UXP Debugger – VS Code Extension

#StandWithUkraine 🇺🇦

Load, reload and debug Adobe UXP plugins and scripts (Photoshop, InDesign, Premiere Pro, Media Encoder, After Effects) directly from VS Code — with full source-map support and no Adobe UXP Developer Tools (UDT) required.

The extension hosts its own UDT-compatible service broker inside VS Code and announces it to Adobe applications over Vulcan IPC. Host applications connect straight to VS Code, which then loads your plugin and tunnels the Chrome DevTools Protocol to the built-in JS debugger.

Debugging a plugin
UXP Debugger running in VS Code with a plugin paused at a breakpoint
Inspecting a plugin user interface
Inspecting a UXP plugin interface with the built-in HTML and CSS inspector

Video tutorial

UXP Debugger video tutorial

Watch on YouTube: https://www.youtube.com/watch?v=_f5EdNuN7YQ


Requirements

  • VS Code 1.99 or newer (desktop; Windows x64, macOS x64, or macOS Apple silicon)
  • An Adobe host application with UXP support: Photoshop 23.2+, InDesign 18.5+, Premiere Pro 25.6+, Media Encoder 27.0+, or After Effects 27.1+
  • Adobe UXP Developer Tools app is NOT needed — close it if it is running (it occupies port 14001)
  • Administrator rights once, to enable Adobe's machine-global developer mode (see below)

Getting started

  1. Install the extension from the VS Code Marketplace (search for UXP Debugger).
  2. Open your plugin project and open its manifest.json in the editor.
  3. Open the UXP Devtools panel (Activity Bar) and use Add Plugin (or Add active manifest, using the file open in the editor).
  4. Start your Adobe application (e.g. Photoshop).
  5. Run UXP: Load Plugin.
  6. On first use the extension checks the machine-global developer mode flag. If it is missing you get a consent dialog followed by an OS elevation prompt same as UDT does. So if you used UDT before you will never see that dialog.
  7. Click Debug for the plugin in the UXP Devtools panel and set breakpoints.

Tip: clicking Debug for an unloaded plugin offers "Load and attach" — steps 5 and 6 in one go.


Control panel (sidebar)

The UXP Devtools icon in the Activity Bar opens a sidebar panel — the UDT-style home for day-to-day app launch, plugin and script registration, lifecycle actions, debugging, inspection, Watch, and packaging. Its global registry is independent of the current workspace, and every Command Palette entry below remains available. See Control Panel for the complete behavior and App Discovery and Launch for host status and startup.

UXP Devtools control panel showing connected apps, plugins, and scripts

GitHub Copilot and agent tools

The extension contributes VS Code language-model tools so compatible agents can discover, operate, and inspect UXP development sessions. Start with uxp_get_debug_state; see Language Model Tools for the complete tool reference, confirmation policy, and workflows.

Build-tool hooks

Build pipelines can trigger load, unload, refresh, full reload, watch, and pack operations through localhost HTTP hooks on the broker's existing port. See Build-Tool REST Hooks for endpoints and examples.

Documentation

  • Architecture and implementation record — system boundaries, protocol, decisions, measured evidence, constraints, and error model.
  • App discovery and launch — startup, Developer Mode, broker states, installation detection, and manual host launch.
  • Control panel — sidebar UI, registry, actions, Watch, persistence, webview protocol, and tests.
  • Break on start — debugger handshake, script timing limits, diagnostics, and rejected approaches.
  • HTML/CSS inspector — DevTools frontend, CDP multiplexing, safety, and lifecycle.
  • Multi-window takeover — exclusive broker ownership and handoff protocol.
  • Build-tool REST hooks and Language Model Tools — external build and agent entry points.

