Mark Highlight — Xcode-style // MARK: comments for VSCode

Give a section of code a name once, and see it everywhere:

// MARK: - Networking

That single comment becomes a full-width divider in the editor, an entry between your real symbols in the Outline, breadcrumbs, and Go to Symbol (Cmd+Shift+O), a tick in the overview ruler, and a section label in the minimap.

Why Mark Highlight

• Navigate by intent, not just by symbol. Long files don't get shorter — but "Types", "Store", "Lookup helpers" are how you actually think about them. Marks make those sections jumpable instead of scroll-and-squint.
• One merged list, not a second tree. The usual approach — a separate symbol provider — splits the Outline into a "MARK" group next to "TypeScript", because VSCode cannot merge outline trees. Mark Highlight instead injects marks into TypeScript's own symbol tree via a bundled tsserver plugin: one list, ordered by position, with marks nesting into their containing class exactly like Xcode.
• Every language, zero setup. Each language's real comment tokens are discovered from its own configuration: // in TS/Go/Rust/Swift, # in Python/Ruby/Shell/YAML, -- in SQL/Lua, /* */ in CSS, <!-- --> in HTML — including any third-party language you install.
• Two features that can never disagree. The divider and the outline entry come from one shared parser, so what you see in the code is always what you get in navigation — no more stacking two extensions and hoping they match.
• Light and live. Mark-free files cost one substring scan; updates are debounced while typing; every setting applies instantly, no reload.

Quick start

1. Install the extension.
2. Type // MARK: - Section name on its own line (or # MARK: -, -- MARK: -, ... — whatever your language's comment is).
3. Jump to it via the Outline, breadcrumbs, or Cmd+Shift+O.

The dash is optional (// MARK: Section works too), and a bare // MARK: - draws a plain divider without a title — same conventions as Xcode.

The Outline stays one list

Marks are mirrored into symbol navigation between the real symbols — no separate "MARK" group in TypeScript files. Note how Lookup helpers nests inside UserStore:

Every language with comments

Marks are parsed with each language's own comment tokens:

Make it yours

The rule's color, style, and width are configurable — thick rules render as a band in the blank space above the mark line, never over your code:

Settings

All settings apply live — no reload needed.

How it works

Both features key off a single pure function, findMarks(text, keyword) in src/core/findMarks.ts, so they can never disagree about what counts as a mark. That module imports nothing from vscode, which is what lets the Vitest unit tests run without an extension host. A thin adapter maps its results to vscode.Ranges.

• Outline (TS/TSX/JS/JSX): a bundled tsserver plugin (src/tsPlugin/index.ts, shipped in dist/ts-plugin/ and installed into the extension's node_modules/ on activation — the only location tsserver loads plugins from) proxies getNavigationTree and injects one node per mark into TypeScript's own symbol tree. Because the marks live inside the TypeScript provider's results, the Outline stays a single interleaved list — a separate DocumentSymbolProvider would render as its own tree next to "TypeScript" (microsoft/vscode#60641). Marks nest into the node that contains them (a mark inside a class body appears under the class), like Xcode.
• Outline (other configured languages): a regular DocumentSymbolProvider emits flat SymbolKind.Key symbols. For languages with no other symbol provider (plain SQL, shell scripts, ...) the marks simply are the outline. For languages that do have one (CSS/HTML built-ins, Pylance for Python, ...), VSCode renders one Outline tree per provider and cannot merge them (#60641) — marks there appear as their own "MARK" group next to the language's tree. A true merge is only possible where a language server exposes a plugin API, which today is TypeScript only. Cmd+Shift+O always navigates marks and symbols merged, regardless of language.
• Per-language comment syntax (src/commentSyntax.ts): each language's line/block comment tokens are discovered from the language-configuration.json its contributing extension ships — the same data VSCode uses for toggle-comment — so any installed language works without configuration. Marks match a line comment with only whitespace before it, or a block comment that opens and closes on its own line. Languages that declare no comments (plaintext, markdown, ...) are skipped.
• Rule: a single TextEditorDecorationType with isWholeLine: true and a configurable top border, applied to the mark lines of every visible editor. Decoration updates are debounced ~150 ms while typing and applied immediately on editor switches and settings changes.

