ArcGIS Pro Debugger Extension for Visual Studio Code

esri_logo

IMPORTANT This extension is designed for ArcGIS Pro 3.5 and greater.

About the Extension

This extension allows debugging ArcGIS Pro script tools (.atbx, .pyt) using Visual Studio Code (VSC).

Our aim is to provide developers a seamless workflow to attach VSC to the Python process live in ArcGIS Pro. This integration allows developers to leverage VSC's native Python debugging experience while developing script tools for ArcGIS Pro.

Features

Easily attach to ArcGIS Pro and stand-alone Python processes
Debug ArcGIS Pro Script Tools (.atbx) and Python Toolboxes (.pyt)
Debug code on the local machine or remotely on a different machine

Installation

Install the latest ArcGIS Pro Debugger extension from the VSC Marketplace:
After the extension is installed, you may need to reload Visual Studio Code to activate the extension.
You can do this by using the Command Palette (Ctrl+Shift+P) and selecting Developer: Reload Window.

Note: You may see popups indicating the directory where ArcGIS Pro is installed and the Python interpreter path. Additionally, an ArcGIS Pro Debugger item will appear in the status bar (bottom-right of VSC).

Getting Around

The ArcGIS Pro Debugger item in the status bar (bottom-right of VSC) is your main point of entry into controlling the ArcGIS Pro Debugger.

Hovering over the status bar icon reveals at-a-glance details about the current status of the debugger.

Click the help link on the top-right to get to the GitHub repository page you are reading from now.
Debug Mode: Indicates whether the ArcGIS Pro debug mode is currently On or Off.
Attachment Mode: Indicates whether the attachment mode is currently Process ID or Port. This will also show the process or port currently attached to when attached.

Clicking the ArcGIS Pro Debugger item in the status bar will reveal available commands (a dropdown will appear at the top-middle of VSC).

Attach Debugger to ArcGIS Pro: Attach the debugger to ArcGIS Pro. See local debugging and remote debugging for usage.
Remote Development: Set an SSH host and make an SSH connection to the remote machine. See remote debugging for usage.
Set Attachment Mode: Set the attachment mode to either Process ID or Port.
Set ArcGIS Pro Debug Mode: Set the ArcGIS Pro debug mode to either On or Off.

You can alternatively reach these commands from the command palette by pressing Ctrl+Shift+P and searching for the command by name. Tip: Each command is prepended by "ArcGIS Pro Debugger"; You can list all relevant commands by using "ArcGIS Pro Debugger" as the search term.

ArcGIS Pro Debug Mode

ArcGIS Pro debug mode configures ArcGIS Pro for debugging.

IMPORTANT
The ArcGIS Pro debug mode must be enabled in order to successfully attach to ArcGIS Pro.

Open VSC
Enable or Disable ArcGIS Pro Debug Mode
1. Click the ArcGIS Pro status bar icon and select Set ArcGIS Pro Debug Mode
2. Select "ON" if starting a new debugging session.
  Select "OFF" if ending an existing debug session.
NOTE: A checkmark bubble on the ArcGIS Pro icon in the status bar indicates the debug mode is currently ON. You can also use the hover tooltip to confirm the current state.

NOTE: Attaching to ArcGIS Pro will fail when "OFF".

NOTE: While "ON", you may notice a decrease in performance of ArcGIS Pro. We recommend always setting to "OFF" when you are done debugging.

Attachment Mode

The attachment mode configures the ArcGIS Pro debugger extension to attach using either a process id or a port.

Open VSC
Set the Attachment Mode
1. Click the ArcGIS Pro status bar icon and select Set Attachment Mode
2. Select "Process ID" if attaching using process id (default). Use this for local debugging.
3. Select "Port" if attaching using port. Use this for remote debugging.
NOTE: When attached, the hover tooltip of the ArcGIS Pro status icon will additionally show the process or port attached to:

IMPORTANT When attaching to ArcGIS Pro, the Python interpreter must first be initialized (a geoprocessing tool, the Python Window, or a notebook are opened). The debugger will not be able to attach until Python has initialized.

IMPORTANT When attaching using Port, the listening port must first be set on the remote Python process. See remote debugging for detailed steps.

Local Debugging

Debug your scripts on your own machine as you develop your script tool.

