NWScript Workbench

Complete NWScript development tools for VS Code Desktop and VS Code for the Web (vscode.dev, github.dev, Codespaces web editor).

The extension uses KobaltBlu/nwscript-wasm, which packages the native NWScript compiler as WebAssembly. The compiler JavaScript is bundled into the extension and the .wasm binary is shipped inside the VSIX, so no native compiler, Nim, Python, Emscripten, or network access is required at runtime.

NWScript Workbench Home

Run NWScript Workbench: Open Home to open the extension control center in an editor tab.

NWScript Workbench Home provides:

• current workspace and active language-specification status
• language-specification selection and project auto-detection controls
• inline controls for compile-on-save, optimization, and NDB output
• summaries of include/output configuration
• a clear explanation of how nwscript.nss is resolved for each script
• recommended workspace layouts for K1, K2, and custom game targets
• offline help for project language specifications, includes, configuration, and troubleshooting
• a right-side Knowledge Base with focused articles for language-spec resolution and multi-game project layout
• links to the extension and compiler repositories

The Home tab opens automatically once on first run and remains available from the Command Palette afterward.

Script Browser

Run NWScript Workbench: Browse Scripts to search the decompiled KOTOR and TSL source catalog maintained by KOTOR Community Patches.

The browser fetches the repository catalog from GitHub. Search operates locally over script names and repository paths; selecting a result fetches only that script for preview. You can open a source copy in an untitled NWScript editor or download it through VS Code's URI-aware save dialog into a desktop, browser, or virtual workspace.

No upstream script source is packaged with NWScript Workbench. An internet connection is required, and downloaded sources remain subject to the upstream repository and game-content terms.

Language specification resolution

The extension resolves the nwscript.nss used by a script in this order:

1. Custom Language Specification — an nwscript.nss explicitly selected in extension configuration.
2. Embedded Game Target — a language specification bundled into the installed nwscript-wasm build.
3. Workspace-root specification — nwscript.nss at the root of the active workspace folder.
4. Nearest ancestor specification — the closest nwscript.nss above the script being edited or compiled.
5. Single discovered project specification — if exactly one nwscript.nss exists in the workspace, it is used automatically.
6. Ambiguous — if multiple specifications remain possible, the extension does not guess and asks the user to choose one.

A workspace-root nwscript.nss is authoritative for that workspace folder. For projects that contain scripts for multiple games, we recommend placing each game in its own subfolder with its own nwscript.nss rather than putting a shared specification at the workspace root.

Recommended layout:

My NWScript Workspace/
├─ kotor1/
│  ├─ nwscript.nss
│  ├─ includes/
│  └─ scripts/
│     └─ k1_script.nss
│
├─ kotor2/
│  ├─ nwscript.nss
│  ├─ includes/
│  └─ scripts/
│     └─ k2_script.nss
│
└─ custom-game/
   ├─ nwscript.nss
   └─ scripts/
      └─ custom_script.nss

With this layout, scripts under kotor1/ resolve against kotor1/nwscript.nss, scripts under kotor2/ resolve against kotor2/nwscript.nss, and custom projects can provide their own language specification independently.

Features

• Compile .nss files to .ncs entirely through WebAssembly.
• Runs in the browser extension host and the desktop extension host.
• Uses only VS Code URI / workspace.fs APIs at runtime, including virtual workspaces.
• Custom Language Specification: explicitly select an nwscript.nss from the workspace or any URI exposed by VS Code.
• Project auto-detection: when no explicit language spec or embedded target is selected, the extension automatically discovers nwscript.nss in the active workspace folder.
• Optional embedded game targets supplied by nwscript-wasm when present.
• Recursive #include discovery and loading.
• Configurable include search paths.
• Compiler errors surfaced as VS Code diagnostics.
• Optional compile-on-save.
• Optional NDB generation.
• Configurable O0/O1/O2/O3 optimization level.
• Read-only NCS hex editor with automatic side-by-side disassembly preview.
• NCS disassembly when the installed nwscript-wasm build exposes it.
• Basic NWScript and NCS assembly syntax highlighting.

Why this works online and offline

The extension has only a browser entry point. VS Code therefore runs the same web-extension bundle in:

• VS Code Desktop
• vscode.dev
• github.dev
• browser-based Codespaces
• other VS Code-compatible web extension hosts

The runtime does not import Node's fs, path, or child-process APIs. Workspace and extension resources are read and written through vscode.workspace.fs.

During the extension build, @neverwinter/nwscript-wasm is pulled from:

https://github.com/KobaltBlu/nwscript-wasm/tree/master

Its JavaScript wrapper is bundled into dist/web/extension.js and its compiled WASM is copied to:

dist/web/nwscript-compiler.wasm

At runtime the extension reads the WASM bytes from its own installation and passes them directly to Emscripten.

