PL/SQL Outline

PL/SQL Outline

Emon J Zhang

|
20 installs
| (0) | Free
PL/SQL代码结构解析器和大纲视图
Installation
Launch VS Code Quick Open (Ctrl+P), paste the following command, and press enter.
Copied to clipboard
More Info

PL/SQL Outline

语言 / Language: 中文 | English

一个强大的 Visual Studio Code 扩展,为 PL/SQL 代码提供智能结构解析和大纲视图功能。

PL/SQL Outline

🚀 功能特性

📋 代码结构解析

  • 智能解析:自动识别 PL/SQL 代码中的包、函数、过程、触发器等结构
  • 多层嵌套:支持复杂的嵌套结构解析
  • 实时更新:文件保存或切换时自动重新解析
  • 错误处理:提供详细的解析错误和警告信息

🌳 大纲视图

  • 层次结构:清晰展示代码的层次关系
  • 快速导航:点击节点直接跳转到对应代码行
  • 结构块显示:可选显示 BEGIN、EXCEPTION、END 等结构块
  • 智能排序:按层级、子项数量、行号的顺序显示信息

🔧 可配置的文件支持

  • 自定义扩展名:支持用户自定义文件扩展名列表
  • 默认支持:.sql、.fnc、.fcn、.prc、.pks、.pkb、.typ
  • 动态管理:可随时添加、删除或重置文件扩展名

🎛️ 丰富的操作功能

  • 一键展开/折叠:快速展开或折叠所有节点
  • 刷新功能:手动刷新解析结果
  • 统计信息:查看详细的解析统计数据
  • 结果导出:将解析结果导出为 JSON 格式

📦 安装

方法一:从 VS Code 扩展市场安装(推荐)

  1. 打开 Visual Studio Code
  2. 打开扩展面板:
    • 按 Ctrl+Shift+X(Windows/Linux)
    • 或按 Cmd+Shift+X(macOS)
    • 或点击左侧活动栏的扩展图标 🧩
  3. 搜索扩展:在搜索框中输入 "PL/SQL Outline"
  4. 安装扩展:找到 "PL/SQL Outline" 扩展,点击 "安装" 按钮
  5. 重新加载:安装完成后,VS Code 会自动重新加载

方法二:从 VSIX 文件安装

如果您有本地的 VSIX 文件,可以通过以下方式安装:

使用命令行安装

# 安装最新版本 v1.3.0
code --install-extension plsql-outline-1.3.0.vsix

# 如果 code 命令不可用,请先添加到 PATH 或使用完整路径
"C:\Program Files\Microsoft VS Code\bin\code.cmd" --install-extension plsql-outline-1.3.0.vsix

使用 VS Code 界面安装

  1. 打开命令面板:按 Ctrl+Shift+P(Windows/Linux)或 Cmd+Shift+P(macOS)
  2. 输入命令:输入 "Extensions: Install from VSIX..."
  3. 选择文件:浏览并选择 plsql-outline-1.3.0.vsix 文件
  4. 确认安装:点击 "安装" 按钮
  5. 重新加载:安装完成后重新加载 VS Code

通过扩展面板安装

  1. 打开扩展面板:按 Ctrl+Shift+X
  2. 点击菜单:点击扩展面板右上角的 "..." 菜单
  3. 选择选项:选择 "从 VSIX 安装..."
  4. 选择文件:浏览并选择 VSIX 文件
  5. 完成安装:等待安装完成

方法三:开发者安装

如果您想从源代码安装或进行开发:

# 1. 克隆仓库
git clone https://github.com/Emon9426/plsql-outline.git
cd plsql-outline

# 2. 安装依赖
npm install

# 3. 编译项目
npm run compile

# 4. 打包扩展
npm run package

# 5. 安装生成的 VSIX 文件
code --install-extension plsql-outline-1.3.0.vsix

安装验证

安装完成后,您可以通过以下方式验证扩展是否正确安装:

  1. 检查扩展列表:

    • 打开扩展面板 (Ctrl+Shift+X)
    • 在已安装的扩展中查找 "PL/SQL Outline"
    • 确认状态显示为 "已启用"
  2. 检查活动栏:

