Automaton Automator

Automaton Automator

HakkinDavid

|
10 installs
| (1) | Free
Automaton editor with real time preview. Requires Graphviz.
Installation
Launch VS Code Quick Open (Ctrl+P), paste the following command, and press enter.
Copied to clipboard
More Info

Automaton Automator

This Visual Studio Code extension allows working with .auto files to visualize automata using Graphviz.

Features

  • Real-time preview of DOT/Graphviz diagrams
  • Special focus on automata
  • Command to copy as PNG
  • Syntax highlighting for .auto and .dot files

Requirements

  • Visual Studio Code 1.60.0 or higher
  • Graphviz installed on the system (the dot command available in the PATH)

Usage

  1. Install the extension
  2. Create or open a file with the .auto extension
  3. The extension will automatically display a preview of the diagram
  4. Use the context menu or command palette for "Copy as PNG"

Example of a .auto file

digraph pda {
  rankdir=LR;
  size="8,5"

  node [shape = point]; qi
  node [shape = circle]; q1 q2 q3
  node [shape = doublecircle]; q4

  qi -> q1

  q1 -> q2 [label="1,\\epsilon\\to\\empty"]
  q2 -> q1 [label="\\epsilon,\\epsilon\\toB"]
  q1 -> q3 [label="\\epsilon,\\empty\\to$"]
  q2 -> q4 [label="0,A\\to\\epsilon"]
  q3 -> q4 [label="\\epsilon,B\\toA"]
  q4 -> q1 [label="0,$\\to\\epsilon"]
}
