kiberon-labs Behave Graphs for VScode

This is a proof of concept exploration of embedding the graph engine inside of VS Code for faster iteration of behave graph

Features

• Provides a custom editor for the new file extension type .kbgraph which is a kiberon-labs specific format for the serialized behave graph.

• Custom icons for the .kbgraph format

• Provides a command to quick create new Graph files

• Built-in graph execution server with support for custom registries

Custom frontend plugins

Frontend plugins can be loaded dynamically via the use of a plugin.js file adjacent to a graph.

Examples

Ready-to-run example graphs live in examples/. Open an example's .kbgraph in the editor and press Run; the adjacent registry.ts is loaded automatically so its custom nodes are available. The set covers a headless workflow, a Web-Audio-style audio chain (custom value type + node kind), a game loop on RealtimeEngine, and an embed value type. See examples/README.md.

Custom Registry Support

The GraphRunnerServer loads custom registries to extend or replace the default core profile nodes. When you open a .kbgraph, an adjacent registry.ts / registry.js (or one named by a .kbworkspace) is dynamically loaded — TS is transpiled on demand, so a .ts registry works without a build step.

Usage

Note: .ts registries and plugins are transpiled on demand using the typescript (or esbuild) compiler installed in your workspace. There is no build step, but one of those must be present in your project's node_modules. If neither is installed, ship a precompiled .js registry instead.

Create a registry.ts (or .js) that exports a configured registry:

import { registerCoreProfile, ManualLifecycleEventEmitter } from '@kiberon-labs/behave-graph';

export const registry = registerCoreProfile({
  values: {},
  nodes: {
    // Add custom node types here
  },
  dependencies: {
    ILogger: console,
    ILifecycleEventEmitter: new ManualLifecycleEventEmitter(),
  }
});

A registry module may also export two optional seams the run server honors:

• executionHandlers — a map of custom node kind → handler, taught to the engine via registerNodeExecutionHandler. This lets you add brand-new node kinds (not just node types). See examples/audio/registry.ts.
• createEngine — a factory (graph, registry) => Engine to run on a different engine, e.g. RealtimeEngine. See examples/game/registry.ts.

See examples/ for complete, runnable registries.

Requirements

Running graphs works out of the box. Loading a .ts registry or editor plugin additionally requires typescript (or esbuild) installed in the graph's workspace; see Custom Registry Support.

Extension Settings

The extension exposes the following settings (under Settings → Extensions → Behave Graph). They control the built-in MCP server that lets external agents and VS Code Copilot use the editor's tools.

Known Issues

Due to how serialization occurs for array buffers and typed arrays, you must use engine 1.57.0 and above of vscode to prevent huge data transfer inefficiencies

Release Notes

Please see the changelog included in the project for more information
