Kylin Clangd

This extension helps developers write, understand and improve C/C++ code by providing:

• .clangd, .clang-format, .clang-tidy file support. Create these three files in workspace folder if doesn't exist when this extension activated. and support auto completion, schema validation when edit these files.
• code completion
• compile errors and warnings
• go-to-definition and cross references
• hover information and inlay hints
• include management
• code formatting
• simple refactorings

Full documentation for clangd is at clangd.llvm.org.

Changes made to the original vscode-clangd extension

• Add some settings to control the clangd server more flexibly.

  • clangd.headerInsertion: set to iwyu to insert include-what-you-use header, set to never to disable header insertion.
  • clangd.enableClangTidyDiagnostic: enable clang-tidy diagnostics. enable this option will create a .clang-tidy file in workspace

• Add a command clangd.createClangdConfigFile to create three files: .clangd, .clang-tidy, and .clang-format in the workspace folder. These files have default configurations that can be modified as needed. You can input Create clangd configuration file in the command palette to execute this command.

• Add auto completion, schema validation for .clangd, .clang-tidy and .clang-format files (You must have extension redhat.vscode-yaml installed to enable schema validation).

  • .clangd file is used to configure the clangd server, see clangd configuration for more information.
  • .clang-tidy file is used to control the clang-tidy diagnostics, see clang-tidy documentation for more information.
  • .clang-format file is used to control the code formatting, see clang-format documentation for more information.

• Adapted for Kylin/openKylin system and Kylin-IDE

Feedback

Please report bugs or feature requests for this extension at Kylin Clangd OpenKylin Repository.

Requirements

• Please install clangd, the newer the better. The extension requires clangd 9 or later. .clangd file support requires clangd 11 or later.
• Please install extension redhat.vscode-yaml to enable schema validation for .clangd, .clang-format, .clang-tidy files.

Setup

clangd server

The extension requires the clangd language server. You will be prompted to download it if it's not found on your PATH. (Automatic installation is possible on x86-64 Linux, Windows, and Mac).

If you have an old version of clangd installed on your system already, you can run "Check for clangd language server update" from the command palette.

Project setup

clangd is based on the clang C++ compiler, and understands even complex C++ code. However, you must tell clangd how your project is built (compile flags). A compile_commands.json file can usually be generated by your build system (e.g. with CMake, by setting -DCMAKE_EXPORT_COMPILE_COMMANDS=1).

See Project Setup in the clangd documentation for details and alternatives.

Features

Auto completion, schema validation for .clangd, .clang-tidy and .clang-format files

Suggestions will appear as you type in these files, you can also press ctrl + space to bring up the suggestion list.

Code completion

Suggestions will appear as you type names, or after . or ->. Because clangd uses a full C++ parser, code completion has access to precise type information.

Errors, warnings, and clang-tidy

Code errors are shown as you type (both as red squiggle underlines, and in the "Problems" panel). These are the same as produced by the clang compiler, and suggested fixes can automatically be applied.

Most clang-tidy checks are supported (these can be enabled using a .clang-tidy file).

Cross-references

Go-to-definition and find-references work across your code, using a project-wide index.

Press Ctrl-P # to quickly navigate to a symbol by name.

Hover and inlay hints

Clangd can describe almost any entity if you hover the mouse (or press Ctrl-KI).

Inlay hints for parameters and deduced types can be shown temporarily or permanently (the editor.inlayHints.enabled setting controls this).

Include management

Code completion works across your codebase and adds #include directives where needed. The • shows includes that will be inserted.

clangd can suggest inserting missing #includes, where they cause errors. It can warn on unused includes.

Formatting

clangd uses the clang-format engine. You can format a file or the selection. When "Format on Type" is enabled in the settings, pressing enter will cause clangd to format the old line and semantically reindent.

The style used for formatting (and certain other operations) is controlled by the project's .clang-format file.

Refactoring

clangd supports some local refactorings. When you select an expression or declaration, the lightbulb menu appears and you can choose a code action.

Current refactorings include:

• extract variable/function
• expand auto types and macros
• use raw strings
• rename (bound to <F2>, rather than a contextual code action)
