Tonto VS Code Extension

packages/extension contains the VS Code extension published as tonto. It connects the editor UI to the Tonto language server, CLI-style project commands, TPM, PlantUML previews, and the bundled diagram webview.

For user-facing guides, see the documentation site in packages/tonto-documentation.

Features

.tonto language registration, syntax highlighting, semantic tokens, and language configuration.
Langium language client/server activation for diagnostics, completion, hover, references, formatting, and workspace updates.
Tonto activity bar and Explorer command views.
Commands for JSON generation, JSON import, validation, gUFO transformation, TPM install, project initialization, guidance generation, and semantic token color setup.
Optional automatic folding for multilingual label and description blocks.
PlantUML diagram preview/export commands.
Sprotty-based diagram preview and optional .tontodiagram editor.

Runtime Shape

flowchart LR
    VSCode["VS Code"] --> Extension["Extension host<br/>pack/extension/main.cjs"]
    Extension --> Client["LanguageClient"]
    Client --> Server["Language server<br/>pack/language/main.cjs"]
    Server --> Tonto["tonto-cli language services"]
    Extension --> Commands["Tonto commands<br/>views + palette"]
    Commands --> CLI["Generation, import,<br/>validation, transform"]
    Extension --> Webview["Diagram webview<br/>pack/webview"]
    Webview --> Model["Sprotty / React diagram UI"]

Commands

The extension contributes these command IDs:

Command	Title
`tonto.diagram.open`	Open Tonto Diagram
`tonto.diagram.createFile`	New Diagram From Current Model
`tonto.diagram.fit`	Fit to Screen
`tonto.diagram.center`	Center selection
`tonto.diagram.delete`	Delete selected element
`tonto.diagram.export`	Export diagram to SVG
`tonto.diagram.plantuml.open`	Open PlantUML Diagram
`tonto.diagram.plantuml.openProject`	Open Ontology PlantUML Diagram
`tonto.diagram.plantuml.export`	Export PlantUML
`tonto.generateJSON`	Transform Tonto -> JSON
`tonto.generateTonto`	Transform JSON -> Tonto
`tonto.validateModel`	Validate Model
`tonto.transformModel`	Transform to GUFO
`tonto.tpm.install`	Install Packages (TPM)
`tonto.initProject`	Init new Tonto project
`tonto.addGuidances`	Add Guidances to project (Work with LLMs)
`tonto.addSkill`	Add Tonto Skill to project
`tonto.addSemanticTokenColors`	Add Semantic Token Colors to User Settings
`tonto.editor.toggleLabelAndDescriptionFolding`	Toggle Label and Description Folding

Configuration

The .tontodiagram editor is feature-gated through:

{
  "tonto.features.tontodiagram.enabled": true
}

Multiline label and description blocks can be folded automatically when a Tonto editor becomes active:

{
  "tonto.editor.autoFoldLabelsAndDescriptions": true
}

The setting is disabled by default and can also be changed with Tonto: Toggle Label and Description Folding. Folding changes only the editor presentation; it does not modify the .tonto document or generated ontology artifacts.

Development

From the repository root:

npm install
npm run build --workspace=tonto
npm run watch --workspace=tonto

The extension build also builds the private webview package:

npm --prefix packages/webview run build
node packages/extension/esbuild.mjs

To run locally in VS Code:

Open this repository in VS Code.
Run the default build task or npm run watch --workspace=tonto.
Launch Run Extension from the debug panel.
Open a .tonto file in the Extension Development Host.

Packaging

npm run package --workspace=tonto

Publishing requires VS Code Marketplace credentials:

npm run publish --workspace=tonto

License

Distributed under the MIT License. See the repository root LICENSE file for more information.
