SSH Relay Guard (SRG)

SSH Relay Guard is an Antigravity extension that manages SSH reverse tunnels and transparently routes remote traffic through your local proxy — bypassing network restrictions and DNS pollution on remote servers.

GitHub: double12gzh/ssh-relay-guard

Features

• 🔒 SSH Reverse Tunnel — Automatically configures ~/.ssh/config.srg with per-host RemoteForward and ControlMaster blocks.
• 🛡️ Language Server Proxy — Wraps the remote language server binary with mgraftcp-fakedns for transparent process-level proxy, bypassing DNS pollution.
• 📊 Status Dashboard — Real-time panel showing local/remote proxy health, SSH tunnel state, and connection metrics.
• 🔍 Health Check — Full diagnostic suite: local proxy, SSH config, remote port forwarding, binary check, external connectivity, and DNS pollution detection.
• 📈 Traffic Monitor — Live connection count and session statistics on the remote side.
• 🌐 Bilingual UI — Chinese and English support.

How It Works

1. On the local machine: the extension writes an SSH config block in ~/.ssh/config.srg that forwards the remote proxy port back to your local proxy.
2. On the remote machine: the extension installs a wrapper script around the language server binary that forces it through mgraftcp-fakedns.

📖 Manual Reproduction Guide — Explains the minimal commands needed to manually replicate what the extension does, with a full data flow diagram.

Installation

SRG uses a local + remote dual deployment model, with each side handling different tasks:

Environment Requirements

• A running local proxy (Clash / V2Ray / etc.) with working Antigravity AI features confirmed locally
• A remote Linux x86_64 server accessible via SSH

Quick Start

Local side

1. Search for and install SSH Relay Guard in the Antigravity extension marketplace
2. Open settings and set localProxyPort to your local proxy port (default 7890)
3. Run command SSH Relay Guard: Add Host Forwarding and enter the remote hostname (as in ~/.ssh/config)

Remote side

4. Connect to your remote server via SSH through Antigravity
5. Install SSH Relay Guard again in the remote extension list
6. Restart the remote window when prompted (may require multiple restarts)

Verify

7. Open the SRG Dashboard → Run "Health Check" → All items showing ✅ means setup is complete

Configuration

Commands

srg-cli (Optional, Standalone Tool)

srg-cli is NOT bundled with the extension. It is a standalone command-line tool for users who don't use Antigravity or need to manage multiple remote hosts from the terminal.

If you only use Antigravity, you do NOT need srg-cli — the extension handles everything automatically via the Setup Remote Environment command.

Installation

# Clone the repository
git clone https://github.com/double12gzh/ssh-relay-guard.git
cd ssh-relay-guard/srg-cli

# (Optional) Build mgraftcp-fakedns pre-compiled binaries
# Requires Linux + go, make, gcc
bash build-bin.sh

# Add srg to PATH
export PATH="$PWD:$PATH"
# Or create a symlink
ln -s "$PWD/srg" /usr/local/bin/srg

Usage

# One-time setup for a remote host
srg setup my-server

# Check status
srg status my-server

# Diagnose issues (full local + remote diagnostics)
srg doctor my-server

# List configured hosts
srg list

# Remove all configuration
srg teardown my-server

Plugin vs srg-cli

Remote Commands (available after setup)

SSH Config Format

SRG uses a dedicated ~/.ssh/config.srg file included from the main SSH config:

# SSH Relay Guard — Tunnel & Proxy Config
# --- SRG:my-server ---
Host my-server
    RemoteForward 7890 127.0.0.1:7890
    ExitOnForwardFailure no
    ControlMaster auto
    ControlPath ~/.ssh/sockets/%r@%h-%p
    ControlPersist 4h
# --- SRG:my-server END ---

Uninstall

When uninstalling, the extension automatically cleans up local SSH configuration (~/.ssh/config.srg and the Include line in ~/.ssh/config). No manual rollback is needed.

Remote artifacts (LS wrapper, ~/bin/srg-* tools) are safe to leave — the LS wrapper has a built-in fallback that runs the original binary if mgraftcp is missing. To fully clean up the remote server, run SSH Relay Guard: Rollback Remote Environment before uninstalling.

Development

1. Setup Environment

git clone https://github.com/double12gzh/ssh-relay-guard.git
cd ssh-relay-guard
npm install

2. Local Debugging

To test and debug the extension locally:

1. Open this project in VS Code / Antigravity.
2. Press F5 to launch a new "Extension Development Host" window.
3. Make changes to the source code.
4. Run Developer: Reload Window (Cmd+R or Ctrl+R) in the debug host to immediately apply changes.

3. Code Quality & Testing

This project integrates ESLint (with strict TypeScript rules) and Prettier for formatting. A husky pre-commit hook ensures code quality before every commit.

# Format codebase (Prettier)
npm run format

# Run linting and autofix (ESLint)
npm run lint -- --fix

# Run all unit tests (100% coverage)
npm run test

4. Build & Publish

# Compile and actively watch for changes
npm run watch

# Package the extension into a .vsix file (for manual installation)
npx vsce package --no-dependencies

# Publish (Normally handled by GitHub Actions automatically on new v* tags)
npx vsce publish

License

MIT © double12gzh