Commands

Command What it does
UXP: Load Plugin Validates and loads a registered plugin into one selected compatible app
UXP: Load Plugin (Break on Start) Loads a plugin and pauses it until the debugger attaches
UXP: Unload Plugin Unloads a live plugin session
UXP: Reload Plugin Reloads a live session (an attached debugger survives the reload)
UXP: Inspect Plugin UI (HTML/CSS) Opens the DevTools Elements panel (DOM + CSS) for a live plugin session
UXP: Debug Current Script Runs + debugs the .ccjs / .psjs / .idjs / .js / .ts file in the active editor
UXP: Pack Plugin… Packages a registered plugin as a .ccx archive
UXP: Enable Developer Mode Writes Adobe's developer-mode flag (consent + elevation)
UXP: Start UXP Devtools Starts the built-in broker
UXP: Stop UXP Devtools Stops the built-in broker
UXP: Enable Compact View Switches the panel to its compact layout
UXP: Disable Compact View Restores the full panel layout

launch.json (optional)

Attach to a plugin with F5:

{
  "type": "uxp",
  "request": "attach",
  "name": "Attach to UXP Plugin",
  "manifestPath": "${workspaceFolder}/manifest.json"
}

Run + debug a script:

{
  "type": "uxp-script",
  "request": "launch",
  "name": "Debug UXP Script",
  "script": "${file}",
  "app": "PS",
  "userArgs": [1920, 1080, { "keepRatio": true }]
}

app is optional and restricts execution to one host app id (PS, ID, premierepro); without it you are asked to pick when several compatible apps are connected. The script's file extension always decides which apps are compatible (see Script debugging notes); app can only narrow that set. Use the Create launch.json configuration button on a plugin (… menu) or script row in the UXP Devtools panel to generate these entries with the known values filled in.


Script debugging notes

Supported extensions are .ccjs, .psjs, .idjs, .js, and .ts.

Target app selection. The file extension decides which host apps may run the script:

  • .js, .ts, and .ccjs run in any connected UXP host app.
  • .psjs runs only in Photoshop and .idjs only in InDesign.

The target (app in launch.json, appId in the uxp_debug_script tool, or the target-app selector in the panel) never overrides the extension. It only narrows the compatible apps further, so it is meaningful for .js, .ts, and .ccjs. A target that conflicts with the extension (e.g. .psjs with app: "ID") matches no app and is reported as "host app not running".

Script arguments are comma-separated JSON values or userArgs in launch.json. The panel workflow and .ts type-erasure limits are documented in Control Panel; the short-script attach race and workaround are documented in Break on start.

Source maps & breakpoints

Breakpoints in your original TypeScript/JavaScript sources work out of the box:

  • Inline and external source maps are both supported — your bundler can emit either an inline map (e.g. webpack devtool: "inline-source-map", esbuild/Vite sourcemap: "inline") or an external .map file next to the bundle referenced via //# sourceMappingURL=.
  • Unbundled plain .js and standalone .ts scripts work without a bundler — for scripts without a source map, the CDP proxy automatically synthesizes a 1:1 identity source map once it matches the runtime script to a file on disk; standalone .ts scripts are type-stripped in place with an inline identity map.
  • Automatic path resolution — when UXP parses a script, the CDP proxy resolves every sources entry against your plugin directory, up to 5 ancestor directories (stopping at .git), and their immediate subdirectories, rewriting matched sources to canonical file:/// URLs (and inlining external .map files) before handing the event to VS Code's JS debugger.

HTML/CSS inspector

UXP: Inspect Plugin UI (HTML/CSS) opens the bundled Chrome DevTools Elements panel for a live plugin session. See HTML/CSS Inspector for capabilities, limitations, CDP routing, lifecycle, and maintenance.


Troubleshooting

Symptom Cause Fix
"Port 14001 is already in use" Adobe UXP Developer Tools (or an old uxp service) is running Close it and hit Retry
"<App> is not running or not connected" Host app not started, or connected before the broker existed Start (or restart) the app, wait a few seconds, Retry
"Developer mode could not be enabled" Elevation prompt declined Run UXP: Enable Developer Mode again and accept the prompt
"Plugin load timed out" Host app busy or showing a modal dialog Dismiss dialogs in the app and Retry
"…is a sandboxed host application" UWP-style host (not supported yet) Use a non-sandboxed host app
Breakpoints not binding (hollow gray circle) Debugger not attached, stale build, missing source maps, or unresolved source paths Follow Why is my breakpoint not binding? below
"None of the connected applications report script-debugging support" Older UXP runtime Update the host app, or use Try anyway

The UXP Debugger output channel contains detailed diagnostics; each host app also gets its own UXP – <App> <version> log channel.

