Realm Explorer for VS Code

Inspect and query local Realm database files directly within VS Code with a powerful, modern UI.

Features

🗂️ Schema Explorer

• View all object types in your Realm database
• Expand object types to see their properties and types
• Quick refresh to reload schema changes

🔍 Advanced Query Interface

• Visual Filter Builder: Create filters using a user-friendly interface
  • Multiple filter conditions with AND/OR logic
  • Support for all comparison operators (equals, greater than, contains, etc.)
  • Field selection with auto-complete
• Raw RQL Mode: Write Realm Query Language queries directly for advanced filtering
• Tabbed Interface: Switch between visual and RQL modes seamlessly

📊 Query Execution

• Run Query: Execute queries and view paginated results
• Count Only: Get record counts without fetching data (faster for large datasets)
• Smart Pagination: Navigate through large result sets with page controls
• Configurable Page Size: Choose between 20, 50, 100, or 500 records per page

📈 Results Display

• Sortable Columns: Click column headers to sort results ascending/descending
• Rich Table View: Clean, responsive table with proper VSCode theme integration
• Object Rendering: Nested objects displayed as formatted JSON
• Null Handling: Clear indication of null values
• Performance Metrics: View execution time and record counts

💾 Data Export

• Export query results to JSON files
• Includes all fetched records with proper formatting
• Timestamped filenames for easy organization

🎨 Modern UI

• Native VSCode theme integration (dark/light mode support)
• Responsive design that adapts to different panel sizes
• Loading states and error handling
• Status bar with real-time query statistics
• Badge showing total record count

Usage

1. Click on the Realm icon in the Activity Bar (sidebar)
2. Click the Open Realm File button (folder icon) in the Schema Explorer title bar
3. Select a .realm file from your workspace
4. Explore the schema:
   • Expand object types to view their properties
   • See property types and optionality
5. Query your data:
   • Click the Run Realm Query button (play icon) or use the command palette
   • Choose an object type from the dropdown

Visual Filter Builder

1. Select the "Visual Filter" tab
2. Choose a field from the dropdown
3. Select an operator (equals, contains, greater than, etc.)
4. Enter a value
5. Click "+ Add" to add more conditions with AND/OR logic
6. Click "▶ Run Query" to execute

Raw RQL Mode

1. Select the "Raw RQL" tab
2. Write your filter expression (e.g., age > 20 AND name BEGINSWITH 'J')
3. Click "▶ Run Query" to execute

Additional Features

• # Count Only: Get quick count without fetching data
• Clear Results: Reset the results view
• 📥 Export JSON: Save results to a JSON file
• Pagination Controls: Navigate with Previous/Next buttons or jump to a specific page
• Sort Results: Click any column header to sort

Requirements

• This extension uses the realm Node.js package which contains native modules
• Compatible with macOS, Windows, and Linux
• VS Code version 1.80.0 or higher

Extension Commands

• Realm: Open Realm File - Open a Realm database file
• Realm: Run Query - Open the query explorer panel
• Realm: Refresh Schema - Reload the schema tree view

Tips

• Use the Count Only feature for quick data exploration without loading full result sets
• The visual filter builder automatically quotes string values
• Export functionality saves only the current page of results - adjust page size before exporting
• Sorting is performed client-side on the current page of results
• For complex queries, switch to Raw RQL mode for full Realm Query Language support

Known Limitations

• Export saves only currently loaded page (not all matching records)
• Client-side sorting applies to current page only
• Very large objects may render slowly in the table view

Future Enhancements

• Virtual scrolling for large result sets
• Server-side sorting
• Export all matching records (not just current page)
• Query history and saved queries
• Data editing capabilities
• Schema comparison between Realm files

Keyboard Shortcuts

• Cmd/Ctrl + Enter in filter textarea: Execute query (coming soon)

Support

For issues, feature requests, or contributions, please visit the GitHub repository.

Enjoy exploring your Realm databases! 🗄️✨