Why the plugin config travels through a file

VSCode runs two tsserver processes and routes navtree (document symbols) to the syntax server, while the configurePlugin API request only ever reaches the semantic server. Settings therefore reach the plugin through a config.json written next to the installed plugin, which it re-reads (mtime-cached) on every request; configurePlugin is still sent as a secondary channel. Two more cache layers are handled on settings changes: the TS extension's per-document navtree response cache is evicted via a throwaway symbol request, and VSCode's outline-model cache is invalidated by re-registering our symbol provider (which is registered for TS languages too — returning no symbols there — precisely so it participates in that cache key).

Scope notes (deliberate choices)

• Whole-line comments only. A mark matches a line comment with nothing but whitespace before it (// MARK: x, # MARK: x, -- MARK: x), or a block comment occupying the whole line (/* MARK: x */, <!-- MARK: x -->). Trailing comments (foo(); // MARK: x) and multi-line block comments are not matched — this also keeps "// MARK:" inside string literals from producing false positives.
• Keyword matching is case-sensitive, like Xcode.
• Empty titles (// MARK: -) still draw a rule; in the Outline they show as MARK.
• Mark icon: in TS-family files marks show the Variable icon — tsserver plugins can only emit ScriptElementKind strings, and the TS extension maps everything outside its known set (module/class/enum/interface/method/property/variable/function/constructor) to SymbolKind.Variable. Non-TS languages use the key icon (SymbolKind.Key).
• Workspace-specific settings across multiple windows: the tsserver plugin reads one shared config file per extension install, so two windows whose workspaces configure different keywords will share the most recently written one. User-level settings behave as expected.
• No minimap text labels from this extension. The public VSCode API has no way for an extension to draw text into the minimap; the overview-ruler tick is the supported substitute. That said, VSCode itself (1.85+) natively renders // MARK: comments as minimap section headers when editor.minimap.showMarkSectionHeaders is on (the default) — so with the default keyword you get minimap labels anyway, courtesy of the editor.
• Outline interleaving assumes the Outline's default Sort By: Position; sorting by name or category groups the marks together instead.

Development

npm install
npm test              # Vitest unit tests for the parser
npm run test:coverage # + v8 coverage (coverage/index.html)
npm run typecheck     # tsc --noEmit
npm run build         # esbuild → dist/extension.js
npm run package       # vsce package → .vsix (not published)

Regenerating the README screenshots

docs/*.png are generated, not hand-made. scripts/screenshots.mjs launches the @vscode/test-electron-managed VSCode with the extension in development mode; a scene driver (scripts/screenshotScenes.cjs, injected via --extensionTestsPath) opens the example files, arranges the layout, and tweaks settings per scene; the window is then captured and trimmed with ImageMagick.

xvfb-run -a npm run screenshots   # Linux/CI (needs xvfb + imagemagick)
npm run screenshots               # macOS (visible window, uses screencapture)

Press F5 to launch the Extension Development Host with the examples/ folder open — one demo.* file per language (TypeScript, JavaScript, Python, Go, Rust, Java, C++, C#, Swift, Ruby, Shell, SQL, HTML, CSS, YAML), each using its own comment syntax. They double as manual test fixtures and as material for marketplace screenshots.

The tsserver plugin builds to dist/ts-plugin/ (what the vsix ships) and is also copied to node_modules/vscode-mark-highlight-ts-plugin/ — the only location tsserver loads plugins from. The build does this copy for the F5 dev host; in an installed extension the activation code does it (and restarts the TS server once when it had to). After changing src/tsPlugin/, rebuild and run TypeScript: Restart TS Server in the dev host — the plugin is loaded once at server start.