Why is my breakpoint not binding?

When a breakpoint stays hollow/gray ("Unbound breakpoint") or is never hit, work through the causes below from the simplest everyday oversights to the most complex source-map and timing issues:

  1. The debugger is not attached (or is attached to a different session)

    • Clicking Load (or running UXP: Load Plugin) only loads the plugin into the host app — it does not start a VS Code debug session. Click Debug on the plugin row in the UXP Devtools panel (or press F5 with a "type": "uxp" configuration) and confirm the VS Code debug toolbar is visible.
    • If you have multiple plugins or multiple Adobe host apps connected, verify in the Call Stack view (or the UXP Devtools panel) that the active debug session is attached to the plugin and host app you are actually interacting with.
  2. The breakpoint is on a non-executable line, or the build/plugin is stale

    • Breakpoints placed on TypeScript interface / type declarations, comments, blank lines, or dead code eliminated by tree-shaking have no generated JavaScript instructions to bind to. Try placing the breakpoint on a concrete statement (e.g. console.log(...)).
    • If you edited your source files without rebuilding, or rebuilt without refreshing the plugin, the running UXP session still has the old bundle. Rebuild your bundle and click Refresh / Reload (or enable Watch on the plugin row).
  3. The script or chunk has not been parsed by UXP yet

    • VS Code's JS debugger can only bind a breakpoint after UXP actually loads and parses the script containing that code (Debugger.scriptParsed).
    • If the file is never imported from your entry point, or lives in a lazy-loaded chunk (import()), a secondary HTML dialog/panel that has not been opened yet, or a Web Worker, the breakpoint will remain unbound until that code path is loaded at runtime.
  4. Top-level startup code already ran before the debugger attached (or a short script finished first)

    • Plugins: If your breakpoint is inside top-level initialization code that runs immediately when the plugin loads, attaching the debugger after a normal load is too late — that code has already executed. Check Break on load in the UXP Devtools panel header (or run UXP: Load Plugin (Break on Start)) and then click Debug so the runtime pauses before executing the bundle.

    • Standalone scripts (.js, .ts, .ccjs, .psjs, .idjs): Very short synchronous scripts can finish executing before VS Code finishes attaching and processing the source map. Add a short initial async pause at the top of the script while debugging:

      await new Promise((resolve) => setTimeout(resolve, 1500));


    See Break on start for the full startup handshake details.

  5. Your bundler is not emitting source maps (or uses eval devtool modes)

    • If your build pipeline transpiles TypeScript/JSX or bundles modules without emitting a source map, UXP only sees the compiled .js file and the debugger never learns about your original .ts / .tsx files.
    • Enable inline source maps (webpack: devtool: "inline-source-map", esbuild/Vite: sourcemap: "inline") or external .map files (webpack: devtool: "source-map", esbuild/Vite: sourcemap: true).
    • Avoid webpack's eval or eval-cheap-* modes — eval() strings do not carry a script-level sourceMapURL on Debugger.scriptParsed and lack accurate source mappings.
    • If you use external .map files, make sure your build copies the .js.map file into the deployed plugin folder right next to the .js bundle referenced by manifest.json.
  6. Inspect the UXP Debugger Output panel to see which source maps and files resolved on disk

    • Open VS Code's Output panel (Ctrl+Shift+U / Cmd+Shift+U) and select UXP Debugger from the channel dropdown.
    • Whenever a debug session starts or a script is parsed, the CDP proxy logs how each runtime script and its source-map sources entries were matched to local files on disk:
      • Script match:

        [CDP] Script: "uxp://..." → "file:///.../dist/index.js"


        Confirms the runtime script URL was matched to a local .js file in your plugin folder.

