DevMirror - Browser Console Capture Extension

Capture browser console output using Chrome DevTools Protocol

DevMirror is a VS Code extension that captures browser console output to timestamped log files using Chrome DevTools Protocol (CDP) or Adobe CEF debugging.

Current Features (v0.4.82)

• Multiple Instance Support - Run DevMirror in multiple projects simultaneously without conflicts
• Per-Project Chrome Profiles - Each project gets its own isolated Chrome profile
• Complete Error Context - All errors now include file name, line and column numbers
• Configurable Debug Logging - Advanced CDP protocol debugging for troubleshooting
• Complete Console Capture - Logs all console messages with formatted arrays/objects as foldable JSON
• Enhanced Formatting - Arrays and objects display as multi-line, indented JSON for better readability
• Console.table() Support - Displays as formatted ASCII tables with all object properties as columns
• Dual Mode Support - Works with regular Chrome (CDP) and Adobe CEF extensions
• Smart Dynamic Paths - Shim-based CLI resolution survives extension updates
• DevMirror Scripts Panel - Visual tree view in Explorer sidebar showing all package.json scripts
• One-Click Setup - Add mirror scripts instantly with the (+) button
• Startup Wizard - Advanced configuration interface with magic wand icon
• Auto Port Detection - Automatically finds running dev server ports
• Live Status Bar - Shows active capture with log count and duration
• Real-time Updates - Log files update as new content arrives
• Stack Traces - Full JavaScript stack traces for errors and console messages
• Network Error Tracking - Captures failed network requests with details
• Intelligent Filtering - Excludes cache directories and temporary files

Installation

1. Install DevMirror from VS Code Marketplace
2. Open your project in VS Code
3. Use the DevMirror Scripts panel or Command Palette to set up

Quick Start

Option 1: Visual Setup (Recommended)

1. Look for DevMirror Scripts panel in Explorer sidebar
2. Click + button next to any script for instant setup
3. Or click the magic wand icon for the Startup Wizard
4. Run your new :mirror script

Option 2: Command Palette

# Run in VS Code (Cmd/Ctrl+Shift+P)
DevMirror: Setup Project

This creates devmirror.config.json in your project root.

Running DevMirror

After setup, use the generated mirror scripts:

# Instead of:
npm run dev

# Use:
npm run dev:mirror

Logs are written to ./devmirror-logs/ folder with timestamps.

Configuration

Basic Configuration (devmirror.config.json)

{
  "outputDir": "./devmirror-logs",
  "mode": "cdp",
  "url": "http://localhost:3000"
}

Adobe CEF Mode

{
  "mode": "cef",
  "cefPort": 8860,
  "outputDir": "./devmirror-logs",
  "autoOpenBrowser": true
}

Configuration Options

Debug Configuration

DevMirror includes powerful debug logging to help diagnose CDP protocol issues. Add to devmirror.config.json:

{
  "outputDir": "./devmirror-logs",
  "mode": "cdp",
  "url": "http://localhost:3000",
  "debug": {
    "enabled": true,
    "logExceptions": true,     // Log raw Runtime.exceptionThrown events
    "logConsoleAPI": true,      // Log raw Runtime.consoleAPICalled events
    "logLogEntries": true,      // Log raw Log.entryAdded events
    "logRawCDP": false,         // Log ALL CDP traffic (verbose!)
    "logToFile": true,          // Write debug to current.log file
    "logToConsole": false       // Output to terminal (default: true)
  }
}

Debug Options:

• enabled: Master switch for debug logging
• logExceptions: Capture raw exception data from CDP
• logConsoleAPI: Capture raw console API calls
• logLogEntries: Capture browser log entries
• logRawCDP: Log ALL CDP protocol traffic (very verbose)
• logToFile: Save debug output to current.log
• logToConsole: Show debug in terminal where DevMirror runs

Debug messages are prefixed with [DEVMIRROR:] to distinguish from application debug output.

Log Output Format

[250924T14:30:52.12] [LOG] Application started
[250924T14:30:52.13] [ERROR] Failed to load resource
    at fetchData (app.js:45:12)
    at initialize (app.js:23:8)
[250924T14:30:52.14] [WARN] Using deprecated API
[250924T14:30:52.15] [INFO] User logged in successfully
[250924T14:30:52.16] [LIFECYCLE] ════════════ Page Navigated ════════════
[250924T14:30:52.17] [LIFECYCLE] ════════════ Page Loaded ════════════

Format: [yymmddThh:mm:ss.ms] [TYPE] message

• Timestamp: YYMMDDThhmmss.ms (2-digit milliseconds)
• Types: LOG, ERROR, WARN, INFO, DEBUG, LIFECYCLE, etc.

VS Code Commands

Status Bar

• Idle: DevMirror (click to activate)
• Active: DevMirror Active | projectName.root | 234 logs | 5m 32s

Click status bar to open logs directory.

DevMirror Scripts Panel

The Scripts panel in Explorer shows:

• Root package.json as projectName.root
• All npm scripts with mirror capability
• Quick add (+) button for instant setup
• Magic wand icon for Startup Wizard

Scripts are automatically updated with dynamic CLI paths that survive extension updates.

File Structure

./devmirror-logs/
  ├── 2025-09-24-143052.log  # Timestamped log files
  └── current.log             # Symlink to active log

devmirror.config.json         # Project configuration

Dynamic Path Resolution

DevMirror uses a stable shim pattern that ensures scripts continue working after extension updates:

• Creates .vscode/devmirror/cli.js (or .cjs for ESM packages) in your workspace
• Shim reads the current extension path from a config file
• Package.json scripts use relative paths to the shim
• Supports both single-repo and monorepo setups

Requirements

• VS Code 1.104.0+
• Node.js 16+
• Chrome or Chromium browser

Troubleshooting

Scripts Break After Extension Update

The extension now auto-updates paths. If you have old scripts, remove and re-add them using the Scripts panel.

Multiple Dev Servers

For projects with multiple servers (e.g., app + docs), explicitly set the url in devmirror.config.json to target the correct one.

CEF Not Connecting

1. Enable debugging in your Adobe application
2. Check the .debug file for the port number
3. Set cefPort in devmirror.config.json

No Logs Appearing

Ensure Chrome/Chromium is installed and the target URL is accessible.

Support

Report issues: https://github.com/ivg-design/devMirror/issues

License

MIT

© 2025 IVG Design