IMPORTANT

Requires VSC and the following additional extensions:

ArcGIS Pro Debugger

Requires ArcGIS Pro >= 3.5

Open your script tool in ArcGIS Pro:
1. Open your ArcGIS Pro project (.aprx)
2. Open the tool you are debugging
Open VSC
Open your project folder in VSC:
1. From the menu select File > Open Folder
NOTE: This will generate a .vscode folder in that workspace (if it is not already there). This folder will be populated with settings injected by the extension.

NOTE: You must have read/write-permission to this workspace. You may need to start VSC as administrator.
Open your script in VSC and set breakpoints:
1. In VSC, open the .py file associated with your .atbx, or the .pyt file, that you wish to debug.
2. Set breakpoints as needed.
NOTE: For script tools (.atbx), some additional setup might be required to debug execution code or validation code. No additional setup is required for python toolboxes (.pyt).
Set Python interpreter:
1. Press Ctrl+Shift+P to open the command palette
2. Choose Python: Select Interpreter
3. Select the currently active ArcGIS Python interpreter from the dropdown
NOTE: You can alternatively click the Python Interpreter element in the status bar (bottom) of VSC to select the interpreter.

NOTE: It could be arcgispro-py3 or a clone of it. Use the Package Manager in ArcGIS Pro to determine the active environment.
Set ArcGIS Debug Mode to "ON":
1. See Enable ArcGIS Pro Debug mode
Set Attachment Mode to Process ID
1. See Attachment Mode
Open the Debug Console:
1. From the menu choose View > Debug Console.
NOTE: The debug console opens. Debug messages from the ArcGIS Pro debugger extension will appear here
Attach to a running ArcGIS Pro instance using process ID:
1. Click the ArcGIS Pro status bar icon and select Attach Debugger to ArcGIS Pro
2. Select the ArcGIS Pro process from the dropdown
3. If you have multiple workspaces open in the Explorer tab, select the current workspace from the dropdown list.
NOTE: You will see attaching messages appear in the Debugger Console.

NOTE: Once attached, the Debug Toolbar should appear with a socket icon indicating that you are attached and debugging.

NOTE: If you have not opened a script tool (in ArcGIS Pro), attaching will fail. See If the extension fails to attach to ArcGIS Pro for more details.
Debugging your script:
1. Run the .atbx or .pyt script from ArcGIS Pro. The execution will pause at the breakpoints set in VSC, allowing you to debug the script.

Remote Debugging

Debug your script tool while it is running on another machine (of your coworker, for example). It may be easier to debug this way than attempting to reproduce the conditions in which the script is failing on your own machine.

IMPORTANT
On the local (client, initiating) machine

Requires VSC and the following additional extensions:

ArcGIS Pro Debugger

Requires OpenSSH Client

On the remote (host, target) machine

Requires VSC and the following additional extensions:

ArcGIS Pro Debugger

Requires OpenSSH Server

Requires ArcGIS Pro >= 3.5

Start the SSH service:
On the remote machine
1. Open the PowerShell as administrator
2. Run Start-Service sshd
NOTE: When you no longer need the SSH service, run Stop-Service sshd.

NOTE: You can run Get-Service -Name sshd to confirm service is running or stopped.

NOTE: Keep the PowerShell open, you will use it in the next step.
Find the hostname or IP address of your remote machine:
On the remote machine
1. Run the command hostname and note the name
  -or-
2. Run the command ipconfig and note the IPv4 address (formatted X.X.X.X, where each X is a number between 0 and 255).
NOTE: You will use either the host name or the IP address to make an SSH connection from your local to your remote machine.
Set up a remote listening port for debugpy in your ArcGIS Pro session:
On the remote machine
1. Open your ArcGIS Pro project (.aprx)
2. Open the Python Window
3. Run the following code:
```
import os, debugpy
debugpy.configure(python=os.path.join(sys.prefix, "python.exe"))
debugpy.listen(<port>)
```
NOTE: Replace <port> with an open port, for example, try 5678.

