Project Structure Generator (项目结构生成器)

中文文档

A VS Code extension that scans project files and generates a structured directory tree in a file. Supports automatic updates when files change!

✨ Features

Two Generation Modes: Project-wide structure or directory-specific structure
Smart File Comments: Preserves and displays comments marked with # after file names
Auto-Update: Optional automatic regeneration when files/folders are created, deleted, or renamed
Clipboard Export: Copy project or directory structure without writing a file
Selection Conversion: Convert selected tree text into HTML, CSV, or Mermaid mindmap files
Multiple Output Formats: Generate Markdown, Mermaid mindmap (.mmd), CSV, or standalone HTML visualization files
Interactive HTML View: HTML output includes search, expand/collapse controls, and summary stats
.gitignore Support: Optionally applies .gitignore rules while scanning
Generation Stats: Shows directory, file, and ignored item counts after generation
Safer Scanning: Excludes the output file itself and sorts directories before files
Flexible Configuration: Customizable ignore patterns, scan depth, and output file names
Multi-language Support: English and Chinese interfaces
Intelligent Filtering: Default ignores common directories like .git, .idea, .vscode, dist, node_modules

🚀 Usage

Available Commands

1. Generate Project Structure

What it does: Scans the entire project from root directory
Where it saves: Always saves to project root directory
Output behavior: Uses projectStructure.outputFileName and the configured output format
When to use: For complete project documentation
Access:
- Command Palette: "Generate Project Structure"
- Right-click on files: "Generate Project Structure"
- Right-click on folders: "Generate Project Structure"

2. Generate Directory Structure

What it does: Scans only the selected directory
Where it saves: Saves to the selected directory
Output behavior: Uses projectStructure.directoryOutputFileName and the configured output format
When to use: For documenting specific modules or subdirectories
Access:
- Right-click on folders: "Generate Directory Structure"

3. Copy Project Structure to Clipboard

What it does: Generates the structure and copies it to the clipboard without writing a file
Scope: Command Palette copies the workspace structure; right-click copies the selected folder or the parent folder of a selected file
Format: Uses the currently configured projectStructure.outputFormat
When to use: For pasting into chats, issues, prompts, or documents
Access:
- Command Palette: "Copy Project Structure to Clipboard"
- Right-click on files/folders: "Copy Project Structure to Clipboard"

4. Convert Selected Structure

What it does: Converts selected tree text into HTML, CSV, or Mermaid mindmap output
Where it saves: Saves next to the current file, or in the workspace root if the current document has no file path
Output name: Uses <root-name>-structure plus the selected format extension
When to use: When you already have a generated structure block in a Markdown file
Access:
- Select the structure text in the editor
- Right-click and choose "Convert Selected Structure To..."

How to Access Commands

Command Palette

Press Ctrl+Shift+P (Windows/Linux) or Cmd+Shift+P (macOS)
Type "Generate Project Structure" and select the command

Note: The Command Palette provides project-wide generation, clipboard export, and configuration commands.

On Files: Shows "Generate Project Structure" and "Copy Project Structure to Clipboard"
On Folders: Shows "Generate Project Structure", "Generate Directory Structure", and "Copy Project Structure to Clipboard"

Key Difference:

Command Palette: Best for project-wide generation and clipboard export
Right-click Folders: Can choose between project structure, directory structure, or clipboard export

⚙️ Configuration Options

Access settings by searching for projectStructure, Project Structure Generator, or 项目结构生成器 in VS Code settings, or use the "Configure Project Structure Generator" command.

Available Settings

Setting	Type	Default	Description
`projectStructure.outputFileName`	string	"PROJECT_STRUCTURE"	Output file name for project structure, without extension
`projectStructure.directoryOutputFileName`	string	"PROJECT_STRUCTURE"	Output file name for directory structure, without extension
`projectStructure.outputFormat`	string	"markdown"	Output format: `markdown`, `mindmap`, `csv`, or `html`
`projectStructure.ignoredPatterns`	array	`[".git", ".idea", ".vscode", "dist", "node_modules"]`	Files/directories to ignore
`projectStructure.maxDepth`	number	0	Maximum directory depth to scan; `0` means unlimited
`projectStructure.autoUpdate`	boolean	false	Auto-update when files change
`projectStructure.useGitignore`	boolean	true	Apply `.gitignore` rules while scanning
`projectStructure.excludeOutputFile`	boolean	true	Exclude the generated output file itself from the structure
`projectStructure.showStats`	boolean	true	Show directory/file/ignored counts after generation

Output Formats

Output file extensions are added automatically based on the selected format: .md, .mmd, .csv, or .html.

markdown: Updates or creates a .md file, replaces the existing structure section when found, and preserves comments in the existing structure block.
mindmap: Creates a Mermaid mindmap .mmd file for visualizing the project structure.
csv: Creates a .csv file with path, name, type, level, parent, and comment columns.
html: Creates a standalone .html tree view with search, expand/collapse controls, and summary stats.

