KDAB DAP

A VS Code extension that debugs C/C++ programs using GDB's and LLDB's own Debug Adapter Protocol support. Both debuggers speak DAP natively — GDB as gdb -i dap, LLDB through its lldb-dap binary — so this extension is a thin layer: it finds a suitable debugger, works out what to pass it, and hands it to VS Code as the debug adapter.

Linux and macOS. Windows is out of scope, by design.

There are two debug types, one per debugger:

GDB 16.1 is the floor because older GDBs run the inferior as part of the DAP launch request instead of deferring it to configurationDone, so breakpoints set before the program starts are never hit, and they ignore stopOnEntry. LLDB has no comparable floor, so there is no version check for it.

gdb is Linux-only here for a reason that isn't the extension's to fix: macOS requires a debugger to be code-signed for debugging, and gdb isn't. Use kdap-lldb there. Nothing stops a kdap configuration on macOS if you have a gdb that works — it just won't be found by default.

lldb-dap is looked up as lldb-dap, falling back to the highest lldb-dap-<version> on PATH, since distributions often ship only the suffixed name. On macOS, where Xcode and the Command Line Tools keep lldb-dap inside the developer directory instead of on PATH, it then asks xcrun for it, so a stock install needs no configuration.

macOS and code signing

The lldb-dap that comes with Xcode is signed for debugging and works as-is. One from Homebrew or an LLVM release is only ad-hoc signed, and launching under it fails with attach failed (Not allowed to attach to process) until its debugserver is signed with com.apple.security.cs.debugger, or LLDB_DEBUGSERVER_PATH points at Xcode's. Since PATH is searched before xcrun, an unsigned one on PATH is what gets picked — set kdap.lldb.path to Xcode's, or unset it from PATH, if you hit this. Attaching by pid to a process you don't own needs elevation on macOS, as it does elsewhere.

Usage

Create a launch configuration in .vscode/launch.json:

{
  "type": "kdap", // or "kdap-lldb"
  "request": "launch",
  "name": "Launch",
  "program": "${workspaceFolder}/<your program>",
  "args": [],
  "cwd": "${workspaceFolder}",
  "stopOnEntry": true
}

Or use the "GDB: Launch" / "LLDB: Launch" snippets, and their Attach and Load Core Dump counterparts, offered when adding a new configuration.

Shared configuration

These mean the same thing under both debuggers, in both launch and attach configurations.

• debuggerPath: Path to the debugger executable to use, with a leading ~ expanded. Overrides the kdap.gdb.path / kdap.lldb.path setting.
• sourceFileMap: Maps source paths recorded in the debug info to their location on disk. Each key is the path as recorded, each value where it is found locally. Applied with set substitute-path under gdb and target.source-map under lldb.
• program: Path to the executable to debug.
• sysroot: Where to look for shared libraries and debug info, as if by set sysroot. gdb only — lldb's nearest equivalent, platform select --sysroot, also picks a platform, which would be the wrong guess for the remote targets sysroot exists to serve. Use initCommands under lldb to say exactly what you mean.
• skipInitFiles: Skip reading the debugger's own init files, as if by passing -nx. gdb only — lldb-dap sources ~/.lldbinit unconditionally and offers no way to stop it.
• qtPrettyPrinters: Automatically load Qt pretty-printers (default false). Under gdb, this downloads the KDevelop Qt gdb pretty-printer scripts on first use, offering to do so if they aren't there yet. Under lldb-dap, this imports the Qt pretty-printers bundled with the extension - nothing to download.

Setting a gdb-only option on an kdap-lldb session isn't fatal: the session starts and a warning says what was ignored.

Launch

• args: Command-line arguments passed to the inferior.
• cwd: The working directory for the debugger and the launched program. If omitted, the debugger inherits VS Code's working directory rather than the workspace folder, so set this explicitly.
• env: Environment variables for the inferior. These are added to the environment the inferior would otherwise inherit; PATH, HOME and friends survive. (gdb's DAP handler replaces the whole environment instead; the extension works around that so both debuggers behave the same way.)
• stopOnEntry: Stop at the program's first instruction. Defaults to false.
• stopAtBeginningOfMainSubprogram: Stop at main, as if by gdb's start command. gdb only.

Attach

• pid: The process ID to attach to.
• coreFile: Path to a core dump file to load instead of attaching to a live process.
• target: The target to connect to, passed to target remote. gdb only — under lldb, use initCommands with gdb-remote or platform connect.

lldb-dap configuration

kdap-lldb configurations also accept lldb-dap's own properties, which it reads directly: initCommands, preRunCommands, postRunCommands, stopCommands, exitCommands, terminateCommands, launchCommands, attachCommands, runInTerminal, waitFor, platformName, targetTriple, debuggerRoot, disableASLR, disableSTDIO, shellExpandArguments, detachOnError, enableAutoVariableSummaries, enableSyntheticChildDebugging, displayExtendedBacktrace, customFrameFormat, customThreadFormat and timeout. See lldb-dap's documentation for what each does.

Settings

• kdap.gdb.path: Path to the gdb binary. Defaults to searching PATH.
• kdap.lldb.path: Path to the lldb-dap binary. Defaults to searching PATH, then xcrun on macOS.
• kdap.logPath: Enable DAP logging to this file, for whichever debugger is in use.
• kdap.gdb.logLevel: gdb's DAP logging verbosity (default 1). gdb only; lldb-dap has no equivalent.
• kdap.environment: Extra environment variables set on the debugger process itself.

Commands

• KDAB DAP: Download Qt Pretty Printers — downloads the KDevelop Qt gdb pretty-printer scripts into the extension's global storage. Run this once via the Command Palette to enable Qt pretty-printing (see qtPrettyPrinters above). Linux only, being for gdb; lldb's Qt pretty-printers ship with the extension and need no download.
• KDAB DAP: Debug with Args — starts one of your launch configurations, prompting for the arguments to pass to the inferior instead of using the configuration's args. The input is split like a shell splits a command line, so quote arguments containing spaces.
• KDAB DAP: Run with Args — the same, but without debugging: breakpoints and entry stops are ignored.
• KDAB DAP: Load Core File — starts one of your attach configurations against a core dump, prompting for the core file and program if the configuration doesn't name them.

The last three work with both debug types, on both platforms.