NOTE: If successful, you should see something like ('123.0.0.4', 5678) printed to the output. IMPORTANT: This is not the same as the IP address obtained earlier.
Open VSC on the local machine
Set Attachment Mode to "Port":
1. See Attachment Mode

  NOTE: The default configuration is Attach using Process ID, this is recommended for local debugging. For remote debugging, Attach using Port is recommended.
Add an SSH host (skip if this was already done previously):
On the local machine
1. Click the ArcGIS Pro status bar icon and select Remote Development
2. Select Add New SSH Host...
3. Enter the host name or IP address noted earlier and press enter
4. Choose an option for how SSH host configuration is stored (select first option if unsure)
Make an SSH connection:
On the local machine
1. Click the ArcGIS Pro status bar icon and select Remote Development
2. Select the remote machine from the list
3. Select the remote machine operating system from the list
NOTE: A separate VSC instance may open, continue there with all steps going forward
5. Enter the password and press enter

NOTE: Once connected, you will see SSH: <hostname/IP> on the lower left of the status bar. This instance (window) of VSC is now accessing the remote machine.
Ensure all necessary components are installed on remote machine
On the local machine
1. Click the Extensions tab and make sure the ArcGIS Pro Debugger extension components are installed on the SSH host
NOTE: From the Extensions tab you will see extensions installed on the remote machine under the SSH: <hostname/IP> - INSTALLED section. This tab will also show you extensions that are missing on the remote machine, make sure the required extensions are installed on the remote machine before proceeding (refer to the list of required extensions provided earlier). For the ArcGIS Pro Debugger extension item in the list, you may have to click on the Install in SSH: <hostname/IP> to install required components. Make sure the versions match between the local and remote machines.
Open the remote project folder:
On the local machine
**NOTE: You may skip this step if you already have a folder opened
1. From the menu select File > Open Folder. You can alternatively do this from the Explorer tab.
NOTE: The drop-down list shows folders on the remote machine
2. Select the project folder containing the scripts you want to debug 3. If prompted, re-enter the password 4. If prompted, decide whether you trust the authors of the workspace, and proceed accordingly (either accept or decline to open the workspace)

NOTE: From the Explorer tab you will see the directory tree of the remote machine. You can open and edit scripts remotely.

NOTE: This will generate a .vscode folder in that workspace (if it is not already there). This folder will be populated with settings injected by the extension.

NOTE: You must have read/write-permission to this workspace. You may need to start VSC as administrator.
Open your script:
On the local machine
1. In VSC, open the .py file associated with your .atbx, or the .pyt file, that you wish to debug.
2. Set breakpoints as needed.
NOTE: For script tools (.atbx), some additional setup might be required on the remote machine to debug execution code or validation code. No additional setup is required for python toolboxes (.pyt).
Set Python interpreter:
On the local machine
1. Press Ctrl+Shift+P to open the command palette
2. Choose Python: Select Interpreter
3. Select the currently active ArcGIS Python interpreter (of the remote machine) from the dropdown
NOTE: You can alternatively click the Python element in the status bar (bottom) of VSC to select the interpreter.

NOTE: It could be arcgispro-py3 or a clone of it. Use the Package Manager in ArcGIS Pro on the remote machine to determine the active environment.
Set ArcGIS Debug Mode to "ON":
1. See Enable ArcGIS Pro Debug mode
Open the Debug Console:
1. From the menu choose View > Debug Console.
NOTE: The debug console opens. Debug messages from the ArcGIS Pro debugger extension will appear here.

NOTE: Alternatively, you can also click on the ArcGIS Pro Debugger in the status bar to perform this action.
Attach to a running ArcGIS Pro instance using the debug port:
On the local machine
1. Click the ArcGIS Pro status bar icon and select Attach Debugger to ArcGIS Pro
2. Enter the port number you chose in an earlier step
3. If you have multiple workspaces open in the Explorer tab, select the current workspace from the dropdown list
NOTE: Once successfully attached, the debug toolbar should appear with a socket icon indicating that you are attached and debugging.

NOTE: Once attached, the Debug Toolbar should appear with a socket icon indicating that you are attached and debugging.

NOTE: Attaching will fail if the Python environment has not been initialized in ArcGIS Pro, as there is no Python.exe process to attach to, see https://pro.arcgis.com/en/pro-app/latest/arcpy/get-started/activate-an-environment.htm). If you followed the steps above, the interpreter will have already been initialized when you opened the Python Window.

NOTE: Alternatively, you can also click on the ArcGIS Pro Debugger in the status bar to perform this action.
Run your script tool in ArcGIS Pro:
On the remote machine
1. Open the tool you are debugging
2. Run the tool
NOTE: Execution of the tool will stop when a breakpoint is hit, in the UI on the remote machine it will appear to have gotten stuck.
Debugging your script:
On the local machine
1. The execution will pause at the breakpoints set in VSC, allowing you to debug the script.