Scanning Behavior

Existing comments after # are parsed from the current Markdown structure and kept during regeneration.
The default scan depth is unlimited. Set projectStructure.maxDepth to a positive number only when you want to limit recursion.
Directory entries are listed before files, then sorted by name.
Ignore patterns support exact file or directory names and simple wildcards such as *.log.
When projectStructure.useGitignore is enabled, .gitignore rules are applied in addition to projectStructure.ignoredPatterns.
When projectStructure.excludeOutputFile is enabled, the generated .md, .mmd, .csv, or .html file is not included in its own structure.

🔄 Auto-Update Feature

When enabled, the extension automatically regenerates the project structure when you:

Create new files or folders
Delete files or folders
Rename files or folders

To enable auto-update:

Open VS Code settings
Search for projectStructure.autoUpdate
Check the box to enable

Note: Auto-update only affects the project structure (saved to root), not directory-specific structures.

🔧 Resetting Settings

If you have previously customized settings and want to use the new defaults:

Open VS Code settings
Search for the setting you want to reset
Click the gear icon next to the setting
Select "Reset Setting"

📁 File Comments

The extension supports comments after file names using the # symbol:

src/
├── components/
│   ├── Button.vue # Reusable button component
│   └── Modal.vue # Modal dialog component
├── utils/
│   └── helpers.js # Utility functions
└── main.js # Application entry point

To add comments, simply include them in existing structure files after the # symbol.

📋 Example Output

my-project #
├── src #
│   ├── components #
│   │   ├── Header.vue # Navigation header component
│   │   ├── Footer.vue # Page footer component
│   │   └── Button.vue # Reusable button component
│   ├── router #
│   │   └── index.js # Vue router configuration
│   ├── store #
│   │   └── index.js # Vuex store setup
│   ├── utils #
│   │   └── api.js # API helper functions
│   ├── App.vue # Main application component
│   └── main.js # Application entry point
├── public #
│   ├── index.html # HTML template
│   └── favicon.ico # Site icon
├── package.json # Project dependencies
└── PROJECT_STRUCTURE.md # Project structure output

📝 Changelog

v1.1.0

✅ Added clipboard export for project and directory structures without writing files
✅ Added configurable output formats: Markdown, Mermaid mindmap, CSV, and HTML
✅ Changed the default project and directory output file name to PROJECT_STRUCTURE
✅ Improved VS Code settings search by adding Project Structure Generator keywords to setting titles and descriptions
✅ Changed the default scan depth to unlimited; projectStructure.maxDepth now limits recursion only when set to a positive number
✅ Added "Convert Selected Structure To..." command for converting selected tree text into HTML, CSV, or Mermaid mindmap files
✅ Added standalone HTML output with search, expand/collapse controls, and summary stats
✅ Conversion output is saved next to the source document as <root-name>-structure.html, .csv, or .mmd
✅ Output file extensions are now determined automatically from the configured format
✅ Added .gitignore integration, output-file exclusion, and generation statistics
✅ Improved ignore matching with exact directory-name matching and simple wildcard support
✅ Improved regeneration by replacing existing Markdown structure sections and keeping file comments
✅ Added localized labels for clipboard, conversion, CSV, and HTML output

v1.0.2

✅ Added auto-update feature
✅ Fixed comment preservation issue
✅ Fixed file recognition issues (e.g., routes.js, router folders)
✅ Updated default ignore patterns (added .git)
✅ Right-click folders can choose between generating project structure or directory structure
✅ Command palette dedicated to generating project structure

v1.0.1

✅ Added directory structure generation feature
✅ Multi-language support

v1.0.0

Initial release

中文版本

VS Code 扩展，用于扫描项目文件并生成结构化的目录树文件。支持文件变化时自动更新！

✨ 功能特色

双生成模式：项目整体结构或目录特定结构
智能文件注释：保留并显示文件名后用 # 标记的注释
自动更新：可选的文件/文件夹创建、删除或重命名时自动重新生成
剪贴板导出：无需写入文件，直接复制项目或目录结构
选中结构转换：将编辑器中选中的树形结构转换为 HTML、CSV 或 Mermaid 思维导图文件
多输出格式：支持生成 Markdown、Mermaid 思维导图（.mmd）、CSV 或独立 HTML 可视化文件
交互式 HTML 视图：HTML 输出包含搜索、展开/折叠和统计信息
.gitignore 支持：扫描时可自动应用 .gitignore 规则
生成统计：生成后显示目录数、文件数和忽略项数量
更安全的扫描：自动排除输出文件本身，并优先排列目录再排列文件
灵活配置：可自定义忽略模式、扫描深度和输出文件名
多语言支持：中英文界面
智能过滤：默认忽略常见目录如 .git、.idea、.vscode、dist、node_modules