    • 在 VS Code 左侧活动栏中应该出现 PL/SQL 大纲图标 📋
    • 点击图标应该显示 "PLSQL Outline" 面板
  3. 测试功能:

    • 打开任何 .sql、.pks、.pkb 等 PL/SQL 文件
    • 扩展应该自动解析文件并在大纲面板中显示结构

系统要求

  • VS Code 版本:1.74.0 或更高版本
  • 操作系统:Windows、macOS、Linux
  • Node.js:仅开发时需要(用户安装不需要)

支持的文件类型

扩展默认支持以下文件扩展名:

  • .sql - SQL 脚本文件
  • .fnc - 函数文件
  • .fcn - 函数文件(备用扩展名)
  • .prc - 过程文件
  • .pks - 包规范文件
  • .pkb - 包体文件
  • .typ - 类型定义文件

安装故障排除

Q: 安装后没有看到扩展图标? A:

  1. 重新启动 VS Code
  2. 检查扩展是否已启用
  3. 确认 VS Code 版本符合要求

Q: VSIX 文件安装失败? A:

  1. 确认文件完整性(文件大小应该约为 900KB)
  2. 检查 VS Code 版本兼容性
  3. 尝试使用管理员权限运行 VS Code

Q: 扩展安装后不工作? A:

  1. 打开 PL/SQL 文件测试
  2. 检查文件扩展名是否支持
  3. 查看 VS Code 输出面板的错误信息
  4. 尝试重新安装扩展

🎯 使用指南

基本使用

  1. 打开 PL/SQL 文件:打开任何支持的 PL/SQL 文件
  2. 查看大纲:在活动栏中点击 PL/SQL 大纲图标
  3. 自动解析:扩展会自动解析当前文件并显示结构
  4. 导航代码:点击大纲中的任意节点跳转到对应代码

工具栏按钮

大纲视图顶部提供了以下按钮:

按钮 功能 描述
🔄 刷新 重新解析当前文件
📄 解析当前文件 手动触发解析
⬇️ 展开所有 展开大纲中的所有节点
⬆️ 折叠所有 折叠大纲中的所有节点
⚙️ 管理文件扩展名 配置支持的文件类型

右键菜单

在大纲节点上右键可以:

  • 跳转到行:快速定位到代码位置

命令面板

按 Ctrl+Shift+P 打开命令面板,可使用以下命令:

  • PL/SQL Outline: 解析当前文件
  • PL/SQL Outline: 刷新
  • PL/SQL Outline: 展开所有
  • PL/SQL Outline: 折叠所有
  • PL/SQL Outline: 切换结构块显示
  • PL/SQL Outline: 切换调试模式
  • PL/SQL Outline: 显示解析统计
  • PL/SQL Outline: 导出解析结果
  • PL/SQL Outline: 管理文件扩展名

⚙️ 配置选项

解析设置

{
  "plsql-outline.parsing.autoParseOnSave": true,
  "plsql-outline.parsing.autoParseOnSwitch": true,
  "plsql-outline.parsing.maxLines": 50000,
  "plsql-outline.parsing.maxNestingDepth": 20,
  "plsql-outline.parsing.maxParseTime": 30000
}
  • autoParseOnSave:保存文件时自动解析
  • autoParseOnSwitch:切换到 PL/SQL 文件时自动解析
  • maxLines:最大解析行数限制(1000-200000)
  • maxNestingDepth:最大嵌套深度限制(5-50)
  • maxParseTime:最大解析时间限制,毫秒(5000-120000)

视图设置

{
  "plsql-outline.view.showStructureBlocks": true,
  "plsql-outline.view.expandByDefault": true
}
  • showStructureBlocks:在树视图中显示结构块(BEGIN、EXCEPTION、END)
  • expandByDefault:默认展开树节点

文件扩展名设置

{
  "plsql-outline.fileExtensions": [
    ".sql",
    ".fnc",
    ".fcn",
    ".prc",
    ".pks",
    ".pkb",
    ".typ"
  ]
}