Development

Requirements for building the extension itself:

• Node.js 22+
• npm
• Git

You do not need Emscripten locally unless you are rebuilding nwscript-wasm itself.

Install dependencies:

npm install

Build:

npm run build

The output is:

dist/web/extension.js
dist/web/extension.js.map
dist/web/nwscript-compiler.wasm

Run in VS Code Desktop as a web extension

Open this project in VS Code and run the Run Web Extension launch configuration.

It launches an Extension Development Host with:

--extensionDevelopmentKind=web

so the exact browser-hosted extension code is tested even on desktop.

Run in a browser

The project includes @vscode/test-web:

npm run test-web

This builds the extension and launches a local VS Code for the Web instance.

Package a VSIX

npm run package

The generated VSIX contains the bundled extension JavaScript and compiler WASM. A user installing that VSIX on desktop does not need access to GitHub or npm afterward.

Commands

NWScript Workbench: Compile Current File

Compile the active or Explorer-selected .nss file.

The default output location is beside the source file:

script.nss
script.ncs

If NDB generation is enabled:

script.nss
script.ncs
script.ndb

NWScript Workbench: Select Compiler Target

Choose either:

• Custom Language Specification: Choose nwscript.nss...
• any game target embedded in the bundled nwscript-wasm

Embedded targets are optional. A WASM build containing no embedded language specifications is fully supported.

NWScript Workbench: Select Custom Language Specification

Opens VS Code's URI-aware file picker and stores the selected language specification in the current workspace/workspace-folder configuration. This works with desktop files, vscode.dev, github.dev, and virtual workspace file-system providers.

NWScript Workbench: Show Embedded Game Targets

Displays the target names compiled into the WASM package.

Opening NCS files

Opening an .ncs file uses the extension's readonly NWScript NCS Hex custom editor by default. The primary editor shows the binary as a conventional 16-byte-per-row hex dump with offsets and an ASCII column.

At the same time, the extension disassembles the NCS with the active custom, project-detected, or embedded language specification and opens <name>.ncsasm beside the hex view as a preview tab without stealing focus.

If the language specification cannot be resolved, the hex view still opens normally and the assembly preview displays the disassembly error.

NWScript Workbench: Disassemble NCS

Reads an .ncs file, calls the WASM disassembler, and opens the same named <name>.ncsasm preview used by the automatic NCS viewer.

Custom Language Specifications

The extension does not require the WASM package to contain game-specific nwscript.nss files. Users can explicitly select a custom language specification at runtime.

Use NWScript Workbench: Select Compiler Target and choose Custom Language Specification: Choose nwscript.nss..., or run NWScript Workbench: Select Custom Language Specification directly.

The selected resource is read through vscode.workspace.fs, not Node filesystem APIs. That means the language spec can come from a normal desktop workspace or from a virtual/browser workspace provider.

A workspace-relative selection is persisted as ${workspaceFolder}/...; resources outside the workspace are stored as explicit VS Code URIs.

Example workspace configuration:

{
  "nwscript.languageSpec": "${workspaceFolder}/game/k1/nwscript.nss"
}

No game assets need to be included in the extension or the nwscript-wasm distribution.

Configuration

nwscript.gameTarget

Default:

""

Optional embedded game target used to supply nwscript.nss. Embedded targets are a convenience only; leave this empty when using a custom or project language specification.

nwscript.autoDetectLanguageSpec

{
  "nwscript.autoDetectLanguageSpec": true
}

When enabled, the extension automatically searches the active workspace folder for nwscript.nss whenever neither nwscript.languageSpec nor nwscript.gameTarget is configured.

Detection prefers a workspace-root nwscript.nss, then the nearest nwscript.nss in an ancestor directory of the script being compiled or edited. If no ancestor applies and exactly one specification exists in the workspace, that file is used automatically. Multiple unrelated specifications are treated as ambiguous so the extension does not guess between game targets.

For multi-game workspaces, place each game's scripts below its own game folder and keep that folder's nwscript.nss alongside them. Avoid a workspace-root nwscript.nss when the workspace contains multiple independent game environments, because the root specification is authoritative for the workspace folder.

nwscript.languageSpec

Default:

""

Custom Language Specification workspace-relative path or explicit URI to an nwscript.nss.

When set, it overrides nwscript.gameTarget. This is the baseline configuration when the WASM package contains no embedded targets.

Example:

{
  "nwscript.languageSpec": "scripts/nwscript.nss"
}

Using a workspace-relative path is recommended because it also works in vscode.dev and virtual workspaces.

nwscript.includePaths

Example:

{
  "nwscript.includePaths": [
    "scripts",
    "scripts/includes",
    "shared"
  ]
}

Include resolution checks, in order:

1. The directory containing the including NSS file.
2. nwscript.includePaths.
3. A lazily generated workspace-wide .nss resource index.

