File Tree Extractor

Generate a directory structure with a simple copy and paste.

Features

• 1️⃣ Extract from Any Directory: Support extracting file tree from the root or any subdirectory.
• 2️⃣ File Filtering: Automatically filter files based on your project's .gitignore or custom ignore rules.
• 3️⃣ Highly Customizable: Numerous configuration options to tailor the output.
• 4️⃣ Multiple Output Formats: Generate tree structure in ASCII or JSON format.
• 5️⃣ File Size Information: Optionally include file sizes in the output.
• 6️⃣ Depth Control: Set a maximum depth for the generated tree structure.

Usage

1. Right-click on a folder in the VS Code file explorer
2. Select "Copy File Tree" or "Copy File Tree From This Directory"
3. The file tree will be copied to your clipboard
4. Paste the tree wherever you need it

Alternatively, use the keyboard shortcut Ctrl+Alt+C to copy the file tree of the entire project.

root/
├── .env
├── .gitignore
├── asset/
│   ├── icon/
│   │   └── icon.png
│   ├── logo.svg
│   └── logo_text.svg
├── dist/
│   ├── index.d.ts
│   ├── main.esm.js
│   ├── main.js
│   ├── main.min.js
│   ├── main.min.js.map
│   └── main.umd.js
├── file_tree.txt
├── package-lock.json
├── package.json
├── README.md
├── rollup.config.js
└── src/
    ├── config.js
    ├── error.js
    ├── index.js
    ├── render.js
    ├── util.js
    └── validate.js

Configuration

You can customize the extension's behavior through VS Code settings.

To access these settings, go to File > Preferences > Settings and search for "File Tree Extractor".

fileTreeExtractor.ignoredItems

Description: This setting allows you to specify a list of files and folders that should be ignored when generating the file tree. It is useful if you want to exclude certain files or folders from the generated file tree, such as temporary or cached files, or other directories that are not part of your project's main structure.

Default Value: [".git", "node_modules"]

settings.json

"fileTreeExtractor.ignoredItems": [".git", "node_modules", "dist", "**/src"]

root/
├── .env
├── .gitignore
├── asset/
│   ├── icon/
│   │   └── icon.png
│   ├── logo.svg
│   └── logo_text.svg
├── package-lock.json
├── package.json
├── README.md
└── rollup.config.js

fileTreeExtractor.ignoredBy

Description: Specifies the method to ignore files and folders when generating the file tree structure.

Options: "gitignore" | "ignoredItems" | "both"
Default Value: "ignoredItems"

settings.json

"fileTreeExtractor.ignoredBy": "ignoredItems"

• "gitignore": The extension will use the .gitignore file to determine which files and folders to ignore.
• "ignoredItems": The extension will use "fileTreeExtractor.ignoredItems" specified in the extension settings.
• "both": The extension will use both "ignoredItems" and "gitignore" method.

fileTreeExtractor.indent

Description: The number of spaces to use for indenting each level in the generated file tree.

Default Value: 1

settings.json

"fileTreeExtractor.indent": 4

root/
├──── .env
├──── .gitignore
├──── asset/
│     ├──── icon/
│     │     └──── icon.png
│     ├──── logo.svg
│     └──── logo_text.svg
├──── package-lock.json
├──── package.json
├──── README.md
└──── rollup.config.js

fileTreeExtractor.showFileSize

Description: Include file sizes in the generated tree.

Options: "true" | "false"
Default Value: "false"

settings.json

"fileTreeExtractor.showFileSize": true

root/
├── .env (0 Bytes)
├── .gitignore (135 Bytes)
├── asset/
│   ├── icon/
│   │   └── icon.png (1.36 MB)
│   ├── logo.svg (677 Bytes)
│   └── logo_text.svg (1.71 KB)
├── package-lock.json (217.22 KB)
├── package.json (1.27 KB)
├── README.md (0 Bytes)
└── rollup.config.js (1.27 KB)

fileTreeExtractor.maxDepth

Description: Sets the maximum depth of the generated file tree structure. Using a value of -1 will generate the tree with unlimited depth.

Default Value: -1

settings.json

"fileTreeExtractor.maxDepth": 3

root/
├── .env
├── .gitignore
├── asset/
│   ├── icon/
│   ├── logo.svg
│   └── logo_text.svg
├── package-lock.json
├── package.json
├── README.md
└── rollup.config.js

fileTreeExtractor.outputFormat

Description: The format of the output tree structure.

Options: "ascii" | "json" | "yaml" | "xml"
Default Value: "ascii"

settings.json

"fileTreeExtractor.outputFormat": "json"

{
  "name": "root",
  "type": "directory",
  "children": [
    {
      "name": "asset",
      "type": "directory",
      "children": [
        {
          "name": "icon",
          "type": "directory",
          "children": [
            {
              "name": "icon.png",
              "type": "file",
              "size": "104.36 KB"
            }
          ]
        },
        {
          "name": "logo.svg",
          "type": "file",
          "size": "677 Bytes"
        },
      ]
    },
    {
      "name": "package.json",
      "type": "file",
      "size": "1.27 KB"
    },
  ]
}

fileTreeExtractor.directoryOnly 🆕

Description: Show only directories in the tree structure, excluding all files from the output.

Default Value: false

settings.json

"fileTreeExtractor.directoryOnly": true

menuy/
├── asset/
│   └── icon/
├── dist/
└── src/

fileTreeExtractor.showHiddenFiles 🆕

Description: Show hidden files in the tree output.

Default Value: true

Notice: The option only works for Linux and Mac OS.

Commands

• File Tree Extractor: Copy File Tree
• File Tree Extractor: Copy File Tree From This Directory
• File Tree Extractor: Report an Issue

Feedback & Contributions

We welcome your feedback and contributions! Please report any issues or suggestions through:

• The "Report an Issue" command in VS Code
• Our GitHub repository

License

This extension is licensed under the MIT License.