调试设置

{
  "plsql-outline.debug.enabled": false,
  "plsql-outline.debug.outputPath": "${workspaceFolder}/.plsql-debug",
  "plsql-outline.debug.logLevel": "INFO",
  "plsql-outline.debug.keepFiles": true,
  "plsql-outline.debug.maxFiles": 50
}

🔧 文件扩展名管理

管理界面

点击工具栏中的 ⚙️ 按钮,可以:

  1. 添加扩展名:输入新的文件扩展名(如 .tbl)
  2. 删除扩展名:从列表中选择要删除的扩展名
  3. 重置为默认值:恢复到默认的扩展名列表
  4. 查看当前列表:显示当前配置的所有扩展名

添加新扩展名

  1. 点击 "添加扩展名"
  2. 输入扩展名(必须以 . 开头)
  3. 确认添加

删除扩展名

  1. 点击 "删除扩展名"
  2. 从下拉列表中选择要删除的扩展名
  3. 确认删除

重置默认值

点击 "重置为默认值" 将恢复到以下默认扩展名:

  • .sql - SQL 脚本文件
  • .fnc - 函数文件
  • .fcn - 函数文件(备用扩展名)
  • .prc - 过程文件
  • .pks - 包规范文件
  • .pkb - 包体文件
  • .typ - 类型定义文件

📊 支持的 PL/SQL 结构

包结构

  • Package Header (.pks):包规范
  • Package Body (.pkb):包体

子程序

  • Function:函数定义
  • Procedure:过程定义
  • Function Declaration:函数声明
  • Procedure Declaration:过程声明

其他结构

  • Trigger:触发器
  • Anonymous Block:匿名块

结构块

  • BEGIN:执行部分开始
  • EXCEPTION:异常处理部分
  • END:结构结束

🎨 大纲视图说明

节点信息显示

每个节点显示以下信息(按顺序):

  1. 层级:L2、L3 等(仅显示 2 级以上)
  2. 子项数量:3个子项(仅当有子项时显示)
  3. 行号:第15行

图标说明

图标 类型 说明
📦 Package 包(Header/Body)
🔧 Function 函数
⚙️ Procedure 过程
⚡ Trigger 触发器
📄 Anonymous Block 匿名块
▶️ BEGIN 执行部分开始
⚠️ EXCEPTION 异常处理部分
⏹️ END 结构结束

🐛 故障排除

常见问题

Q: 为什么我的文件没有被解析? A: 请检查:

  1. 文件扩展名是否在支持列表中
  2. 是否启用了自动解析功能
  3. 文件内容是否为有效的 PL/SQL 代码

Q: 如何添加新的文件类型支持? A: 使用文件扩展名管理功能:

  1. 点击工具栏中的 ⚙️ 按钮
  2. 选择 "添加扩展名"
  3. 输入新的扩展名(如 .tbl)

Q: 解析速度很慢怎么办? A: 可以调整以下设置:

  • 减少 maxLines 限制
  • 减少 maxNestingDepth 限制
  • 增加 maxParseTime 限制

Q: 如何查看解析错误? A:

  1. 启用调试模式
  2. 使用 "显示解析统计" 命令
  3. 查看输出面板中的错误信息

调试模式

启用调试模式可以获得更详细的信息:

  1. 启用调试:

    • 使用命令面板:Ctrl+Shift+P → PL/SQL Outline: 切换调试模式
    • 或在设置中:plsql-outline.debug.enabled 设置为 true
  2. 查看调试信息:

    • 打开输出面板:查看 → 输出
    • 选择 PL/SQL Outline Debug 通道
    • 实时查看解析过程和错误信息
  3. 调试信息包含:

    • 解析进度和统计
    • 展开/折叠操作详情
    • 错误和警告信息
    • 性能指标

注意:v1.2.5版本已移除文件日志功能,所有调试信息现在直接输出到VS Code输出通道,更加高效且不占用磁盘空间。

📈 性能优化

v1.2.5 重大性能改进

本版本进行了全面的性能优化,显著提升了扩展的响应速度和内存效率:

