tokens, links, status bar, commands,
                           scaffolding, luals

The parser never throws. A file is re-read on every keystroke, so half-typed code is the normal case: what it cannot understand is recorded, the token is skipped, and the walk continues — an unfinished if at the bottom of a file does not cost you the outline of everything above it.

It is checked against the real thing: 618 Lua files from the server's own resources/ folder, 6.6 MB, parse with zero errors — the only three failures are MTXA-protected script containers, which are not Lua at all.
