Debug Data Structures Visualizer

See your data structures while you debug. Stop at a breakpoint and the extension draws your binary trees, linked lists, stacks, queues, heaps, hash tables, n-ary trees and tries, then redraws them at every step. Made for data structures courses, in Python and Java.

✨ Features

• 🔎 Automatic detection: lists the data structures in the current frame (root, bst.root, self.root, this.root, queue...) so you open one with a click, no configuration
• 🌳 Binary trees: BSTs, AVL trees, any node with left/right children
• 🔗 Linked lists: singly and doubly linked, with head / tail and next / previous pointers
• 📚 Stacks and queues: on top of a list, or in an array (circular queues included) with top / front / rear markers
• ⛰️ Heaps: the array and the tree it encodes, side by side
• #️⃣ Hash tables: buckets with their separate chains
• 🌲 N-ary trees and tries: nodes with a list, array or dictionary of children
• 🔄 Live: redrawn every time the debugger stops, whether you step from the panel, the toolbar or a shortcut
• 🎮 Debug controls in the panel: Step Over, Step Into, Step Out, Continue
• 🖱️ Interactive: click any node, box or cell to see its fields; drag tree nodes around
• 🐍☕ Python and Java, tested with the debuggers VS Code uses for both

🚀 Quick Start

1. Set a breakpoint where your data structure exists, and start debugging (F5).
2. When the program stops, open the visualizer:
   • Cmd+K Cmd+V (Mac) or Ctrl+K Ctrl+V (Windows/Linux)
   • the Visualize button in the status bar
   • the graph icon at the top right of the editor, or in the debug toolbar
   • right-click a variable in the Variables view → Visualize Data Structure (opens it directly)
3. Click a structure in the list of structures found in the current frame.
4. Step through your code with Step Over in the panel (or F10) and watch the structure change.

No breakpoint yet? Try the examples: one folder per data structure, in Python and Java.

🧱 Supported Data Structures

Each structure is detected from its field names, the way they are written in courses and textbooks (in any letter case). Values are read from fields such as element, val, value, data, item or key, including entries that hold a key and a value.

Binary trees

Plain trees, BSTs and AVL trees. Textbook trees work too, like this Java BST whose nodes hold an element entry with a key and a value, linked with leftChild / rightChild:

Linked lists

Stacks and queues

Heaps

Hash tables

N-ary trees and tries

An n-ary tree lets each node have any number of children. A trie is an n-ary tree of letters that stores words: words with the same beginning share the same path.

🧪 Try It with the Examples

The examples folder has one folder per data structure, each with a Python program, a Java program and a README listing what you should see at every breakpoint:

Download the repository, open the examples folder in VS Code, set breakpoints on the lines marked BREAKPOINT and press F5 with Python: current file or Java: current file.

🖱️ In the Panel

• Click a node, list box, array cell or hash table entry to see its fields. Click anywhere else to close the details.
• Drag tree nodes to make room; the links follow.
• Step Over / Step Into / Step Out / Continue control the debugger from the panel.
• CurrentSize shows the size field of the structure, when it has one.
• Refresh redraws the structure (Cmd+Shift+R / Ctrl+Shift+R when the panel is focused).
• Back returns to the wizard; Add Another Visualization opens a second panel, for example to watch two structures at once.
• Large structures are scaled down to fit (to 50% at most), then the panel scrolls.

🛠️ Setting the Paths Yourself

If your binary tree uses unusual field names, enter the variable name in the wizard, choose Binary Tree (set each path yourself) and fill in the paths to the tree root, the left and right children, the key, the value and the size. Check shows the value each path points to.

For every other structure, keep Detect automatically in step 2.

⚙️ Settings

⌨️ Keyboard Shortcuts

Change them in Keyboard Shortcuts (Cmd+K Cmd+S / Ctrl+K Ctrl+S) by searching for "Data Structure".

🌐 Languages

🔧 Requirements

• VS Code 1.85 or later, or an editor based on it (Cursor, VSCodium, Windsurf...)
• A debugger for your language: Python Debugger for Python, Extension Pack for Java for Java

🐛 Troubleshooting

"No active debug session": start debugging first (F5), with a breakpoint where your structure exists.

"The program is still running": the debugger has not stopped yet. Set a breakpoint and wait until the line is highlighted.

My structure is not listed: it has to exist in the frame where the program stopped (a local variable, or a field of self / this). Type its name in the wizard, press Search and keep Detect automatically. For a binary tree with unusual field names, set the paths yourself.

The tree is cut: trees deeper than dataStructuresVisualizer.maxDepth (20 by default) are cut at that depth.

Found a bug or have an idea? Open an issue or write to contact@mccprogrammer.com.

🗺️ Roadmap

• Graphs (adjacency lists and matrices)
• Red-black trees with their colours, AVL trees with balance factors
• Export a visualization as PNG or SVG

❤️ Support

If the extension helps you, a rating on the Marketplace or a coffee on Ko-fi makes a big difference.

📬 Contact

Questions, feedback or ideas: contact@mccprogrammer.com.

🤝 Contributing

Contributions are welcome. Open an issue or a pull request on GitHub.

📄 License

MIT

🙏 Acknowledgments

• D3.js for the drawings (bundled with the extension, so it works offline)
• The VS Code Debug Adapter Protocol, which lets the extension read variables from any debugger