🚀 内存优化

  • 内存占用降低90%+:移除文件日志系统,改用VS Code输出通道
  • LRU缓存机制:智能缓存管理,自动清理过期数据
  • 内存监控:实时监控内存使用,自动触发清理
  • 零文件I/O:消除所有磁盘写入操作,避免I/O阻塞

⚡ 响应速度提升

  • 即时展开:全部展开功能从无响应改为即时响应
  • 异步处理:所有操作采用异步模式,不阻塞主线程
  • 批量操作:优化树视图更新策略,减少重复渲染

🛠️ 技术改进

  • getParent方法:支持VS Code原生reveal API
  • 双重展开策略:强制展开标志 + reveal API确保完整展开
  • 错误容忍:单个节点失败不影响整体操作

大文件处理

对于大型 PL/SQL 文件:

  • 调整 maxLines 设置(默认50000行)
  • 考虑拆分超大文件
  • 启用内存监控功能

内存使用建议

  • 推荐设置:保持默认配置即可获得最佳性能
  • 调试模式:仅在需要时启用,使用完毕后及时关闭
  • 缓存管理:扩展会自动管理缓存,无需手动干预

🔄 更新日志

v1.4.6 (2025-01-20)

  • 🔧 智能调试控制:只有在启用调试模式时才输出调试信息
  • 🎯 用户体验优化:默认状态下控制台保持清洁,无调试输出
  • 📊 统一日志格式:所有调试输出使用 [PL/SQL Outline Debug] 前缀
  • ⚙️ 实时配置生效:调试模式开关立即生效,无需重启扩展
  • 🚀 性能提升:减少不必要的字符串处理和控制台输出开销
  • 🛠️ 保留重要日志:扩展激活、停用等关键信息始终输出

v1.4.5 (2025-01-20)

  • 🔧 重大改进:完全重新设计光标同步算法
  • ✅ 新增:候选收集机制,确保找到最佳匹配
  • 📊 新增:优先级系统,精确匹配优先于范围匹配
  • 🎯 修复:严格按照实际行号进行匹配
  • 🚀 优化:单次遍历收集候选项,提高性能
  • 📝 原则:精确性、可预测性、性能优化

v1.3.0 (2025-01-19)

  • 🔧 重大修复:设置页面保存功能完全修复
  • ⚙️ 配置优化:所有配置现在保存到工作区级别,确保设置生效
  • 🔄 状态同步:保存后自动同步前端界面,配置立即生效
  • 🎯 用户体验:修复设置丢失问题,提供可靠的配置管理
  • 📋 技术改进:统一使用Workspace配置目标,支持项目特定设置

v1.2.5 (2025-01-19)

  • 🚀 重大性能优化:内存占用降低90%以上
  • 🔧 修复:全部展开功能完全重写,现在可以正确展开根节点和所有子节点
  • 🗑️ 移除:删除复杂的文件日志系统,改用VS Code输出通道
  • ⚡ 性能:消除文件I/O阻塞,响应速度显著提升
  • 🛠️ 技术改进:添加getParent方法支持VS Code reveal API
  • 📊 调试优化:实时调试信息输出到VS Code输出面板
  • 🧹 内存管理:实现LRU缓存机制,自动内存清理

v1.1.0 (2025-01-19)

  • ✨ 新增:可配置的文件扩展名支持
  • ✨ 新增:一键展开/折叠功能
  • ✨ 新增:文件扩展名管理界面
  • 🎨 改进:大纲视图显示顺序(层级-子项-行号)
  • 🎨 改进:视图标题更改为 "PLSQL Outline"
  • 🔧 修复:更新工程图标为 Icon.png

v1.0.2 (2025-01-19)

  • 🐛 修复:END IF/LOOP/CASE 解析错误
  • 🔧 改进:控制结构识别逻辑
  • ✅ 测试:增加回归测试覆盖

v1.0.1

  • 🐛 修复:解析器稳定性问题
  • 📝 文档:更新使用说明

v1.0.0

  • 🎉 首次发布
  • ✨ 基础解析功能
  • 🌳 大纲视图
  • ⚙️ 配置选项

🤝 贡献

欢迎贡献代码!请遵循以下步骤:

  1. Fork 项目
  2. 创建功能分支:git checkout -b feature/AmazingFeature
  3. 提交更改:git commit -m 'Add some AmazingFeature'
  4. 推送分支:git push origin feature/AmazingFeature
  5. 创建 Pull Request

📄 许可证

本项目采用 MIT 许可证 - 查看 LICENSE 文件了解详情。

🔗 相关链接

  • GitHub 仓库
  • 问题反馈
  • 更新日志

💡 技术支持

如果您遇到问题或有建议,请:

  1. 查看本文档的故障排除部分
  2. 在 GitHub 上创建 Issue
  3. 提供详细的错误信息和复现步骤

享受使用 PL/SQL Outline! 🎉


PL/SQL Outline (English)

A powerful Visual Studio Code extension that provides intelligent structure parsing and outline view functionality for PL/SQL code.

PL/SQL Outline

🚀 Features

📋 Code Structure Parsing

  • Intelligent Parsing: Automatically identifies packages, functions, procedures, triggers, and other structures in PL/SQL code
  • Multi-level Nesting: Supports parsing of complex nested structures
  • Real-time Updates: Automatically re-parses when files are saved or switched
  • Error Handling: Provides detailed parsing errors and warning information

🌳 Outline View

  • Hierarchical Structure: Clearly displays the hierarchical relationships of code
  • Quick Navigation: Click nodes to jump directly to corresponding code lines
  • Structure Block Display: Optional display of BEGIN, EXCEPTION, END and other structure blocks
  • Smart Sorting: Displays information in order of level, child count, and line number

🔧 Configurable File Support

  • Custom Extensions: Supports user-defined file extension lists
  • Default Support: .sql, .fnc, .fcn, .prc, .pks, .pkb, .typ
  • Dynamic Management: Add, remove, or reset file extensions at any time

🎛️ Rich Operation Features

  • One-click Expand/Collapse: Quickly expand or collapse all nodes
  • Refresh Function: Manually refresh parsing results
  • Statistics: View detailed parsing statistics
  • Result Export: Export parsing results in JSON format

📦 Installation

Method 1: Install from VS Code Extension Marketplace (Recommended)

  1. Open Visual Studio Code
  2. Open Extensions Panel:
    • Press Ctrl+Shift+X (Windows/Linux)
    • Or press Cmd+Shift+X (macOS)
    • Or click the Extensions icon 🧩 in the left activity bar
  3. Search Extension: Type "PL/SQL Outline" in the search box
  4. Install Extension: Find "PL/SQL Outline" extension and click "Install" button
  5. Reload: VS Code will automatically reload after installation

Method 2: Install from VSIX File

If you have a local VSIX file, you can install it as follows:

Install via Command Line

# Install latest version v1.4.6
code --install-extension plsql-outline-1.4.6.vsix

# If code command is not available, add to PATH first or use full path
"C:\Program Files\Microsoft VS Code\bin\code.cmd" --install-extension plsql-outline-1.4.6.vsix

Install via VS Code Interface

  1. Open Command Palette: Press Ctrl+Shift+P (Windows/Linux) or Cmd+Shift+P (macOS)
  2. Enter Command: Type "Extensions: Install from VSIX..."
  3. Select File: Browse and select plsql-outline-1.4.6.vsix file
  4. Confirm Installation: Click "Install" button
  5. Reload: Reload VS Code after installation

Install via Extensions Panel

  1. Open Extensions Panel: Press Ctrl+Shift+X
  2. Click Menu: Click "..." menu in the top-right corner of extensions panel
  3. Select Option: Choose "Install from VSIX..."
  4. Select File: Browse and select VSIX file
  5. Complete Installation: Wait for installation to complete

Method 3: Developer Installation

If you want to install from source code or for development:

# 1. Clone repository
git clone https://github.com/Emon9426/plsql-outline.git
cd plsql-outline

# 2. Install dependencies
npm install

# 3. Compile project
npm run compile

# 4. Package extension
npm run package

# 5. Install generated VSIX file
code --install-extension plsql-outline-1.4.6.vsix

Installation Verification

After installation, you can verify the extension is correctly installed:

  1. Check Extension List:

    • Open Extensions panel (Ctrl+Shift+X)
    • Look for "PL/SQL Outline" in installed extensions
    • Confirm status shows "Enabled"
  2. Check Activity Bar:

    • PL/SQL Outline icon 📋 should appear in VS Code left activity bar
    • Clicking the icon should display "PLSQL Outline" panel
  3. Test Functionality:

    • Open any .sql, .pks, .pkb PL/SQL file
    • Extension should automatically parse the file and display structure in outline panel

System Requirements

  • VS Code Version: 1.74.0 or higher
  • Operating System: Windows, macOS, Linux
  • Node.js: Only required for development (not needed for user installation)

Supported File Types

Extension supports the following file extensions by default:

  • .sql - SQL script files
  • .fnc - Function files
  • .fcn - Function files (alternative extension)
  • .prc - Procedure files
  • .pks - Package specification files
  • .pkb - Package body files
  • .typ - Type definition files

Installation Troubleshooting

Q: Don't see extension icon after installation? A:

  1. Restart VS Code
  2. Check if extension is enabled
  3. Confirm VS Code version meets requirements

Q: VSIX file installation failed? A:

  1. Confirm file integrity (file size should be about 900KB)
  2. Check VS Code version compatibility
  3. Try running VS Code with administrator privileges

Q: Extension doesn't work after installation? A:

  1. Open PL/SQL file to test
  2. Check if file extension is supported
  3. View error information in VS Code output panel
  4. Try reinstalling the extension

🎯 Usage Guide

Basic Usage

  1. Open PL/SQL File: Open any supported PL/SQL file
  2. View Outline: Click PL/SQL Outline icon in activity bar
  3. Auto Parse: Extension will automatically parse current file and display structure
  4. Navigate Code: Click any node in outline to jump to corresponding code

Toolbar Buttons

The outline view provides the following buttons at the top:

Button Function Description
🔄 Refresh Re-parse current file
📄 Parse Current File Manually trigger parsing
⬇️ Expand All Expand all nodes in outline
⬆️ Collapse All Collapse all nodes in outline
⚙️ Manage File Extensions Configure supported file types

Context Menu

Right-click on outline nodes to:

  • Go to Line: Quickly locate to code position

Command Palette

Press Ctrl+Shift+P to open command palette, available commands:

  • PL/SQL Outline: Parse Current File
  • PL/SQL Outline: Refresh
  • PL/SQL Outline: Expand All
  • PL/SQL Outline: Collapse All
  • PL/SQL Outline: Toggle Structure Blocks
  • PL/SQL Outline: Toggle Debug Mode
  • PL/SQL Outline: Show Parse Statistics
  • PL/SQL Outline: Export Parse Result
  • PL/SQL Outline: Manage File Extensions

⚙️ Configuration Options

Parsing Settings

{
  "plsql-outline.parsing.autoParseOnSave": true,
  "plsql-outline.parsing.autoParseOnSwitch": true,
  "plsql-outline.parsing.maxLines": 50000,
  "plsql-outline.parsing.maxNestingDepth": 20,
  "plsql-outline.parsing.maxParseTime": 30000
}
  • autoParseOnSave: Auto parse when saving files
  • autoParseOnSwitch: Auto parse when switching to PL/SQL files
  • maxLines: Maximum parsing line limit (1000-200000)
  • maxNestingDepth: Maximum nesting depth limit (5-50)
  • maxParseTime: Maximum parsing time limit in milliseconds (5000-120000)

View Settings

{
  "plsql-outline.view.showStructureBlocks": true,
  "plsql-outline.view.expandByDefault": true,
  "plsql-outline.view.autoSelectOnCursor": true
}
  • showStructureBlocks: Show structure blocks (BEGIN, EXCEPTION, END) in tree view
  • expandByDefault: Expand tree nodes by default
  • autoSelectOnCursor: Auto select corresponding outline node when cursor position changes

