Flr Extension

Flr (Flutter-R) Extension: A Flutter Resource Manager VSCode Extension, which can help flutter developer to auto specify assets in pubspec.yaml and generate r.g.dart file after he changes the flutter project assets. With r.g.dart, flutter developer can apply the asset in code by referencing it's asset ID function.

Feature

Support auto service that automatically specify assets in pubspec.yaml and generate r.g.dart file, which can be triggered manually or by monitoring asset changes
Support R.x (such as R.image.test(), R.svg.test(width: 100, height: 100), R.txt.test_json()) code struct
Support for processing image assets ( .png, .jpg, .jpeg, .gif, .webp, .icon, .bmp, .wbmp, .svg )
Support for processing text assets ( .txt, .json, .yaml, .xml )
Support for processing font assets ( .ttf, .otf, .ttc)
Support for processing image asset variants
Support for processing asset which’s filename is bad:
- filename has illegal character (such as blank, ~, @, # ) which is outside the range of valid characters (0-9, A-Z, a-z, _, +, -, ., ·, !, @, &, $, ￥)
- filename begins with a number or character _ or character$
Support for processing assets with the same filename but different path
Support for processing multi projects (the main project and its sub projects in one workspace)
Support for auto merging old asset specifications when specifying new assets

Installation

search and install Flr in VSCode Extensions Marketplace
install vsix version from Release

Usage

If you open a folder in VSCode and with pubspec.yaml in root,

It'll show the FLR(ASSETS MANGER) session in EXPLORER window

Detail feature of Flr

+: Add flr config to pubspec.yaml

Refresh: regenerate r.g.dart according to config

Start/Stop Monitor: enable/disable resource folder monitor. if enabled, will auto refresh r.g.dart if resources changed.

Recommended Flutter Resource Structure

Flr the following flutter resource structure schemes:

scheme 1:

flutter_project_root_dir
├── build
│   ├── ..
├── lib
│   ├── assets
│   │   ├── images // image resource directory of all modules
│   │   │   ├── #{module} // image resource directory of a module
│   │   │   │   ├── #{main_image_asset}
│   │   │   │   ├── #{variant-dir} // image resource directory of a variant
│   │   │   │   │   ├── #{image_asset_variant}
│   │   │   │
│   │   │   ├── home // image resource directory of home module
│   │   │   │   ├── home_badge.svg
│   │   │   │   ├── home_icon.png
│   │   │   │   ├── 3.0x // image resource directory of a 3.0x-ratio-variant
│   │   │   │   │   ├── home_icon.png
│   │   │   │
│   │   ├── texts // text resource directory
│   │   │   │     // (you can also break it down further by module)
│   │   │   └── test.json
│   │   │   └── test.yaml
│   │   │   │
│   │   ├── fonts // font resource directory of all font-families
│   │   │   ├── #{font-family} // font resource directory of a font-family
│   │   │   │   ├── #{font-family}-#{font_weight_or_style}.ttf
│   │   │   │
│   │   │   ├── Amiri // font resource directory of Amiri font-family
│   │   │   │   ├── Amiri-Regular.ttf
│   │   │   │   ├── Amiri-Bold.ttf
│   │   │   │   ├── Amiri-Italic.ttf
│   │   │   │   ├── Amiri-BoldItalic.ttf
│   ├── ..

scheme 2:

flutter_project_root_dir
├── build
│   ├── ..
├── lib
│   ├── ..
├── assets
│   ├── images // image resource directory of all modules
│   │   ├── #{module} // image resource directory of a module
│   │   │   ├── #{main_image_asset}
│   │   │   ├── #{variant-dir} // image resource directory of a variant
│   │   │   │   ├── #{image_asset_variant}
│   │   │
│   │   ├── home // image resource directory of home module
│   │   │   ├── home_badge.svg
│   │   │   ├── home_icon.png
│   │   │   ├── 3.0x // image resource directory of a 3.0x-ratio-variant
│   │   │   │   ├── home_icon.png
│   │   │
│   ├── texts // text resource directory
│   │   │     // (you can also break it down further by module)
│   │   └── test.json
│   │   └── test.yaml
│   │   │
│   ├── fonts // font resource directory of all font-families
│   │   ├── #{font-family} // font resource directory of a font-family
│   │   │   ├── #{font-family}-#{font_weight_or_style}.ttf
│   │   │
│   │   ├── Amiri // font resource directory of Amiri font-family
│   │   │   ├── Amiri-Regular.ttf
│   │   │   ├── Amiri-Bold.ttf
│   │   │   ├── Amiri-Italic.ttf
│   │   │   ├── Amiri-BoldItalic.ttf
│   ├── ..

Big Attention, the resource structure in the root directory of the font resource MUST follow the structure described above: name the subdirectory with a font family name, and place the font resources of the font family in the subdirectory. Otherwise, Flr may not scan the font resource correctly.

Example

# pubspec.yaml
...
# flutter-resource-structure-scheme-1 example:
flr:
  core_version: 1.0.0
  # config the line length that is used to format r.g.dart
  dartfmt_line_length: 80
  # config the image and text resource directories that need to be scanned
  assets:
    - lib/assets/images
    - lib/assets/texts
  # config the font resource directories that need to be scanned
  fonts:
    - lib/assets/fonts

...

You can get more details from the following examples：

License

The extension is available as open source under the terms of the MIT License.
