AgentUX — VS Code Extension for Screenshot UX Audits

AgentUX reviews static UI screenshots with OpenAI Vision, a strict JSON pipeline, and an interactive VS Code webview. It surfaces spacing, typography, contrast, navigation, interaction, and design-system insights backed by attention heatmaps and region overlays.

Two Distinct Output Formats

AgentUX provides two complementary analysis outputs to help you understand and act on UX findings:

1. Visual Output

An interactive webview panel displaying:

• Screenshot overlay with bounding boxes highlighting detected issues
• Attention heatmap showing visual focus areas (adjustable opacity)
• Interactive region selection (click regions or use Ctrl+A to select all, Escape to clear)
• Hover-to-highlight linking between region boxes and findings list
• Keyboard navigation support for accessibility

2. Descriptive Output

Category-based findings organized across 8 UX categories:

• Spacing & Alignment — Crowding, misalignment, inconsistent gutters, grid violations
• Typography — Font size issues, readability problems, hierarchy concerns, legibility warnings
• Color & Contrast — Low-contrast regions, WCAG compliance issues, accessibility violations
• Interaction Targets — Button/touch target sizing, spacing between actions, missing affordances
• Navigation & Information Architecture — Menu clarity, navigation flow, structure issues
• Design System Drift — Inconsistent components, style variations, token misalignment
• Visual Hierarchy — Element prominence, information prioritization, grouping issues
• Feedback States — Loading states, error messages, user action feedback

Each finding includes:

• Severity level (low/medium/high) with numeric scores
• Actionable notes identifying specific UI elements
• Issue type classification (hard: accessibility violations; soft: style preferences)
• Category-specific recommendations for remediation

Features

• OpenAI Vision analysis with enforced strict-JSON responses (repaired and validated).
• Three-question context capture (platform, UI type, audience) saved to analysisState.metadata.
• Multi-agent pipeline (region segmentation → classification → spacing/typography/contrast/interaction/navigation/design-system → recommendations → heatmap).
• Interactive webview with screenshot, bounding boxes, heatmap, hover-linked findings, keyboard navigation, and theme-aware styling.
• Descriptive category-based findings with actionable recommendations.
• Exports (JSON/Markdown/SVG/PNG) for sharing findings.
• Secure storage of API keys via VS Code SecretStorage.

Requirements

• VS Code 1.90+
• Node.js 18+
• OpenAI API key with Vision access (only needed for real-run testing; mocked responses are used during development).

Commands

• UX Audit: Analyse Screenshot
• UX Audit: Set OpenAI API Key
• UX Audit: Configure Context
• UX Audit: Re-run Last Analysis
• UX Audit: Export Results
• UX Audit: Open UX Panel

Development Workflow

1. npm install
2. npm run watch
3. Press F5 in VS Code to start the extension host.
4. Use mocked fixtures for most tests; reserve real API keys for late-stage validation.
5. Run the documented test suites (see docs/TESTING.md).

Documentation Map

• AGENTS.md – root rules and contracts.
• docs/ARCHITECTURE.md – high-level flow.
• docs/PIPELINE.md & docs/AGENTS_SPEC.md – agent order and contracts.
• docs/SCHEMA.md & docs/SCHEMA_VERSIONING.md – strict JSON schema and evolution.
• docs/WEBVIEW.md – UI behaviour, accessibility, overlay requirements.
• docs/TESTING.md & docs/TEST_FIXTURES.md – DevTestOps matrix, sample fixtures, Cursor vs Playwright MCP usage.
• docs/CONFIGURATION.md & docs/SECURITY.md – secrets, privacy, retention policies.
• docs/TROUBLESHOOTING.md – operational playbooks.
• docs/RELEASE_CHECKLIST.md – packaging and smoke tests.
• docs/PROMPTS.md, docs/PUBLISHING.md, docs/FOLDER_STRUCTURE.md, docs/CONTRIBUTING.md.

Release

Follow docs/RELEASE_CHECKLIST.md, package with vsce, and smoke-test the VSIX in the local VS Code client on this workstation before publishing. Use versioned tags and keep CHANGELOG entries up to date.
