Total War Modding Tools

Make Total War: WARHAMMER III mods in Visual Studio Code. Debug the game's Lua scripts while it runs, browse and edit the game database, check your mod against the game, and pack and launch it, all from one extension.

An unofficial community tool. Not affiliated with or endorsed by Creative Assembly or SEGA. Total War and WARHAMMER are trademarks of their owners.

Quick start

1. Run TotalWar: Create Mod Project… from the Command Palette. It creates a small example campaign mod, finds your game through Steam, and opens the project.
2. Open pack/script/campaign/mod/<your mod>.lua and set a breakpoint in on_heartbeat.
3. Run and Debug (Ctrl+Shift+D) → Launch into a save → F5, and pick a save.

Before every launch the project's totalwar-pack task packs your mod and installs it. The debug session then installs the debugger mod and lists it in the project's mod list file, so there is nothing else to set up. The project's README explains the rest.

Features

Lua debugger

• Breakpoints, conditional breakpoints, hit counts and logpoints.
• Step over, into and out; pause.
• Locals, upvalues and globals. Expand tables, functions and userdata metatables, and change values in the Variables view.
• Evaluate expressions and statements in the Debug Console, even while the game is running. Hover to evaluate while stopped.
• Break on script_error() (in the Breakpoints view). By default it only breaks when a mod script (a file in a mod folder) is involved, because the game's own scripts report errors during normal play. "All script_error() calls" and error() calls are available too.
• From Lua, debuggee.print("warning", "text") prints to the Debug Console (log, warning or error) and debuggee.breakHere("why") stops in the debugger.
• The game's script log (out, print) is mirrored to the Debug Console.
• The debugger follows the game between frontend, campaign and battle and keeps your breakpoints.

Runtime tools (while a debug session is connected)

• Campaign view in Run and Debug shows the factions, their characters and regions, live from the game. Right-click to:
  • add money;
  • apply an effect bundle;
  • give a region to another faction;
  • add levels to, teleport or kill a character.
• TotalWar: Start/Stop Event Monitor lists the script events the game fires, with their faction, character, region and so on, in the TW Script Events output. totalwar.eventMonitor.exclude leaves out noisy events.
• Run File / Run Selection in the Game (editor context menu) runs Lua in the game's script environment. With totalwar.hotReload, saving a mod script runs it again in the game. Guard any listeners it adds, or they are added twice.
• TotalWar: Start Profiler, then Stop Profiler and Show Results, shows where the scripts spend their time, as the busiest functions and a flame graph. The sample interval is totalwar.profiler.interval Lua instructions.

Virtual source files

Every file in the game's packs and in the mods in your mod list is available as the read-only totalwar:/ file system:

• @basegame/ holds the game's own files and @mods/<pack>/ holds each mod's files, so you can see where a file comes from.
• Text files (Lua, XML, .variantmeshdefinition, .wsmodel, .material, ...) open as text in their language, also when the game stores them as UTF-16. DB tables (db/<table>/<file>) open read-only in the table editor, and other files open in whatever editor you have for them.
• TotalWar: Copy to Mod (context menu and editor title of a virtual file) copies the file into your mod's pack folder at the same path, ready to edit. For a DB table it offers to copy one entity instead of the whole table.
• Stack frames open the copy the game actually runs: the first mod in the mod list that has the file, otherwise the game's own. A local copy is preferred when there is one, and a breakpoint in any copy stops in the copy that runs.

To keep the files in the Explorer, use a workspace file that includes them. Adding a folder to a plain folder window restarts the extensions, which ends a running debug session.

// my_mod.code-workspace
{ "folders": [ { "path": "." }, { "name": "Virtual TW Source Files", "uri": "totalwar:/" } ] }

You can also run TotalWar: Show Virtual Source Files while not debugging.

The game alone has over 700,000 files. TotalWar: Filter Virtual Files… (also in the context menu of the virtual folders) hides kinds of files: audio, animations, models, textures and so on. Folders left empty disappear. The command writes the totalwar.virtualFiles.exclude setting, which also accepts your own glob patterns (*.wem, ui/skins/**). Hidden files still open from the debugger and from links.

Models, materials and other game files

• Asset paths in variant mesh definitions, wsmodels, materials and other XML files (variantmeshes/.../x.rigid_model_v2, .dds, .anim, ...) are links: Ctrl+click opens the copy the game uses, from your mod or the packs, and hovering one tells which pack it comes from, with a thumbnail for textures (.dds, .png, .tga, .jpg). Paths complete folder by folder as you type (or with Ctrl+Space after the quote). Paths in your mod that point at no file get a warning.
• Binary files as JSON: portrait settings (portrait_settings*.bin), battle animation fragments (animations/database/battle/bin/*.bin), anim tables, matched combat files, battle map definitions (.bmd) and vegetation open as JSON in a normal text editor, with validation and field descriptions. Saving writes the binary file again; a value the format cannot hold is refused instead of saved. When a file opens, the extension checks that saving it unchanged gives back the exact same bytes, so nothing RPFM does not understand can be lost; a file that fails the check opens read only and says why (in WARHAMMER III every file that decodes passes). TotalWar: Open as JSON in the Explorer's context menu also tries .atlas and groupformations.bin. A BMD (or a part of one) in a version RPFM does not know, about one in ten of the game's, only opens in the default editor. In the JSON of a game file, TotalWar: Copy to Mod (editor title) copies the binary file into your mod.
• DB keys in portrait settings: an entry's id (an art set of campaign_character_art_sets_tables) and a variant's filename (the variant_filename of variants_tables) show their row on hover, complete from the tables, and get a warning when no row has them, also from TotalWar: Check Mod. The mod's own tables count, packed or not.