      • Missing or invalid source map:

        • [CDP] Source map not found: index.js.map — the bundle has a //# sourceMappingURL=... comment, but the .map file could not be found next to the script on disk.
        • [CDP] Failed to rewrite source map: ... — the inline or external source map could not be decoded or is not valid Source Map v3 JSON.
      • Which source files were found on disk and which were not:

        [CDP] Source: "webpack://my-plugin/./src/index.ts" → "file:///.../src/index.ts"
        [CDP] Resolved 12/14 source map sources on disk
        [CDP] Unresolved source: "../../shared/utils.ts"

        • [CDP] Source: "<raw>" → "file:///..." (logged for the first 5 resolved entries per map) shows the exact on-disk file:/// URI that the proxy mapped each source entry to.
        • [CDP] Resolved X/Y source map sources on disk tells you at a glance how many sources entries in the source map were found on disk versus the total count in the map.
        • [CDP] Unresolved source: "..." (up to 15 entries per map, followed by [CDP] ...and N more unresolved) explicitly lists every source-map entry that could not be located on disk.
  7. Complex path-resolution mismatches (out-of-tree staging folders, monorepos, symlinks, or custom bundler paths)

    • When the Output panel reports [CDP] Unresolved source for the file where you set your breakpoint — or resolves it to a different path than the editor tab you have open — check how the proxy searches for source files:
      • Out-of-tree build / staging copy: The proxy searches for source files starting from the script's directory and walks up to 5 ancestor directories (stopping at the .git repository root, your home directory, or the OS temp directory) plus their immediate subdirectories. If your build copies the plugin (manifest.json + bundle) into a completely separate directory outside your repository (e.g. a distant staging folder or >5 directory levels deep), walking up from the loaded manifest.json will never reach your src/ folder. Fix: Load the manifest.json located inside your repository (or emit inline source maps whose sourceRoot / paths resolve within the repo tree).
      • Breakpoint set in a duplicate file or symlinked path: Compare the file:///... target printed in [CDP] Source: ... → "file:///..." with the full path of the file open in your VS Code editor. In monorepos or projects that copy sources into a build folder, the source map may resolve to a copied file or a real path while your breakpoint was set in a symlinked path (or vice versa). Open and set the breakpoint in the resolved path, or adjust your bundler's sourceRoot so sources point to the canonical src/ directory.
      • Custom devtoolModuleFilenameTemplate / virtual bundler URLs: If your bundler rewrites source paths into custom virtual URLs that do not correspond to relative paths on disk, adjust your bundler's source-map configuration so sources contain standard relative paths from the output bundle back to src/.

Known issues

Host app startup can hang while the broker is running

Tracked in #15 (needs more info).

Starting an Adobe host application (e.g. Photoshop) while the broker is already running — whether launched from the control panel or manually — can leave the app stuck on its startup screen. The control panel still shows the app as connected (the App/info handshake completes), but the app never finishes loading. Stopping the broker lets the startup finish; the broker can be started again right after and everything works normally.

This is host-side behavior: a UXP app that finds a developer-tools service announced during its own startup connects to it and blocks on that connection. Adobe's own UXP Developer Tools trigger the exact same hang when left running, so there is nothing the extension sends (or could stop sending) to avoid it.

The exact steps to reproduce the issue are not known

Workarounds:

  • Start the host app before starting the broker (or before opening the workspace that auto-starts it), then load the plugin.
  • If the app is already stuck, run UXP: Stop UXP Devtools (also available from the control panel title bar), wait for the app to finish loading, then run UXP: Start UXP Devtools again. Or click button in UI to disable/enable devtools.
  • Or restart computer

InDesign crashes when typing in the Debug Console while paused

Tracked in #6 (needs an Adobe fix).

While paused on a breakpoint, typing an InDesign DOM expression (e.g. app.) into the VS Code Debug Console can crash InDesign (reproduced on 21.5.1, 21.6.0, on Windows and macOS; affects both scripts and plugins). To offer completions the console reads every property of the object's prototype, including getters, and InDesign crashes on some of those reads. Adobe's UXP Developer Tools don't do this, so they don't trigger it while typing. The same crash happens in UDT, in the VS Code debugger and when run directly in InDesign:

const { app } = require("indesign");
for (const name of Object.getOwnPropertyNames(app.__proto__)) {
 app.__proto__[name]; // eventually crashes InDesign
}

Photoshop is not affected. Plain script variables can be evaluated safely.

