FluxLoop VSCode Extension

Visual Studio Code extension for managing FluxLoop AI agent simulation projects.

Features

🎯 Project-Centric Workflow

• Create and manage multiple FluxLoop projects from the Activity Bar
• Switch between projects with a single click
• Automatic project discovery and configuration validation

📝 Input Management

• View and edit base inputs from configs/input.yaml
• Generate input variations using LLM or deterministic strategies
• Browse generated inputs and recordings in dedicated views

🧪 Experiment Execution

• Run experiments directly from VSCode
• Monitor execution progress with real-time feedback
• View runner configuration and iteration settings at a glance

📊 Results Exploration

• Browse experiment outputs organized by run timestamp under an Experiments folder
• Open traces, summaries, observations, and artifacts with one click
• Parse results into human-readable Markdown timelines with Parse Results action
• Evaluate experiments with rule-based and LLM evaluators using Evaluate Results action
• View parsed analysis outputs in the per_trace_analysis/ folder
• Review evaluation outputs in the evaluation/ folder:
  • summary.json – aggregate statistics, success criteria results, analysis (persona, outliers, trends, baseline comparison)
  • per_trace.jsonl – per-trace scores and failure reasons
  • report.md – human-readable Markdown report
  • report.html – interactive HTML report with charts and visualizations (Phase 2)

🔴 Recording Mode (Advanced)

• Toggle argument recording for complex function signatures
• Enable/disable recording mode from Command Palette or Experiments view
• Status panel shows current recording state and target file

🤖 Integration Assistant (Flux Agent)

• Dedicated Integration view with MCP connection status and recent suggestions
• One-click document search backed by the FluxLoop MCP server
• Flux Agent runs in Integration mode:
  • Repository analysis + framework detection
  • Generates edit plan with validation checklist
  • Uses source_root from project.yaml to analyze target source code (not FluxLoop project folder)
  • No need to open a file—just select folders/files from a picker when running the agent
  • Automatically appends caution notice reminding users to confirm changes before applying
• Suggestion history stores file context, selected code, workflow metadata, and the generated plan

---

Installation

Recommended: Install from Extension Marketplace

🎯 Cursor Users

1. Open Extensions sidebar (Cmd+Shift+X or click Extensions icon)
2. Search for "FluxLoop"
3. Click Install
4. Restart Cursor

Extension is automatically downloaded from Open VSX Registry

💻 VS Code Users

1. Open Extensions (Cmd+Shift+X / Ctrl+Shift+X)
2. Search for "FluxLoop"
3. Click Install
4. Restart VS Code

Or install directly from VS Code Marketplace

Alternative: Manual Installation from VSIX

If you prefer manual installation:

1. Download the latest .vsix file from GitHub Releases
2. Open Command Palette (Cmd+Shift+P or Ctrl+Shift+P)
3. Type and select "Extensions: Install from VSIX..."
4. Select the downloaded .vsix file
5. Restart your editor

Required Dependencies

Install FluxLoop CLI and SDK:

pip install fluxloop-cli fluxloop

Install the FluxLoop MCP server:

pip install fluxloop-mcp

Build (or download) the MCP knowledge index:

packages/mcp/scripts/rebuild_index.sh

Verify you have Python 3.11 or newer:

python3 --version

Flux Agent also requires an OpenAI API key. You can supply it per run or store it securely after the first prompt.

---

Quick Start

1. Create a Project

Open the FluxLoop Activity Bar and click "Create New Project…" or run:

FluxLoop: Create FluxLoop Project

You’ll first choose between two flows:

• Default (Recommended) – Use your current workspace as the agent source, detect its Python environment, and create the FluxLoop project inside the shared root (default ~/FluxLoopProjects).
• Custom (Advanced) – Manually pick both the FluxLoop project location and the environment (original flow retained for power users).

Default Flow

1. Project name – Enter a name; the extension previews the target path (e.g. ~/FluxLoopProjects/agent-e2e).
2. Environment selection – FluxLoop auto-discovers interpreters from:
   • VSCode Python extension’s active interpreter
   • .venv, poetry, conda, pyenv folders under your workspace
   • Manual browse option and a fall-back “Use system Python (not recommended)”
3. Example content – Decide whether to include the sample agent.
4. The project is generated inside the shared root, the environment is validated (with guided retries/install options), and the project is registered/activated.
   • The shared root is stored in fluxloop.projectRoot (change via Settings → FluxLoop → Project Root).

Custom Flow

Follow the original prompts:

• Pick the FluxLoop project root manually
• Enter the project name
• Choose/Create the environment (including project-local .venv)
• Decide on example content

In both flows the extension runs fluxloop init project, creates configs/, .env, examples/, inputs/, recordings/, experiments/, and saves workspace settings that point to the chosen environment.