Game Database

The DB tables (units, buildings, effects, ...) show the values the game uses for your mod list. Each row shows the pack it comes from and the rows it overrides. Within a table, fragments load by file name (!!!my_mod before the game's data__), and the first row with a given key wins.

• The Game Database view in Run and Debug lists the tables. Click one to open it as a sortable, filterable grid (or use TotalWar: Open DB Table…). Click a reference cell to open the row it points to.
• In the Debug Console, :db <table> [key filter] or :db <key> looks up rows. It works without the game running.
• Hover a key string in Lua ("wh_main_emp_inf_swordsmen") to see its row and its texts, for example a unit's on-screen name (totalwar.dbHover).
• TotalWar: Show Conflicts Between Mods in the Mod List lists the files and DB rows that more than one mod in the mod list contains, and which one the game uses.

DB and loc editors

Opening a table file in your mod (pack/db/<table>/<file>) shows it in the same grid, editable. Saving writes the binary table, and the totalwar-pack task packs it.

• Double-click a cell (or press Enter or F2) to edit it. Booleans toggle, and numbers are checked against the column type. Reference columns suggest the game's keys and outline unknown ones. Ctrl+click a reference to open the row it points to.

• Add row (with the schema's defaults), Duplicate, Delete (Del), and Import from game…, which copies rows from the game's tables as your mod list has them. Undo, redo, Save and Revert work as usual.

• The effect column says what each row does in the game:

  • adds a new row;
  • overrides another pack's row (the changed cells are highlighted);
  • loses to a file that sorts first;
  • repeats a key used earlier in the file.

• TotalWar: New DB Table… (also in the Explorer's context menu on a folder) creates an empty fragment, named !!!<mod> by default.

• Loc files (*.loc, *.loc.tsv) open in the same grid (key, text, tooltip). TotalWar: New Loc File… creates one.

• TSV for git: tables and loc files can also be kept as RPFM's TSV text (<file>.tsv, <file>.loc.tsv), which diffs and merges in git. They open in the same editor, and the totalwar-pack task packs them as binary files at their own path without .tsv. totalwar.newTableFormat picks the format of new files.

• TotalWar: Copy Game Entity into the Mod… (also the copy button on a table in the Game Database view) copies a unit, building, effect bundle, and so on under a new key. It copies:

  • the entity's own row;
  • the rows whose key contains its key (a unit's land_units row, ...);
  • the link rows that tie it to other things (recruitment permissions, unit sets, the buildings that recruit it), with a new id;
  • its texts.

  Rows it only refers to (factions, castes, armour types) stay shared. A preview lists the tables; uncheck the ones you don't want. The rows go into !!!<mod> files in the mod's pack/db/<table>/ and pack/text/db/.

Decoding tables needs an RPFM schema. It is downloaded from rpfm-schemas daily (or with TotalWar: Update DB Schema), and a copy ships with the extension as a fallback. Point totalwar.dbSchemaPath at RPFM's schemas folder to use your own.

Mod checks

In a mod project, the Problems view checks the mod's tables and loc files against the game and the mod list (totalwar.modDiagnostics, or run TotalWar: Check Mod DB Tables, Loc Files and Asset Paths). It reports:

• table versions older than the game's, which crash the game. TotalWar: Migrate DB Table to the Game's Version rewrites the table; it is also in the Explorer's context menu;
• references to keys that don't exist;
• repeated keys;
• new rows without loc text.

Lua IntelliSense

Completion, signatures and documentation for the game's script library: cm, core, bm, the campaign and battle managers, and about 2,700 other documented functions. They are generated from CA's own doc comments in the game's scripts and regenerated after a game update.

• core:add_listener completes the game's event names.
• In any Lua string, DB keys complete ("wh_main_emp_inf_sw → wh_main_emp_inf_swordsmen, showing the table it is in). Known keys are Ctrl+clickable to open their row (totalwar.dbCompletion).

Run TotalWar: Set Up Lua IntelliSense, which is offered once in a mod project. It uses the Lua extension (sumneko.lua, installed on request) and sets its workspace settings (Lua.runtime.version 5.1, Lua.workspace.library).

Packing and dependencies

The totalwar-pack task builds a .pack from a folder and installs it into the game. Mods can depend on Steam Workshop items, other packs, or other mods you develop; see Mods that depend on other mods.

