IFS Projection Resolver

ℹ️ LEGAL DISCLAIMER This tool was developed independently using exclusively publicly available information, standard HTTP/REST protocols, and OpenAPI specifications. It is not officially affiliated with, endorsed by, or created by IFS.

Why use this tool instead of the manual IFS Projection Explorer? Finding the right APIs in IFS Cloud manually can be tedious. The native Projection Explorer requires you to know exactly what you are looking for and involves a lot of clicking to inspect metadata. This tool drastically speeds up your workflow by providing:

• Fuzzy & Broad Search: Instantly search across Projection names, View names, Table names, Entities, and descriptions all at once.
• Offline & Local Capabilities: Scan your local IFS source checkout (.projection / .views files) in milliseconds without needing a running IFS Cloud instance.
• Automated OpenAPI Resolution: Automatically verify if a projection is active and fetch its OpenAPI specification directly into your IDE.
• Context-Aware Mapping: Seamlessly integrate custom mapping hint files (like DATEV mapping matrices) to immediately see which API endpoints are relevant for your specific integration use cases.
• No Context Switching: Stay entirely within VS Code to find your APIs, copy the JSON results, and continue coding.

This is the generic resolver for IFS Cloud projections. It supports two resolver modes:

• Local mode: scans a local IFS Cloud source checkout for .projection and .views files.
• Live mode: queries an IFS Cloud environment through Projection Explorer and, optionally, OpenAPI metadata.

Run one of these VS Code commands to get started:

• INNEX IFS Projection Resolver: Open Search UI
• INNEX IFS Projection Resolver: Quick Search
• INNEX IFS Projection Resolver: Show Output

Quick search guide

For a fast, broad overview, enter one short domain term such as customer, supplier, voucher, invoice, account, or payment. Do not use *, an empty query, or a full sentence: the resolver performs normalized substring matching rather than semantic question answering.

Recommended broad-search preset:

Steps to use the search function

1. Search customer or loyalty with the expensive options disabled to get a broad overview.
2. Narrow the query to an exact live projection such as CustomerLoyaltyHandling.
3. Enable Resolve OpenAPI metadata for a compact summary of paths, methods, tags, and schema names.
4. Select Full OpenAPI Output to load the complete JSON document, including parameters, request bodies, responses, and schema properties. The formatted document replaces the result area so Copy output and Save as JSON export the full specification; Save suggests <ProjectionName>.json automatically.
5. Select Open Documentation online to open the same projection in the interactive IFS API documentation viewer configured by the current Base URL and App Context.

Full OpenAPI Output and Open Documentation online are enabled only when exactly one live projection matches. Local source artifacts, zero matches, and multiple matches keep both buttons disabled.

When JSON output is disabled, the readable result table includes an Active column: a green check mark indicates an active live projection and a red cross indicates an inactive one. Local artifacts without a live activation status show a dash.

Preparation

IAM Client Setup

To use the Live mode, you must configure an IAM Client in IFS Cloud with the following settings:

• Client Type: Service Account (or Public with Direct Access Grant).
• Enabled Grants: Direct Access Grant must be enabled to allow username/password or client credentials flow.
• Redirect URI: Set a valid Redirect URI (e.g., http://localhost).
• Permissions: The service account/user must be granted access to the ProjectionExplorer projection (to search metadata) and any other specific APIs you wish to resolve.

Environment Setup

The installed extension has no Python or Go runtime dependency. Its VSIX contains prebuilt Go resolver binaries for macOS x64/ARM64, Linux x64/ARM64, and Windows x64. Building the extension from source requires Node.js/npm and Go 1.22 or newer. A custom compatible resolver executable can be selected with ifsProjectionResolver.binaryPath.

For live mode in the VS Code extension, prefer global extension settings such as ifsProjectionResolver.baseUrl, ifsProjectionResolver.appContext, ifsProjectionResolver.tokenUrl, ifsProjectionResolver.clientId, ifsProjectionResolver.clientSecret and ifsProjectionResolver.scope. These are passed to the resolver as IFS_* environment variables before any local .env fallback is considered. Local workspace .env fallback is disabled by default in the extension and can be enabled with ifsProjectionResolver.useLocalEnv.

Base URL, token URL, client ID, and client secret are intentionally empty on a new installation. Enter the values for your own IFS Cloud environment in the IAM configuration section. Updating the extension does not replace existing user settings.

For CLI usage, or when .env fallback is enabled, use:

IFS_BASE_URL=https://your-ifs.example.com
IFS_APP_CONTEXT=main
IFS_TOKEN_URL=https://your-ifs.example.com/auth/realms/<realm>/protocol/openid-connect/token
IFS_CLIENT_ID=<client-id>
IFS_CLIENT_SECRET=<client-secret>
IFS_SCOPE="openid microprofile-jwt"

If ifsProjectionResolver.sourceRoot or --source-root points to a local IFS Cloud checkout and live credentials are missing, the resolver skips live IFS access and runs a source-only scan instead of failing with a credential error.

Optional resolver settings:

IFS_TIMEOUT_SECONDS=30
IFS_MAPPING_FILE=path/to/optional_mapping_hints.md

Set IFS_APP_CONTEXT=int or ifsProjectionResolver.appContext = "int" for environments whose APIs live below /int/ifsapplications/.... If the base URL already ends in /main or /int, the resolver detects that suffix automatically.