🚀 使用方法

可用命令

1. 生成项目结构

功能：从根目录扫描整个项目
保存位置：始终保存到项目根目录
输出行为：使用 projectStructure.outputFileName 和当前配置的输出格式
使用场景：用于完整的项目文档
访问方式：
- 命令面板："生成项目结构"
- 文件右键："生成项目结构"
- 文件夹右键："生成项目结构"

2. 生成目录结构

功能：仅扫描选中的目录
保存位置：保存到选中的目录
输出行为：使用 projectStructure.directoryOutputFileName 和当前配置的输出格式
使用场景：用于记录特定模块或子目录
访问方式：
- 文件夹右键："生成目录结构"

3. 复制项目结构到剪贴板

功能：生成结构并复制到剪贴板，不写入文件
扫描范围：命令面板复制工作区结构；右键时复制选中文件夹或选中文件所在目录
格式：使用当前配置的 projectStructure.outputFormat
使用场景：粘贴到聊天、Issue、提示词或文档
访问方式：
- 命令面板："复制项目结构到剪贴板"
- 文件/文件夹右键："复制项目结构到剪贴板"

4. 转换选中的结构

功能：将编辑器中选中的树形结构转换为 HTML、CSV 或 Mermaid 思维导图
保存位置：保存到当前文件所在目录；如果当前文档没有文件路径，则保存到工作区根目录
输出名称：使用 <根节点名称>-structure 加所选格式扩展名
使用场景：已有 Markdown 文件里的结构块，需要临时转换成其他格式
访问方式：
- 在编辑器中选中结构文本
- 右键选择"将选中结构转换为..."

命令访问方式

命令面板

按 Ctrl+Shift+P (Windows/Linux) 或 Cmd+Shift+P (macOS)
输入"生成项目结构"并选择命令

注意：命令面板提供项目整体生成、剪贴板导出和配置命令。

右键菜单

文件右键：显示"生成项目结构"和"复制项目结构到剪贴板"
文件夹右键：显示"生成项目结构"、"生成目录结构"和"复制项目结构到剪贴板"

重要区别：

命令面板：适合生成项目整体结构和复制到剪贴板
右键文件夹：可选择生成项目结构、目录结构或复制到剪贴板

⚙️ 配置选项

在 VS Code 设置中搜索 projectStructure、Project Structure Generator 或 项目结构生成器，也可以使用"配置项目结构生成器"命令访问设置。

可用设置

设置项	类型	默认值	描述
`projectStructure.outputFileName`	字符串	"PROJECT_STRUCTURE"	项目结构输出文件名，不含扩展名
`projectStructure.directoryOutputFileName`	字符串	"PROJECT_STRUCTURE"	目录结构输出文件名，不含扩展名
`projectStructure.outputFormat`	字符串	"markdown"	输出格式：`markdown`、`mindmap`、`csv` 或 `html`
`projectStructure.ignoredPatterns`	数组	`[".git", ".idea", ".vscode", "dist", "node_modules"]`	要忽略的文件/目录
`projectStructure.maxDepth`	数字	0	扫描的最大目录深度；`0` 表示不限制
`projectStructure.autoUpdate`	布尔值	false	文件变化时自动更新
`projectStructure.useGitignore`	布尔值	true	扫描时应用 `.gitignore` 规则
`projectStructure.excludeOutputFile`	布尔值	true	从生成的结构中排除输出文件本身
`projectStructure.showStats`	布尔值	true	生成后显示目录/文件/忽略项数量

输出格式

输出文件会根据所选格式自动添加扩展名：.md、.mmd、.csv 或 .html。

markdown：更新或创建 .md 文件；如果找到已有结构段会直接替换，并保留已有结构块里的注释。
mindmap：创建 Mermaid 思维导图 .mmd 文件，用于可视化项目结构。
csv：创建 .csv 文件，包含路径、名称、类型、层级、父目录和注释列。
html：创建独立 .html 树形视图，包含搜索、展开/折叠和统计信息。

扫描行为

会从当前 Markdown 结构中解析 # 后的已有注释，并在重新生成时保留。
默认不限制扫描深度，会递归到底；只有把 projectStructure.maxDepth 设置为正数时才会限制层级。
目录会排在文件之前，同类型项目按名称排序。
忽略模式支持精确文件名、目录名和 *.log 这类简单通配符。
启用 projectStructure.useGitignore 后，会在 projectStructure.ignoredPatterns 之外继续应用 .gitignore 规则。
启用 projectStructure.excludeOutputFile 后，生成的 .md、.mmd、.csv 或 .html 文件不会出现在自己的结构中。