Check the detected environment anytime via:

FluxLoop: Show Environment Info

For full diagnostics (Python/FluxLoop/MCP/index), run:

FluxLoop: Run Doctor

2. Review Configuration

Navigate to the Inputs view to inspect base inputs from configs/input.yaml. Click any base input to open the config file directly.

Alternatively, go to Experiments → Current Experiment → Open configuration to review configs/simulation.yaml.

3. Generate Inputs

From the Inputs view, click "Generate New Inputs…" to launch the wizard:

• Choose generation mode (Deterministic/LLM)
• Select variation strategies (rephrase, verbose, error_prone, etc.)
• Set limit and overwrite options
• Enter LLM API key if needed (saved to VS Code secrets and .env)

Generated inputs will appear under Inputs → Generated Inputs.

4. Run Experiment

From the Experiments view:

• Click Run Experiment (located next to Current Experiment)
• Select execution environment (Local Python/Dev Container)
  • Local Python: Runs with your current Python environment
  • Dev Container: Runs inside an active Dev Container
  • Docker: Coming soon
• Optionally override iterations

Results will be saved to experiments/ and appear in the Results view.

5. View Results

The Results view lists recent experiment runs under an Experiments folder. Expand any run to see:

• Parse Results – Generate human-readable Markdown timelines from traces
• Evaluate Results – Run rule-based + optional LLM evaluation pipeline
• per_trace_analysis/ – Parsed analysis outputs (appears after parsing)
• evaluation/ – Evaluation outputs (summary, per-trace JSONL, markdown report)
• summary.json – aggregate statistics
• traces.jsonl – detailed execution traces
• observations.jsonl – observation stream
• errors.json – error logs (if any)
• logs.json – additional logs

Click Parse Results to convert experiment outputs into per-trace Markdown files. You can specify a custom output directory or use the default per_trace_analysis.

Click Evaluate Results to run rule-based and LLM-based evaluators, compute success criteria, perform advanced analysis (persona breakdown, outlier detection, trend analysis, baseline comparison), and generate Markdown and HTML reports. Configure evaluators, thresholds, and report settings in configs/evaluation.yaml. Results are stored under evaluation/ with:

• summary.json – aggregate statistics and Phase 2 analysis
• per_trace.jsonl – detailed per-trace scores
• report.md – human-readable Markdown report
• report.html – interactive HTML report with charts (Phase 2)

Use the prompt dialog to override the output directory or keep the default evaluation.

---

6. Use the Integration Assistant

1. Open the Integration view in the FluxLoop activity bar.
2. Press Connect MCP to verify fluxloop-mcp is available and the knowledge index is present.
3. Press Search in Documents to run a one-off documentation query (fluxloop-mcp --once --query "<question>").
4. Press Run Flux Agent (no need to open a file first).
5. Choose whether to pick folders or files for analysis—the agent will scan the selected scope.
6. The extension will:
   • Read source_root from your project.yaml to determine the target codebase
   • Execute IntegrationContextTool on the selected folders/files
   • Collect the result and feed it to the configured OpenAI model
   • Render the plan (summary, step list, validation checklist) in a dedicated panel
   • Append a caution notice reminding you to keep original source intact and confirm changes
7. Provide your OpenAI API key when prompted (the extension can store it in Secret Storage).
8. Revisit previous answers from Recent Suggestions; each entry reopens the full plan and workflow metadata.

Note: The Flux Agent currently operates in Integration mode only. Future releases will add Base Input, Experiment, and Insight modes as described in the multi-mode PRD.

---

Recording Mode (Advanced)

For agents with complex call signatures (WebSocket handlers, callbacks, etc.), you can record actual arguments and replay them during experiments.

Enable Recording

Use Command Palette:

FluxLoop: Enable Recording Mode

Or run in terminal:

fluxloop record enable

This updates .env and configs/simulation.yaml to enable recording. The Status panel will show "Record Mode: Enabled".

Capture Arguments

Run your application normally. FluxLoop SDK will capture arguments to recordings/args_recording.jsonl.

Disable Recording

Use Command Palette:

FluxLoop: Disable Recording Mode

Or run:

fluxloop record disable

Configure Replay

Edit configs/simulation.yaml to use recorded arguments:

replay_args:
  enabled: true
  recording_file: "recordings/args_recording.jsonl"
  override_param_path: "data.content"

Now run experiments—FluxLoop will replay recorded arguments with generated input variations.

---

Configuration Files (v0.2.0)

FluxLoop projects use a multi-file configuration structure:

File	Purpose	Edited From
configs/project.yaml	Project metadata, collector settings	Projects view → Configure Project
configs/input.yaml	Personas, base inputs, LLM settings	Inputs view → Base Inputs (click to open)
configs/simulation.yaml	Runner, iterations, replay args	Experiments view → Open configuration
configs/evaluation.yaml	Evaluators (rule-based, LLM), success criteria, analysis options, report settings	Edit directly

All configs are YAML files that can be edited directly. The extension watches for changes and automatically refreshes views.

