Scalus Profile — VS Code extension

Annotate your Scala source with Scalus CEK-machine profiling cost, right in the editor, and open the full interactive profile report in a panel.

When you profile a Scalus smart contract, the evaluator emits a machine-readable profile.json (per-source-location and per-builtin cost, the control-flow edges, and the total budget). This extension reads that file and shows the cost inline on the source lines that produced it.

Features

• Inline cost annotations — each profiled line gets ⏱ <cpu> · <mem> · <count>× · <fee> lov at the end of the line.
• Heat background — lines are tinted by their share of the selected metric (cpu or fee), so hot spots jump out.
• Hover breakdown — hover a profiled line for its totals, the builtins invoked there, and the hottest control-flow edges leaving it.
• Status bar — total CEK budget and on-chain fee; click to open the full report.
• Open Report — loads the self-contained interactive HTML report (sortable tables, hot paths, annotated source) into a webview.
• Compiled UPLC view – opens the compiled Untyped Plutus Core of the profiled run beside your code, syntax-highlighted, with the cursor synced in both directions.
• Auto-refresh — re-reads the profile when your tests regenerate it.

Producing a profile

From a Scalus project, run an evaluation with profiling enabled. The simplest way is the environment switch:

SCALUS_PROFILE=full <your test/run command>

For every profiled script run this writes, into the report output directory (SCALUS_DUMP_DIR, default: target/scalus):

• <scriptHash>-<tag>-<index>.profile.html – the interactive report
• <scriptHash>-<tag>-<index>.profile.json – machine-readable data ("schemaVersion": 1)
• <scriptHash>-<tag>-<index>.profile.csv – flat table
• profile-manifest.json – the discovery entry point listing every run

The extension reads profile-manifest.json first (schema version 1, checked): each run appears in the profile picker labelled by script hash, redeemer and Plutus version, and "Open Report" opens the HTML report belonging to the selected run. Without a manifest (older Scalus), the extension falls back to scanning for *profile*.json files, newest first – e.g. ones written directly with:

ProfileFormatter.writeJson(profile, "target/my-profile.json")
ProfileFormatter.writeHtml(profile, "target/my-profile.html") // optional, for the report panel

The JSON file paths are absolute source paths captured at compile time; the extension matches them to your open files by trailing path segments, so a profile generated on CI still lines up.

Usage

1. Open your Scalus project folder in VS Code.
2. Generate a profile (above). The extension auto-discovers it via profile-manifest.json (or the newest *profile*.json when there is no manifest).
3. Open a profiled .scala file — annotations appear on the costed lines.
4. Run Scalus Profile: Open Report from the Command Palette for the rich view.

Commands

Settings

Compiled UPLC view

Scalus compiles your Scala to Untyped Plutus Core, and that is what the CEK machine actually runs. Alongside the profile files, Scalus writes a UPLC source map, <scriptHash>-<tag>-<index>.uplc.json: the pretty-printed program plus, for every printed node, the Scala source range it came from. The extension opens that program in a read-only editor beside your code.

Cursor sync works in both directions once the UPLC editor is open:

• Move the cursor in a .scala file – every UPLC node compiled from that position is highlighted, and the innermost one is revealed.
• Move the cursor in the UPLC editor – the Scala range that produced the node under the cursor is highlighted and revealed. The Scala file must already be visible; the view does not open files for you.

Show Compiled UPLC for Function resolves the function from either editor. One function usually compiles to several stretches of UPLC, so the command highlights all of them, merged into contiguous regions and restricted to the file the cursor is in – same-named functions in other files are not painted.

The UPLC text is registered as its own language (uplc) with a syntax grammar, so keywords, builtin names, constant types and literals are coloured. Files with a .uplc extension get the same highlighting.

Requirements. The view needs the UPLC source map, which only recent Scalus versions write:

• Profile at level full (SCALUS_PROFILE=full), and let the run render report files. Console-only profiling writes nothing to disk, so there is no source map either.
• The run's entry in profile-manifest.json must list a file of format "uplc". With an older Scalus the profile still works and the command reports that no UPLC map is available.

Development

npm install
npm run compile      # bundle to dist/extension.js (esbuild)
npm run typecheck    # tsc --noEmit
npm run vsce:package # build a .vsix

Press F5 in VS Code to launch the Extension Development Host. Open the fixtures/ folder (or any Scalus project) — fixtures/sample-profile.json and sample-profile.html are real output from the Scalus auction example, so you can see the annotations and report immediately.

License

Apache-2.0