🔄 自动更新功能

启用后，扩展将在以下情况下自动重新生成项目结构：

创建新文件或文件夹
删除文件或文件夹
重命名文件或文件夹

启用自动更新：

打开 VS Code 设置
搜索 projectStructure.autoUpdate
勾选复选框启用

注意：自动更新仅影响项目结构（保存到根目录），不影响目录特定结构。

🔧 重置设置

如果您之前自定义过设置并想使用新的默认值：

打开 VS Code 设置
搜索要重置的设置
点击设置旁边的齿轮图标
选择"重置设置"

📁 文件注释

扩展支持使用 # 符号在文件名后添加注释：

src/
├── components/
│   ├── Button.vue # 可复用按钮组件
│   └── Modal.vue # 模态对话框组件
├── utils/
│   └── helpers.js # 工具函数
└── main.js # 应用程序入口点

要添加注释，只需在现有结构文件中 # 符号后包含它们。

📋 输出示例

my-project #
├── src #
│   ├── components #
│   │   ├── Header.vue # 导航头部组件
│   │   ├── Footer.vue # 页面底部组件
│   │   └── Button.vue # 可复用按钮组件
│   ├── router #
│   │   └── index.js # Vue 路由配置
│   ├── store #
│   │   └── index.js # Vuex 状态管理
│   ├── utils #
│   │   └── api.js # API 辅助函数
│   ├── App.vue # 主应用组件
│   └── main.js # 应用程序入口点
├── public #
│   ├── index.html # HTML 模板
│   └── favicon.ico # 网站图标
├── package.json # 项目依赖
└── PROJECT_STRUCTURE.md # 项目结构输出

📝 更新日志

v1.1.0

✅ 新增剪贴板导出，可复制项目结构或目录结构且不写入文件
✅ 新增可配置输出格式：Markdown、Mermaid 思维导图、CSV 和 HTML
✅ 将项目结构和目录结构的默认输出文件名改为 PROJECT_STRUCTURE
✅ 增强 VS Code 设置搜索，在设置标题和描述中加入 Project Structure Generator / 项目结构生成器关键词
✅ 将默认扫描深度改为不限制；projectStructure.maxDepth 只有设置为正数时才限制递归层级
✅ 新增"将选中结构转换为..."命令，可将选中的树形结构转换为 HTML、CSV 或 Mermaid 思维导图文件
✅ 新增独立 HTML 输出，支持搜索、展开/折叠和统计信息
✅ 转换结果会保存到源文档所在目录，文件名为 <根节点名称>-structure.html、.csv 或 .mmd
✅ 输出文件扩展名会根据配置的格式自动确定
✅ 新增 .gitignore 集成、输出文件自排除和生成统计
✅ 优化忽略匹配，支持精确目录名匹配和简单通配符
✅ 优化重新生成逻辑，可替换已有 Markdown 结构段并保留文件注释
✅ 补充剪贴板、转换命令、CSV 和 HTML 输出相关的本地化文案

v1.0.2

✅ 新增自动更新功能
✅ 修复注释保留问题
✅ 修复文件识别问题（如 routes.js、router 文件夹）
✅ 更新默认忽略模式（新增 .git）
✅ 右键文件夹可选择生成项目结构或生成目录结构
✅ 命令面板专门用于生成项目结构

v1.0.1

✅ 添加目录结构生成功能
✅ 多语言支持

v1.0.0

初始版本发布

Project Structure Generator (项目结构生成器)

LiLiangAn

Project Structure Generator (项目结构生成器)

✨ Features

🚀 Usage

Available Commands

1. Generate Project Structure

2. Generate Directory Structure

3. Copy Project Structure to Clipboard

4. Convert Selected Structure

How to Access Commands

Command Palette

Right-Click Context Menu

⚙️ Configuration Options

Available Settings

Output Formats

Scanning Behavior

🔄 Auto-Update Feature

🔧 Resetting Settings

📁 File Comments

📋 Example Output

📝 Changelog

v1.1.0

v1.0.2

v1.0.1

v1.0.0

中文版本

✨ 功能特色

🚀 使用方法

可用命令

1. 生成项目结构

2. 生成目录结构

3. 复制项目结构到剪贴板

4. 转换选中的结构

命令访问方式

命令面板

右键菜单

⚙️ 配置选项

可用设置

输出格式

扫描行为

🔄 自动更新功能

🔧 重置设置

📁 文件注释

📋 输出示例

📝 更新日志

v1.1.0

v1.0.2

v1.0.1

v1.0.0