Debug Script Tool Execution Code

If the script tool's execution code is embedded, you must first export the script from the toolbox to a Python file (.py) before you can debug it. Follow these steps to debug the script tool's execution code:

Open the script tool properties dialog and navigate to the Execution tab.
If the execution script is embedded, click the Export script to file button.
Continue debugging using the exported Python script file.
When you are done debugging, don't forget to embed the script again if it was previously embedded.

Debug Script Tool Validation Code

Python code in the script tool validation is embedded in the tool and needs to be copied to an external Python file (.py) to debug it. You can then open the Python file in your IDE and set breakpoints, attach the IDE to ArcGIS Pro, and run your script tool. Upon completion of code modification, copy the contents of the Python file back into the tool validation.

Open the script tool properties dialog and navigate to the Validation tab.
Copy the contents of the code editor into a Python file (validation_code.py in the sample code).

Replace the contents of the code editor in the Tool Properties dialog Validation tab with the sample code below:
In the following example, validation_code.py (contents not shown) contains the ToolValidator class and is saved to the same directory as the toolbox.

import os
import sys

sys.path.append(os.getcwd())  # directory containing module must be in `sys.path`
import validation_code

# the following code will reload the val.py module if it's modified
if 'validation_code' in sys.modules:
    import importlib
    importlib.reload(validation_code)

# ToolValidator should exist at the global scope
ToolValidator = validation_code.ToolValidator

Continue debugging using the validation_code.py file.
When you are done debugging, replace the contents of the code editor in the tool properties dialog Validation tab with those of your Python file (validation_code.py in the sample code) i.e. return things to their original state.

Troubleshooting

If the extension fails to attach to ArcGIS Pro

The extension fails to attach to ArcGIS Pro with the following error message:

"Timed out waiting for debug server to connect"

This can happen if Python has not yet initialized in ArcGIS Pro, or the previous session was improperly disconnected. Try these:

Make sure Python has initialized:
In ArcGIS Pro, Python loads as needed (when a geoprocessing tool, the Python Window, or a notebook are opened). The debugger will not be able to attach until Python has initialized. More precisely, if the Python environment has not been initialized in ArcGIS Pro, there is no Python.exe process to attach to, see https://pro.arcgis.com/en/pro-app/latest/arcpy/get-started/activate-an-environment.htm for more information on Python initailization.
1. Open the tool you are debugging, then try attaching again
NOTE: Opening any geoprocessing tool will cause Python to initialize. Alternatively, open either the Python Window or a Notebook.
Restart:
1. Close ArcGIS Pro
2. Wait ~15 seconds for locks to clear (alternatively, restart Windows)
3. Start ArcGIS Pro and try attaching again

If code using `subprocess` hangs

Code using subprocess hangs indefinitly while debugger is attached to ArcGIS Pro.

Use subprocess.communicate() with a timeout. This avoids potential blocking issues while reading out data.

For example, the following script uses subprocess to run another Python file and retreives the outputs:


import arcpy
import os
import sys
import subprocess
import time

MSG_STR_SPLITTER = " | "
CREATE_NO_WINDOW = 0x08000000

def execute_subprocess(script_path: str) -> str:
    inputs = [
        os.path.join(sys.exec_prefix, "python.exe"),
        script_path
    ]
    try:
        process = subprocess.Popen(
            inputs,
            stdout=subprocess.PIPE,
            stderr=subprocess.PIPE,
            creationflags=CREATE_NO_WINDOW,
            universal_newlines=True
        )
        # Read all output with timeout to prevent hanging
        output, error = process.communicate(timeout=30)
        msg = output.strip()
        if error:
            msg += "\n" + error.strip()
        return msg
    except subprocess.TimeoutExpired:
        process.kill()
        output, error = process.communicate()
        return f"{output.strip()}\nSubprocess timed out."

subproc_file = os.path.join(os.getcwd(), "subproc.py")
arcpy.AddMessage(execute_subprocess(subproc_file))

Issues

Find a bug or want to request a new feature? Please let us know by submitting an issue.

Contributing

Esri welcomes contributions from anyone and everyone. Please see our guidelines for contributing.

Licensing

Licensed under the Apache License, Version 2.0 (the "License"); you may not use this file except in compliance with the License. You may obtain a copy of the License at

http://www.apache.org/licenses/LICENSE-2.0

Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License.

A copy of the license is available in the repository's license.txt file.

ArcGIS Pro Debugger

Esri
