Helix Query Language Extension

This extension provides syntax highlighting and language support for Helix Query Language (HelixQL) files.

Features

• Syntax highlighting for .hx and .hql files with automatic colorization
• Language server integration for diagnostics and hover information
• Support for HelixQL schema definitions (nodes, edges, vectors)
• Query syntax highlighting with proper scoping
• Automatic color scheme - works with any VS Code theme

File Extensions

The extension supports files with the following extensions:

• .hx - Helix Query files
• .hql - Helix Query Language files

Automatic Syntax Highlighting

The extension automatically provides rich syntax highlighting for HelixQL files with the following color-coded elements:

• Keywords: QUERY, RETURN, WHERE, etc. in purple/magenta
• Schema Types: N::, E::, V:: in blue
• Traversal Operators: ::Out, ::In, ::WHERE in yellow
• Creation Operators: AddN, AddE, AddV in teal
• Punctuation: Different colors for different bracket types:
  • <> (generics) in bright yellow
  • () (parameters) in magenta
  • {} (blocks) in gold
  • [] (arrays) in orange-red
• Variables: Light blue for identifiers and field names
• Types: Blue for primitive types like String, I32, etc.
• Strings: Orange for string literals
• Numbers: Light green for numeric values
• Comments: Green and italic

The colors are automatically applied to your existing theme - no configuration required!

Advanced Customization (Optional)

If you want to customize the colors further, you can override them in your VS Code settings.json:

{
  "editor.tokenColorCustomizations": {
    "textMateRules": [
      {
        "scope": "punctuation.definition.generic.begin.helixql",
        "settings": {
          "foreground": "#YOUR_COLOR_HERE"
        }
      }
    ]
  }
}

Available Scopes

The following TextMate scopes are available for customization:

Keywords

• keyword.control.helixql - Control keywords (RETURN, WHERE, etc.)
• keyword.other.query.helixql - QUERY keyword
• keyword.other.node.helixql - N:: prefix
• keyword.other.edge.helixql - E:: prefix
• keyword.other.vector.helixql - V:: prefix
• keyword.operator.traversal.helixql - Traversal operators (::Out, ::In, etc.)
• keyword.operator.creation.helixql - Creation operators (AddN, AddE, etc.)

Punctuation

• punctuation.separator.double-colon.helixql - :: separator
• punctuation.separator.dot.helixql - . separator
• punctuation.separator.comma.helixql - , separator
• punctuation.definition.generic.begin.helixql - < for generics
• punctuation.definition.generic.end.helixql - > for generics
• punctuation.definition.parameters.begin.helixql - ( for parameters
• punctuation.definition.parameters.end.helixql - ) for parameters
• punctuation.definition.block.begin.helixql - { for blocks
• punctuation.definition.block.end.helixql - } for blocks
• punctuation.definition.array.begin.helixql - [ for arrays
• punctuation.definition.array.end.helixql - ] for arrays

Variables and Types

• variable.other.helixql - Variable names
• variable.parameter.helixql - Parameter names
• variable.other.field.helixql - Field names
• entity.name.function.helixql - Function names
• entity.name.type.helixql - Type names
• support.type.primitive.helixql - Primitive types

Language Server

The extension includes a language server that provides:

• Real-time diagnostics for syntax and semantic errors
• Hover information for HelixQL keywords and operations
• Schema validation

Requirements

• VS Code 1.63.0 or higher

Installation

Install from the VS Code marketplace or install the .vsix file directly.

Development

To build and package the extension:

npm install
npm run compile
npm run package