Workarounds:

  • Avoid typing DOM expressions into the Debug Console while debugging InDesign; use breakpoints and the Variables view instead.
  • Use console.log or logpoints to inspect DOM values.

Host app exists at the same time as VS Code

  • If you start host application e.g. Photoshop via UXP debugger those two processes are coupled together. So host app is subprocess of VS Code. And when quit VS Code it takes down host app with it.

Workaround:

  • Start application manually outside of the VS Code

Feedback & issues

Source code, bug reports and feature requests: github.com/jardicc/vscode-uxp-debugger (issues). When reporting a problem, please attach the relevant part of the UXP Debugger output channel.


How it works

UXP Debugger architecture

  1. Developer mode — host apps only join dev workflows when Adobe's machine-global settings.json contains {"developer": true} (one-time elevated write, with your consent).
  2. Broker — the extension runs a WebSocket server on 127.0.0.1:14001 speaking the UXP DevTools wire protocol and announces it via the Adobe Vulcan IPC native library (shipped per platform). Running Adobe apps connect within about a second.
  3. Plugin sessions — local manifest validation followed by Plugin/load creates a session; reload/unload operate on it. Scripts use Plugin/runScript and behave like short-lived plugin sessions.
  4. Debugging — a lightweight CDP proxy bridges VS Code's built-in JS debugger (pwa-node attach) to the broker's /socket/cdt/<session> endpoint, translating UXP protocol quirks (source-map roots, Runtime.evaluate contexts, NodeWorker.enable, reload grace periods).

Project structure

src/
  core/                    Pure Node (no vscode imports) — unit-tested
    protocol/              Wire-protocol types, frame builders, type guards
    broker/                WS broker, app connections, sessions, CDT tunnel
    vulcan/                Native Vulcan addon loading, port announcer, host-app catalog
    devmode/               Developer-mode flag detection
    manifest/              Manifest parsing + app matching
    pack/                  .ccx packaging
    stripTypeScript.ts     Type erasure for .ts scripts (ts-blank-space)
  vscode/                  VS Code layer
    UxpService.ts          Facade: broker lifecycle + fan-out operations
    commands/              One module per command
    debug/                 Debug config providers + session manager
    hooks/                 Local HTTP hooks for build-tool integration
    inspector/             Bundled Chrome DevTools Elements panel
    panel/                 Control-panel sidebar (React webview + controller)
    proxy/                 CDP proxy (transport, message rewriting, source maps)
    tools/                 Language-model tools for agent-driven workflows
    ui/                    Dialogs, pickers, output channels
native/                    Vulcan prebuilds per platform (generated: npm run prepare-native)
devtools-frontend-dist/    Bundled Chrome DevTools frontend for the HTML/CSS inspector
scripts/                   Build helpers (native prebuilds, DevTools bundle, per-platform VSIX)
test/                      vitest suite incl. a scripted fake host app
e2e/                       Real-VS Code harness (@vscode/test-electron), optional live Photoshop
docs/                      Architecture and feature documentation

Development

npm install
npm run prepare-native   # extract Vulcan prebuilds into native/
npm test                 # vitest unit/integration suite (no Adobe app needed)
npm run typecheck        # TypeScript checks without emitting
npm run lint             # ESLint for src/, test/, and e2e/
npm run compile          # esbuild bundle (extension, panel, inspector, DevTools frontend)
npm run test:e2e         # real VS Code instance; set UXP_E2E_PHOTOSHOP=1 for live Photoshop tests
npm run build            # per-platform VSIX packages (win32-x64, darwin-x64, darwin-arm64)

License

MIT. Third-party components and their licenses are listed in ThirdPartyNotices.txt.

  • Contact us
  • Jobs
  • Privacy
  • Manage cookies
  • Terms of use
  • Trademarks
  • Your Privacy Choices
  • Consumer Health Privacy
© 2026 Microsoft
