Tablify

A VS Code extension that opens JSON, YAML and CSV files as an interactive, filterable table.

https://github.com/user-attachments/assets/f11cfb34-4c39-4f40-9068-d628a83d4668

Supported files

Tablify reads .json, .yaml and .yml files whose top level is either a list of entries or a hash of ID → entry:

[
  { "id": "REQ-001", "type": "requirement", "status": "valid" },
  { "id": "REQ-002", "type": "requirement", "status": "draft" }
]

{
  "REQ-001": { "type": "requirement", "status": "valid" },
  "REQ-002": { "type": "requirement", "status": "draft" }
}

The same two shapes work in YAML:

- id: REQ-001          # list
  status: valid

REQ-001:               # hash: the key becomes the `id` column
  status: valid

Any other shape shows a "Not a table file" message with an Open as Text button.

CSV and TSV files (.csv, .tsv) are read as a list: the first line names the columns, every other line is an entry.

id,status,tags
REQ-001,valid,"Functional, Security"

• Delimiter: comma, semicolon, tab or |, detected from the header line.
• Quoting: quoted fields may contain delimiters, "" and line breaks.
• Values: all values are text. Empty fields count as missing, like a missing field in JSON. Comma-separated values work with multienum attributes.
• Editing: an edit rewrites only the changed field, quoted when needed. Line endings and a byte order mark are kept.

Usage

• Right-click a file in the Explorer and choose Open as Table, or use the table icon in the editor title bar. The command palette has Tablify: Open as Table as well.

• Open as Text in the title bar switches back to the text editor.

• To always open a file pattern as a table, add an editor association:

  "workbench.editorAssociations": { "**/requirements/*.yaml": "tablify.tableView" }


The table updates live while you edit the file in a text editor next to it. Cmd/Ctrl+click a cell, or right-click a row and choose Reveal in Text Editor, to jump to its entry in the source.

Editing

Double-click a cell to edit it. Changes are written to the file as minimal text edits, so comments, formatting and quoting elsewhere stay as they are; the file becomes dirty and is saved, undone and redone like any other edit.

Without attribute definitions the editor is chosen from the data: numbers, booleans, lists, HTML, long text and short text. Values keep their representation where possible: a comma-separated multienum string stays a string, and in YAML, strings such as yes are quoted so YAML 1.1 tools still read them as strings. Images in HTML keep their relative paths.

Some cells are read-only: the key of a hash entry, nested objects, and rows that are not objects.

Filtering

Press Cmd/Ctrl+F in the table, or click the filter icon in the editor title bar, to open the filter box at the top right. It filters as you type and suggests field names and known values (Tab/Enter accepts). Escape closes the box but keeps the filter: the filtered columns stay highlighted, the title-bar icon switches to Clear Filter, and the status bar shows the active query and match count (click it to edit).

Clauses are joined with AND:

Clicking a column header adds a clause for that column. Columns with few distinct values open a dropdown of those values. Unfinished clauses such as status= are ignored until a value is typed.

Saved filters: the bookmark button in the filter box lists the saved filters of the file's view; click one to apply it, or × to delete it. Save Current Filter… (also Tablify: Save Filter… in the editor's … menu) asks for a name and stores the query in the view's filters in .vscode/tablify.yaml. Saving under an existing name replaces that filter. Without a matching view, you choose a new view for this file or folder, as with Save View. The bookmark is filled while the current query is a saved filter.

Display

Without attribute definitions, each field becomes a column in the order the fields first appear. Long text wraps, lists are comma-separated, and nested objects show as JSON. String values wrapped in <html>…</html> are rendered as sanitized HTML. Relative image paths resolve against the file's folder.

Workspace configuration and views

Tablify is configured per workspace folder in .vscode/tablify.yaml (.yml and .json work too). It holds a list of views; each applies to the data files matched by its files globs (relative to the workspace folder; patterns without / match the file name anywhere). The first matching view is used, so put specific views before broad ones. Without a matching view, every field is shown as plain text in data order. The table updates when the file changes. See test_data/.vscode/tablify.yaml for a full example.

views:
  - name: Requirements
    files: ["requirements/**/*.yaml"]
    columns: [id, type, status, text]   # column order
    hiddenColumns: [internal_note]      # not shown (still filterable)
    otherColumns: show                  # show | hide fields that are not in `columns`
    widths: { id: 90, text: 420 }
    readonlyColumns: [created]          # not editable in the table
    filters:                            # saved filters, offered in the filter bar
      - { name: Open, query: "status=draft" }
    attributes:                         # how fields are displayed, edited and filtered
      id: { type: string, readonly: true }
      title: string                     # shorthand: just the type
      status:
        type: enum
        label: Status                   # column title
        description: Lifecycle state    # header tooltip
        values:
          - draft                       # shorthand: just the value
          - { value: valid, label: Valid, color: green, description: Approved }

