Databricks Notebook Studio

A VS Code extension that transforms Databricks .py files into interactive notebooks with SQL execution, rich DataFrame display, and multi-profile authentication.

Features

Execute Code with Databricks Connect

• Run Python & SQL cells directly against your Databricks cluster
• Serverless compute support - no cluster management needed
• Persistent kernel state - variables persist across cell executions like Jupyter

Rich DataFrame Display

• Interactive tables for Spark DataFrame results
• Column sorting and resizing for easy data exploration
• Scrollable output for large query results
• Formatted display - automatic spark.sql() wrapping for SQL cells

Multi-Profile Authentication

• Switch between Databricks profiles with a single click
• Status bar indicator showing current active profile
• Automatic kernel restart on profile change
• Workspace-level persistence - remembers your selection per project

SQL IntelliSense

• Schema & table suggestions - auto-complete catalog, schema, and table names
• Column name completion - type a table alias followed by . to get column suggestions (e.g., a. suggests columns from the aliased table)
• Context-aware recommendations - suggestions adapt based on your query context

Full Notebook Experience

• Visual cell separation with proper boundaries
• Rendered Markdown with full formatting support
• Syntax highlighting for Python, SQL, Scala, R, and Shell
• Magic command support - %md, %sql, %python, %pip, %sh, %run
• Cell titles via DBTITLE metadata
• Round-trip editing - preserves Databricks format on save

Supported Cell Types

Installation

Prerequisites

This extension requires the following VS Code extensions (you'll be prompted to install them):

• Python - For Python kernel execution
• Databricks - For workspace configuration and authentication

Important: Databricks Connect Version Requirement

For serverless compute support, you must use Databricks Connect version 17.2 or earlier. Version 17.3+ does not support serverless compute.

# Create and activate a virtual environment
python -m venv .venv
source .venv/bin/activate  # On macOS/Linux
# .venv\Scripts\activate   # On Windows

# Install the correct version
pip install "databricks-connect<=17.2"

Usage

Opening a Databricks Notebook

1. Right-click menu: Right-click on a .py file in the Explorer and select "Open as Databricks Notebook"

2. Command Palette: Open a .py file, then use Ctrl+Shift+P and type "Open as Databricks Notebook"

3. Auto-detection: When opening a file that starts with # Databricks notebook source, you'll be prompted to open it as a notebook

Recommended: Enable automatic rendering in settings for the best experience. Turn on databricks-notebook.autoOpenNotebooks in VS Code Settings, or open it directly: vscode-insiders://settings/databricks-notebook.autoOpenNotebooks

Managing Databricks Profiles

The extension supports managing multiple Databricks authentication profiles from your ~/.databrickscfg file.

Profile Selection

1. Status Bar: Click the cloud icon in the status bar (bottom right) showing your current profile
2. Command Palette: Use Ctrl+Shift+P and type "Select Databricks Profile"
3. Quick Pick: Choose from the list of available profiles with host information

The status bar shows:

• $(cloud) profile-name - Profile is selected and active
• $(cloud) No Profile - No profile selected (yellow warning)
• $(cloud) No Config - No ~/.databrickscfg file found (red error)

Note: Make sure a databricks.yml exists in your project (set up via the Databricks extension tab) that references the corresponding profile. If you want to use a different profile, you can switch it using the status bar or Command Palette but make sure to log into that profile using databricks auth login --profile profile_name to refresh the Access Token.

Profile Configuration

Recommended: Use the Databricks Extension (Required Dependency)

The easiest way to configure profiles is through the official Databricks extension for VS Code:

1. Install the Databricks extension (automatically prompted as a dependency)
2. Open Command Palette (Ctrl+Shift+P) → "Databricks: Configure workspace"
3. Follow the authentication flow to log in to your Databricks workspace

For detailed setup instructions, see the Databricks Extension Quickstart Guide.

The Databricks extension automatically:

• Creates and manages your ~/.databrickscfg file with profile configurations
• Generates and refreshes OAuth tokens in ~/.databricks/token-cache.json
• Enables seamless auto-sync between local files and Databricks workspace

This integration allows the Databricks Notebook Studio to automatically authenticate with your configured profiles without manual token management.

Alternative: Databricks CLI

You can also configure profiles using the Databricks CLI:

# Login to Databricks (creates/updates profile)
databricks auth login --host https://your-workspace.cloud.databricks.com

# Login with a specific profile name
databricks auth login --host https://prod.cloud.databricks.com --profile prod

Example ~/.databrickscfg:

[DEFAULT]
host = https://dev.cloud.databricks.com
auth_type = databricks-cli

[prod]
host = https://prod.cloud.databricks.com
auth_type = databricks-cli

Profile Switching

When you switch profiles:

1. The extension updates the environment variable for the Python kernel
2. Any running kernels are automatically restarted with the new profile
3. Your selection is saved per workspace

Configuration

Configure the extension in VS Code settings (Cmd+, or Ctrl+,):

💡 Tip: You can change the data display limit directly in VS Code settings UI:

• Press Ctrl+, (Windows/Linux) or Cmd+, (Mac)
• Search for "Databricks data display"
• Adjust the numeric value (1-100,000)

Example settings.json:

{
  "databricks-notebook.autoOpenNotebooks": true,
  "databricks-notebook.showNotification": true,
  "databricks-notebook.defaultProfile": "prod",
  "databricks-notebook.showProfileInStatusBar": true,
  "databricks-notebook.dataDisplayLimit": 100
}

Recommended configurations:

• Manual mode (default): autoOpenNotebooks: false, showNotification: true

  • You'll see a prompt asking if you want to open as notebook

• Auto mode: autoOpenNotebooks: true

  • Databricks .py files automatically open as notebooks

• Silent mode: autoOpenNotebooks: false, showNotification: false

  • No automatic behavior; use right-click or Command Palette to open as notebook

Note: After changing these settings, you may need to reload VS Code (Cmd+Shift+P → "Developer: Reload Window") for the changes to take effect on already-opened files.

Databricks .py Format

Databricks notebooks exported as .py files follow this format:

# Databricks notebook source

print("Python cell")

# COMMAND ----------

# MAGIC %md
# MAGIC # Markdown Heading
# MAGIC Some markdown content

# COMMAND ----------

# MAGIC %sql
# MAGIC SELECT * FROM table

License

MIT