---

Available Commands

Access via Command Palette (Cmd+Shift+P / Ctrl+Shift+P):

Project Management:

• FluxLoop: Create FluxLoop Project
• FluxLoop: Add Existing FluxLoop Project
• FluxLoop: Switch FluxLoop Project
• FluxLoop: Remove FluxLoop Project

Workflow:

• FluxLoop: Generate Inputs
• FluxLoop: Run Experiment
• FluxLoop: Run Single Execution
• FluxLoop: Show Status
• FluxLoop: Connect MCP
• FluxLoop: Search in Documents
• FluxLoop: Run Flux Agent
• FluxLoop: Refresh Integration View
• FluxLoop: Clear Integration Suggestion History

Recording:

• FluxLoop: Enable Recording Mode
• FluxLoop: Disable Recording Mode
• FluxLoop: Show Recording Status

Configuration:

• FluxLoop: Open Configuration
• FluxLoop: Select Environment
• FluxLoop: Show Environment Info
• FluxLoop: Run Doctor
• FluxLoop: Configure Execution Wrapper

Results:

• FluxLoop: Parse Experiment – Convert experiment traces to Markdown

---

Advanced Configuration

Execution Wrapper (uv, pipx, etc.)

If you use uv, pipx, or any other wrapper to run FluxLoop CLI, configure it via:

Command Palette:

FluxLoop: Configure Execution Wrapper

Enter the prefix (e.g., uv run) and the extension will automatically prepend it to all CLI commands.

Or manually in .vscode/settings.json:

{
  "fluxloop.executionWrapper": "uv run"
}

This setting is saved to your workspace and will be applied to all FluxLoop commands.

Environment Configuration

FluxLoop automatically detects your project's Python environment (venv, conda, uv, etc.) and uses it for all commands. You can configure this behavior via:

Command Palette:

FluxLoop: Select Environment

Choose from:

• Auto (recommended): Uses project .venv/conda if found, otherwise global PATH
• Workspace only: Requires a virtual environment in the project
• Global PATH: Always uses globally installed executables
• Custom executables: Manually specify python and fluxloop-mcp paths

Or in .vscode/settings.json:

{
  "fluxloop.executionMode": "auto",
  "fluxloop.pythonPath": "/path/to/python",
  "fluxloop.mcpCommandPath": "/path/to/fluxloop-mcp"
}

Check environment status:

• Use FluxLoop: Show Environment Info or FluxLoop: Run Doctor from Command Palette
• Or click Run Doctor in the Integration view → System Status

Setting Target Source Root: When you select Target Source Root… in the Projects view, FluxLoop:

1. Updates project.yaml with the relative or absolute path to your source code
2. Detects virtual environments in that directory
3. Updates FluxLoop Output channel with detected paths
4. Prompts you to review/adjust the environment via Select Environment
5. Flux Agent will use this source_root as the workspace for repository analysis

See the FluxLoop Output channel for detailed environment logs.

---

Troubleshooting

CLI Not Found

Ensure FluxLoop CLI is installed:

pip install fluxloop-cli
# Or with uv:
uv pip install fluxloop-cli

Check the Status panel for installation status.

SDK Not Found

Install the FluxLoop SDK:

pip install fluxloop

The Status panel will verify SDK availability in your Python environment.

fluxloop-mcp Not Found

• Confirm installation: pip install fluxloop-mcp
• Verify environment: Run FluxLoop: Show Environment Info to check if fluxloop-mcp is detected in your project venv or global PATH
• Check with fluxloop doctor command for detailed diagnostics
• Rebuild the knowledge index: packages/mcp/scripts/rebuild_index.sh
• The Integration view shows the package and index state; refresh with FluxLoop: Refresh Integration View

OpenAI Key Prompt Keeps Appearing

• Store the key when prompted (Secret Storage) or set "fluxloop.openaiApiKey": "sk-..." in .vscode/settings.json
• Review and adjust the model with "fluxloop.openaiModel": "gpt-4o-mini" (or any compatible Chat Completions model)

No Configuration Found

Make sure your project has a configs/ directory with required files:

• project.yaml
• input.yaml
• simulation.yaml

Create a new project using FluxLoop: Create FluxLoop Project to scaffold this structure automatically.

Recording Not Working

1. Verify .env contains FLUXLOOP_RECORD_ARGS=true
2. Check configs/simulation.yaml → replay_args.enabled: true
3. Use FluxLoop: Show Recording Status to inspect current state

---

Development

Build Extension

cd packages/vscode
npm install
npm run compile

Package Extension

npm install -g vsce
vsce package

This produces a .vsix file that can be installed locally.

---

Contributing

See CONTRIBUTING.md for guidelines.

---

License

Apache License 2.0 - see LICENSE for details.