Running a command on save

onSave runs a shell command after a file of the view is saved while it is open as a table (from the table or a text editor), for example a formatter:

views:
  - files: ["requirements/**/*.yaml"]
    onSave: npx prettier --write ${file}

Placeholders are replaced with shell-quoted values: ${file} (absolute path), ${relativeFile}, ${fileDirname} and ${workspaceFolder}. The command runs in the workspace folder and is stopped after 30 seconds. Its output (stdout and stderr) is shown as a notification, as an error when the command fails or times out; the full output is in the Tablify output channel. If it rewrites the file, the table reloads. On-save commands only run in trusted workspaces.

Arranging and saving a view

• Drag a column header to move the column.
• Right-click a header for Hide column, Show column › (lists hidden columns), Save View… and Reset View.
• Resize columns by dragging the header edge.

Changes are kept in the editor tab until you save them. While there are unsaved changes, a Save View icon appears in the editor title bar (also in its … menu, with Reset View). Saving writes columns, hiddenColumns, otherColumns and widths to .vscode/tablify.yaml: into the view that matches the file, or into a new view for this file, this folder, or this folder and its subfolders. A new view is placed first, so it takes precedence. The config file is created if needed; comments in it are kept.

Attribute types

Attribute properties: type (required), label, description, readonly (not editable in the table), and values for enum / multienum. Value properties: value (required), label, color (gray, blue, green, yellow, orange, red, purple), description.

Values that are not in an enum's values (or booleans that cannot be read as true/false) are marked with a dashed red outline. An invalid config file shows a warning, and the table falls back to the generic display. VS Code validates and autocompletes .vscode/tablify.yaml through the bundled JSON schema (YAML needs the Red Hat YAML extension).

Scroll position and the filter are kept per editor tab.

Saving

Ctrl/Cmd+S in the table view runs Save without Formatting. A format-on-save formatter (e.g. Prettier) would otherwise reformat the whole file and change entries you did not touch; the table's own edits only change what you edited. Turn this off with tablify.saveWithoutFormatting. Saving through the File menu, Save All, or the prompt when closing still runs the formatter.

Adding, deleting and moving rows

Rows are managed from the narrow baseline column at the left of the table:

• Hover it to show a small toolbar: add row above, add row below, delete row.
• Drag it (the grip appears on hover) to move a row; it is placed next to the row you drop it on.

New rows get a short random ID (8 characters, e.g. k7f3x9qa), unique in the file, and nothing else; in a hash the ID is the key (k7f3x9qa: {}, which becomes a regular block when you fill in the first field). As with cell edits, changes are minimal text edits: in YAML whole entries move, including comments inside them, and every action is a single undo step. Rows of flow-style YAML collections ([...], {...}) cannot be added, deleted or moved, and the last entry of a YAML file cannot be deleted from the table.

Git changes and blame

For files tracked by git, the baseline column shows what changed since the last commit, like the change markers in the editor gutter: green for entries that are new, blue for entries that were modified. Changed cells get a small corner mark. Entries are compared by ID (or hash key) and value, not by line, so reformatting the file does not show up as a change. Unsaved edits are included.

Click the baseline of any row to see its history: for each field the current value, the previous value if it changed, and git blame (author, date and commit) for the field's lines. Blame is loaded only when you open the popup, and includes unsaved changes. The data refreshes after commits, checkouts and similar git operations.

Click the header of the baseline column to show only the changes since the last commit: new and modified entries, plus entries that were deleted (red bar, struck through, shown where they used to be; read-only). It combines with the filter query and is kept per editor tab; click the header again, or Clear Filter, to show all rows.

Settings

Development

npm install
npm run build      # bundle extension + webview into dist/
npm run watch      # rebuild on change
npm run check      # type-check
npm test           # parser unit tests (Node >= 22.18)
npm run package    # build a .vsix

Press F5 in VS Code to start an Extension Development Host with test_data/ open.

Layout:

• src/ runs in the extension host: the custom editor provider, the JSON/YAML parser and the webview HTML with its CSP.
• webview/ runs in the webview: the Tabulator table, formatters and filter.
• test/ holds the parser tests, which use the files in test_data/.

License

MIT