Using it with an existing mod

To start from a mod you only have as a .pack (yours, or one to learn from), run TotalWar: Create Project from Pack… (also in the Explorer's context menu of .pack files): it makes a new project, like Create Mod Project…, with the pack's files in its pack folder. TotalWar: Import Pack into Project… unpacks a pack into the open project, asking whether to overwrite the files it already has. DB tables and loc files come out in the format of totalwar.newTableFormat (binary, or TSV).

Open your mod's folder and press F5. Without a launch.json, the extension finds the game through Steam and starts it. Every debug session installs the debugger mod shipped with the extension into the game's data folder and lists it in the mod list file, so the debugger always matches the extension.

To customise the launch, create a launch.json (Run and Debug → "create a launch.json file" → "Total War Lua"):

{
	"name": "Launch Total War",
	"type": "totalwar-lua",
	"request": "launch",
	"executable": "C:/Program Files (x86)/Steam/steamapps/common/Total War WARHAMMER III/Warhammer3.exe",
	"modListFile": "used_mods.txt",
	// optional: skip the frontend and load a save
	"arguments": "game_startup_mode campaign_load \"My Save.save\";",
	// optional: where your own Lua files are (the folder that contains "script")
	"sourceFilesPath": "${workspaceFolder}/pack",
	// optional: pack and install your mod before every launch
	"preLaunchTask": "Pack my mod"
}

// tasks.json
{
	"label": "Pack my mod",
	"type": "totalwar-pack",
	"packfilesDirectory": "pack",
	"modName": "my_mod.pack",
	"executable": "C:/Program Files (x86)/Steam/steamapps/common/Total War WARHAMMER III/Warhammer3.exe"
}

Starting the game yourself

Use "request": "attach" to connect to a game you start yourself, for example from the game's launcher. The game connects within a second, and you can attach before or after starting it. The launcher writes used_mods.txt itself, so the debugger mod has to be enabled there. Run TotalWar: Install Debugger Mod into Game once, then enable tw_lua_debugger in the launcher. Attaching also updates the installed debugger mod (the game uses the new copy after a restart) and warns when the mod list doesn't include it.

Launch options

Mods that depend on other mods

Declare dependencies in the totalwar-pack task, and use a mod list file that belongs to the project (not used_mods.txt):

// tasks.json
{
	"label": "Pack my mod",
	"type": "totalwar-pack",
	"packfilesDirectory": "pack",
	"modName": "my_mod.pack",
	"executable": "C:/Program Files (x86)/Steam/steamapps/common/Total War WARHAMMER III/Warhammer3.exe",
	"modListFile": "my_mod_mods.txt",
	"dependencies": [
		"2789857593",                                                  // Steam Workshop item id
		"some_mod.pack",                                                // a pack in the game's data folder
		"D:/mods/other_mod.pack",                                       // any pack file
		{ "folder": "../other_mod/pack", "modName": "other_mod.pack" } // a mod you develop: packed too
	]
}

Before every launch the task resolves the dependencies, packs folder dependencies, and rewrites my_mod_mods.txt completely: add_working_directory lines for Workshop items and other folders, then your mod, then the dependencies. The debug session adds the debugger mod after that. In Total War the mod listed first wins when two mods contain the same file, so your mod can override files of its dependencies. Use the same modListFile in the launch configuration.

Workshop dependencies download themselves. When an item, or an item it lists as required on its Workshop page, is not downloaded, the task asks to subscribe to it through Steam (Steam must be running). It waits for the download and lists the required items after yours. totalwar.autoSubscribeDependencies can set this to always or never. With never, a missing item stops the launch with a link to subscribe yourself. What Steam reports about required items is remembered for a day.

To debug into a dependency you develop yourself, add its project folder to your .code-workspace, and its files then open from there. Other dependencies' scripts are in the virtual source files (@mods/<pack>/).

Good to know

• When the game switches between frontend, campaign and battle, it rebuilds its Lua state. The debugger reconnects automatically and keeps your breakpoints. It does not respond during loading screens.
• Breakpoints slow Lua down. While at least one breakpoint is set, the debugger checks every line of script code (Lua 5.1 offers nothing cheaper), which makes scripts run several times slower. Without breakpoints there is no cost. Remove breakpoints you no longer need, especially during long AI turns.
• Only one debugger mod may be active. If the old TW Lua Debugger mod from the Steam Workshop is still enabled, the Debug Console says so: disable it or unsubscribe from it.
• If VS Code is closed or crashes, the game notices within a few seconds and carries on. A game paused at a breakpoint resumes by itself.
• The totalwar-pack task converts .tsv files (RPFM's format) to binary DB tables and loc files. RPFM writes floats in TSV with fewer digits, so a value like 0.90000004 comes back as 0.9.
• WARHAMMER III is the tested game. The other games in the totalwar.game setting (WARHAMMER II, THREE KINGDOMS, TROY, ROME II) are experimental and untested.

Thanks

The debugger is based on the devCAT Lua debugger. Pack files are read and written with RPFM.
