R XPath Generator

Generate smart, ranked XPath expressions and CSS selectors from HTML — with a visual preview panel, element tree sidebar, and framework-ready code snippets. Built for test automation engineers who live in VS Code.

Screenshots

Visual HTML Preview Panel

Element Tree Sidebar

Ranked XPath QuickPick

Framework Code Snippet

Why This Extension?

Browser DevTools are great for inspecting live pages — but when you're writing tests, you're already in your editor. This extension brings the inspect-and-locate workflow directly into VS Code:

• No need to spin up a browser just to find a locator
• Works on raw HTML, JSX, and TSX source files
• Generates multiple ranked strategies, not just one guess
• Outputs ready-to-paste code for your framework of choice

Features

🎯 Visual HTML Preview Panel

Open any HTML file and click any element visually — just like browser DevTools, inside VS Code.

• Hover over elements to see a tooltip with all attributes
• Click any element to instantly generate ranked XPaths
• Filter bar to highlight elements by tag, class, or ID
• Actionable only toggle — dims divs and spans, highlights inputs, buttons and links

🌲 Element Tree Sidebar

A collapsible DOM tree in the VS Code activity bar showing every element in the open file.

• Structured exactly like the browser Elements panel
• Click any node to generate XPath and jump to that element in source
• Colour-coded icons for inputs, buttons, links, selects
• Auto-refreshes when you save the file

📊 Smart XPath Ranking

Every generated XPath is scored out of 10 based on reliability for test automation.

🔗 Relational XPath Strategies

Automatically generates label→input sibling patterns — the most robust locators for form elements.

//label[normalize-space()='Username']/following-sibling::input
//label[contains(text(),'Email')]/following-sibling::input[1]
//*[@id='login-form']//input[@name='password']

📋 CSS Selector Output

Every XPath suggestion includes a parallel CSS selector generated with the same priority logic.

#email-field
input[name="username"]
input[data-testid="search-input"]
.checkout-form input

💻 Framework Code Snippets

Copy locators as ready-to-paste code for your test framework.

Selenium Python

# XPath
element = driver.find_element(By.XPATH, "//input[@name='username']")

# CSS Selector
element = driver.find_element(By.CSS_SELECTOR, "input[name='username']")

Playwright TypeScript

// XPath
const element = page.locator('xpath=//input[@name="username"]');

// CSS Selector
const element = page.locator('input[name="username"]');

Selenium Java

// XPath
WebElement element = driver.findElement(By.xpath("//input[@name='username']"));

// CSS Selector
WebElement element = driver.findElement(By.cssSelector("input[name='username']"));

Cypress

// XPath (requires @cypress/xpath plugin)
cy.xpath('//input[@name="username"]')

// CSS Selector
cy.get('input[name="username"]')

✅ Live XPath Validation

Each suggestion shows a match count against the full open document so you instantly know if a locator is too broad or broken.

✅ 1 match   → exact, safe to use
⚠️ 3 matches → too broad, pick a more specific strategy
❌ 0 matches → broken, element not found in document

🔀 Multi-Selection Support

Hold Alt and click to create multiple selections. The extension processes all of them in one pass and groups results by block.

📦 Bulk JSON Export

Export all generated locators for an entire HTML file as a structured JSON — useful for maintaining a locator library.

[
  {
    "selectionBlock": 1,
    "element": "<input>",
    "topXPath": "//input[@name='username']",
    "topCSSSelector": "input[name='username']",
    "topScore": 8,
    "snippet": "element = driver.find_element(By.XPATH, \"//input[@name='username']\")",
    "allXPaths": [
      { "label": "name", "xpath": "//input[@name='username']", "score": 8 },
      { "label": "placeholder", "xpath": "//input[@placeholder='Enter username']", "score": 7 }
    ]
  }
]

⚡ Auto data-testid Insertion

If no stable attributes are found (score below 7), the extension offers to insert a data-testid directly into your source HTML — with a suggested value built from existing attributes.

<!-- Before -->
<button class="btn-primary">Login</button>

<!-- After (auto-inserted) -->
<button class="btn-primary" data-testid="login-button">Login</button>

Usage

Method 1 — Visual Preview Panel (Recommended)

1. Open any .html, .jsx, or .tsx file
2. Press Ctrl+Shift+V or right-click → XPath: Open HTML Preview
3. The preview opens beside your editor
4. Hover over any element to see its attributes
5. Click any element to generate XPaths
6. Pick a strategy from the ranked list
7. Choose to copy raw XPath, CSS selector, or a code snippet

Method 2 — Element Tree Sidebar

1. Click the XPath Generator icon in the VS Code activity bar (left strip)
2. Open an HTML file — the tree auto-populates
3. Browse or expand elements in the tree
4. Click any element to generate XPath and highlight it in source

Method 3 — Select & Generate (Classic)

1. Open any HTML file
2. Select an HTML element or block in the editor
3. Press Ctrl+Shift+X (Mac: Cmd+Shift+X) — or right-click → XPath: Generate Smart XPath
4. Pick a strategy from the QuickPick list
5. Choose your copy format

Example

Given this HTML:

<div id="login-form">
  <label>Username</label>
  <input name="username" placeholder="Enter your username" />
  <button data-testid="login-btn" class="btn-primary">Login</button>
</div>

Clicking the <input> generates:

✅ [9/10] label→input (sibling text)  → //label[normalize-space()='Username']/following-sibling::input
✅ [8/10] name                        → //input[@name='username']
✅ [8/10] parent#id > child           → //*[@id='login-form']//input
✅ [7/10] placeholder                 → //input[@placeholder='Enter your username']
✅ [6/10] parent#id > nth child       → //*[@id='login-form']/input[1]

Clicking the <button> generates:

✅ [9/10] data-testid                 → //button[@data-testid='login-btn']
✅ [7/10] exact text                  → //button[normalize-space()='Login']
✅ [8/10] parent#id > child           → //*[@id='login-form']//button
✅ [5/10] partial text                → //button[contains(text(),'Login')]
✅ [4/10] class                       → //button[contains(@class,'btn-primary')]

Commands

Mac users: Replace Ctrl with Cmd for all shortcuts.

Supported File Types

Note: JSX/TSX support covers static attributes in source. Dynamically rendered DOM (runtime JavaScript) requires browser DevTools.

Extension Settings

Configure via File → Preferences → Settings → search rXpathGenerator.

Supported Frameworks

Switch anytime via Command Palette → XPath: Set Framework.

Requirements

• VS Code 1.85.0 or higher
• No additional dependencies — zero npm runtime packages

Known Issues

• JSX/TSX dynamic expressions (e.g. className={styles.form}) are not evaluated — only static string attributes are parsed
• Very large HTML files (5000+ elements) may cause a brief delay on tree refresh
• The preview panel renders raw HTML without external CSS files linked via <link> tags — inline styles work fully

Release Notes

0.0.1 — Initial Release

• Smart XPath generation with 17 strategies
• CSS Selector parallel output
• Live document match validation
• Visual HTML Preview Panel with click-to-select
• Element Tree Sidebar (DOM explorer)
• Multi-selection support
• Framework code snippets — Selenium, Playwright, Cypress
• Bulk JSON export
• Auto data-testid insertion
• Configurable framework setting

Contributing

Found a bug or want to suggest a feature?

• Open an issue
• View source on GitHub

License

MIT
