SailPoint IIQ Studio

---

Overview

SailPoint IIQ Studio is a Visual Studio Code extension designed to simplify SailPoint IdentityIQ development.

It provides a modern development experience with direct IdentityIQ integration, allowing developers to import, edit, compare, refresh, and deploy IdentityIQ objects without leaving VS Code.

---

Features

Server Management

• Multiple IdentityIQ server support
• Secure credential storage
• Active server selection
• Test server connectivity

---

Object Management

Supports importing and managing:

• Rules
• Workflows
• Applications
• Forms
• Policies
• Tasks
• Bundles
• QuickLinks

---

Development Features

✔ Import Object from IdentityIQ

✔ Refresh Current XML

✔ Deploy Current XML

✔ Compare Local XML with IdentityIQ

✔ Compare XML Across Environments

✔ Bulk Deploy Folder

---

XML Processing

Automatic XML cleanup during import.

Features include:

• Preserve CDATA
• Remove Internal IDs
• Remove Created Timestamp
• Remove Modified Timestamp
• Remove Reference IDs
• Clean XML for source control

---

Security

• Passwords stored using VS Code Secret Storage
• No credentials stored in project files
• Multi-server support

---

Installation

Install from the Visual Studio Code Marketplace.

Or manually install the VSIX package.

---

⚠️ Prerequisites

SailPoint Studio uses a deployment workflow inside IdentityIQ to enable advanced operations.

The following features require the workflow to be installed:

• ✅ Import Object
• ✅ Refresh Object
• ✅ Deploy Object
• ✅ Compare Object

---

Step 1 - Download the Workflow

Download the workflow XML from GitHub:

Workflow-SailPointStudioImporter.xml

https://github.com/h2creations/sailpoint-studio/blob/master/config/Workflow/Workflow-SailPointStudioImporter.xml

Click Download Raw File (or Raw) and save the XML file locally.

---

Step 2 - Import into IdentityIQ

Login to your IdentityIQ environment.

Navigate to:

System Setup
    └── Import from File

Select:

Workflow-SailPointStudioImporter.xml

Click Import.

If your application server requires it, restart IdentityIQ after the import.

---

Step 3 - Verify Installation

Open SailPoint Studio in VS Code.

1. Add your IdentityIQ server.
2. Test the connection.
3. Import or Deploy an object.

If the workflow has been installed successfully, all deployment features will work automatically.

---

Notes

• The workflow only needs to be imported once per IdentityIQ environment.
• If you have multiple environments (DEV, UAT, QA, PROD), import the workflow into each environment separately.
• Existing workflows can be updated by importing a newer version of the workflow.

Note: The deployment workflow is required only for Import, Refresh, Deploy, and Compare operations. Basic server management and connection testing do not require the workflow.

Getting Started

1. Add Server

Open the SailPoint Activity Bar.

Click

+

Enter

• Server Name
• IdentityIQ URL
• Username
• Password

---

2. Connect

Right-click server

Connect

---

3. Import Object

Click

Import Object

Choose

• Object Type

Example

Rule

Search

BeforeProvisioning

The XML is automatically downloaded into the workspace.

---

4. Edit

Edit XML normally inside VS Code.

---

5. Compare

Right-click XML

Compare with IdentityIQ

or

Compare with Environment

---

6. Refresh

Right-click XML

Refresh Current XML

Latest version is downloaded from IdentityIQ.

---

7. Deploy

Right-click XML

Deploy Current XML

Deploys only the selected object.

---

8. Bulk Deploy

Right-click folder

Bulk Deploy Folder

Deploys every XML file inside the selected folder.

---

Supported Objects

Object	Supported
Rule	✅
Workflow	✅
Application	✅
Form	✅
Policy	✅
Bundle	✅
TaskDefinition	✅
QuickLink	✅

---

Workspace Structure

Workspace

Rules/
Workflows/
Applications/
Forms/
Policies/
Tasks/
Bundles/
QuickLinks/

---

Requirements

• SailPoint IdentityIQ 8.x
• SCIM Enabled
• Workflow Importer Installed

---

Beta Notice

SailPoint IIQ Studio is currently in Beta.

Please report issues and feature requests on GitHub.

---

Roadmap

Community Edition

• Multiple Servers
• Import Objects
• Deploy Objects
• Refresh Objects
• Compare Objects
• XML Sanitizer

Planned

• Deployment Reports
• Output Console
• XML Validation
• Dependency Viewer
• Rule Impact Analysis

Professional Edition (Future)

• AI Assistant
• Advanced Bulk Deployment
• Environment Synchronization
• Deployment Planning
• Team Collaboration

---

Contributing

Contributions, bug reports and feature requests are welcome.

---

License

Copyright © 2026

All Rights Reserved.

---

Disclaimer

SailPoint IIQ Studio is an independent project and is not affiliated with, endorsed by, or sponsored by SailPoint Technologies.

IdentityIQ and SailPoint are trademarks of SailPoint Technologies.