The extension recursively scans discovered includes and preloads them into the in-memory compiler resource manager.

nwscript.outputDirectory

Default:

""

Empty writes generated files beside the source NSS.

A workspace-relative output directory can be configured:

{
  "nwscript.outputDirectory": "compiled"
}

nwscript.compileOnSave

{
  "nwscript.compileOnSave": true
}

Compiles an NSS document after it is saved.

nwscript.optimizationLevel

Supported values:

O0
O1
O2
O3

Default: O1.

nwscript.generateDebug

Generate .ndb output when supported by the compiler:

{
  "nwscript.generateDebug": true
}

nwscript.maxIncludeDepth

Maximum native compiler include depth. Default: 32.

nwscript.maxResolveAttempts

Maximum number of include resources recursively loaded before a compilation. Default: 64.

Diagnostics

Compiler errors such as:

k_test.nss(12): ERROR: DECLARATION DOES NOT MATCH PARAMETERS

are converted into VS Code diagnostics and attached to the corresponding NSS file and line.

The extension also pre-resolves #include resources before invoking the compiler. This makes the extension usable even with older nwscript-wasm builds whose native FILE NOT FOUND diagnostic does not identify the missing resref.

Browser / virtual workspace considerations

VS Code Web does not expose arbitrary host filesystem paths. For maximum compatibility:

• keep NSS source and includes inside the opened workspace;
• configure include paths relative to the workspace;
• configure a custom nwscript.nss with a workspace-relative path;
• allow the virtual workspace provider to handle generated NCS/NDB writes.

A provider may expose a read-only virtual workspace. In that case compilation still works in memory, but writing the generated NCS/NDB to that provider will fail until the workspace is writable.

Updating the compiler dependency

The dependency intentionally points at the master branch of KobaltBlu/nwscript-wasm:

{
  "dependencies": {
    "@neverwinter/nwscript-wasm": "github:KobaltBlu/nwscript-wasm#master"
  }
}

To refresh a local checkout to the latest compiler commit:

npm install

If a lockfile is already pinning an older Git commit, update the dependency explicitly or regenerate the lockfile before producing a release.

Architecture

VS Code / vscode.dev
        │
        ▼
Web Extension Host
        │
        ├── VS Code workspace.fs
        │      ├── NSS source
        │      ├── includes
        │      └── NCS/NDB output
        │
        ▼
CompilerService
        │
        ├── ResourceResolver
        ├── Diagnostics
        └── @neverwinter/nwscript-wasm
                    │
                    ▼
              WebAssembly
                    │
                    ▼
              NCS / NDB

Licensing

The extension source is distributed under GPL-3.0-only because the packaged extension includes the linked NWScript compiler WebAssembly artifact, which is subject to the upstream compiler's GPL-3.0 licensing.

See THIRD_PARTY_NOTICES.md for the upstream compiler dependency.

Engine-aware editor intelligence

The extension builds IntelliSense directly from the active nwscript.nss language specification. Custom and auto-detected project specifications are parsed into a cached engine API model, so changing the active spec changes the editor API without rebuilding the extension.

The NWScript editor provides:

• engine function completions with parameter and return-type metadata
• engine constants and global symbols from the active language specification
• snippet-style function insertion with parameter placeholders
• signature help on ( and ,, including defaults and active-argument highlighting
• multiple signatures when the active specification declares the same function name more than once
• rich hover cards with the declaration, return type, parameter documentation, engine ACTION ID, active-spec availability, and curated NWScript notes for selected APIs

ACTION IDs are derived from function declaration order in the active nwscript.nss, matching the engine command table represented by the language specification.

The current nwscript-wasm public API exposes the names of embedded targets but does not expose the decompressed source text of an embedded nwscript.nss. Compilation can still use an embedded target, but editor intelligence requires an accessible custom or project nwscript.nss until the WASM package exposes that source text to consumers.

Native VS Code navigation

NWScript symbols participate in VS Code's normal language-navigation workflow. The extension resolves symbols using the same translation-unit model as IntelliSense: declarations in the current script take precedence over recursively included NSS files, which take precedence over the active nwscript.nss engine API.

Supported editor features include:

• Go to Definition and Peek Definition for script, include, and engine symbols
• Go to Declaration using the same NWScript symbol resolution
• Find All References across NSS files that actually see the same declaration through their include/spec scope
• Rename Symbol for user script/include symbols; engine API symbols are intentionally read-only
• Document Highlights for the active symbol
• Outline / Go to Symbol in Editor for top-level functions, constants, and globals
• Go to Symbol in Workspace across NSS files
• clickable #include resource links and Go to Definition on include resrefs

Reference and rename searches ignore comments and string literals and validate each candidate NSS file against its resolved translation-unit symbol model instead of performing a blind workspace text replacement.