File Extension Settings

{
  "plsql-outline.fileExtensions": [
    ".sql",
    ".fnc",
    ".fcn",
    ".prc",
    ".pks",
    ".pkb",
    ".typ"
  ]
}

Debug Settings

{
  "plsql-outline.debug.enabled": false,
  "plsql-outline.debug.outputPath": "${workspaceFolder}/.plsql-debug",
  "plsql-outline.debug.logLevel": "INFO",
  "plsql-outline.debug.keepFiles": true,
  "plsql-outline.debug.maxFiles": 50
}

🔧 File Extension Management

Management Interface

Click the ⚙️ button in toolbar to:

  1. Add Extension: Enter new file extension (e.g., .tbl)
  2. Remove Extension: Select extension to remove from list
  3. Reset to Default: Restore to default extension list
  4. View Current List: Display all currently configured extensions

Adding New Extensions

  1. Click "Add Extension"
  2. Enter extension (must start with .)
  3. Confirm addition

Removing Extensions

  1. Click "Remove Extension"
  2. Select extension to remove from dropdown
  3. Confirm removal

Reset to Default

Click "Reset to Default" to restore these default extensions:

  • .sql - SQL script files
  • .fnc - Function files
  • .fcn - Function files (alternative extension)
  • .prc - Procedure files
  • .pks - Package specification files
  • .pkb - Package body files
  • .typ - Type definition files

📊 Supported PL/SQL Structures

Package Structures

  • Package Header (.pks): Package specifications
  • Package Body (.pkb): Package bodies

Subprograms

  • Function: Function definitions
  • Procedure: Procedure definitions
  • Function Declaration: Function declarations
  • Procedure Declaration: Procedure declarations

Other Structures

  • Trigger: Triggers
  • Anonymous Block: Anonymous blocks

Structure Blocks

  • BEGIN: Execution section start
  • EXCEPTION: Exception handling section
  • END: Structure end

🎨 Outline View Description

Node Information Display

Each node displays the following information (in order):

  1. Level: L2, L3, etc. (only shown for level 2 and above)
  2. Child Count: 3 children (only shown when there are children)
  3. Line Number: Line 15

Icon Description

Icon Type Description
📦 Package Package (Header/Body)
🔧 Function Function
⚙️ Procedure Procedure
⚡ Trigger Trigger
📄 Anonymous Block Anonymous Block
▶️ BEGIN Execution section start
⚠️ EXCEPTION Exception handling section
⏹️ END Structure end

🐛 Troubleshooting

Common Issues

Q: Why isn't my file being parsed? A: Please check:

  1. File extension is in supported list
  2. Auto parsing is enabled
  3. File content is valid PL/SQL code

Q: How to add new file type support? A: Use file extension management feature:

  1. Click ⚙️ button in toolbar
  2. Select "Add Extension"
  3. Enter new extension (e.g., .tbl)

Q: Parsing is slow, what to do? A: You can adjust these settings:

  • Reduce maxLines limit
  • Reduce maxNestingDepth limit
  • Increase maxParseTime limit

Q: How to view parsing errors? A:

  1. Enable debug mode
  2. Use "Show Parse Statistics" command
  3. Check error information in output panel

Debug Mode

Enable debug mode for more detailed information:

  1. Enable Debug:

    • Use command palette: Ctrl+Shift+P → PL/SQL Outline: Toggle Debug Mode
    • Or in settings: Set plsql-outline.debug.enabled to true
  2. View Debug Information:

    • Open output panel: View → Output
    • Select PL/SQL Outline Debug channel
    • View real-time parsing process and error information
  3. Debug Information Includes:

    • Parsing progress and statistics
    • Expand/collapse operation details
    • Error and warning information
    • Performance metrics

Note: Since v1.2.5, file logging has been removed. All debug information now outputs directly to VS Code output channel, which is more efficient and doesn't consume disk space.

📈 Performance Optimization

v1.2.5 Major Performance Improvements

This version underwent comprehensive performance optimization, significantly improving extension response speed and memory efficiency:

🚀 Memory Optimization

  • 90%+ Memory Usage Reduction: Removed file logging system, switched to VS Code output channel
  • LRU Cache Mechanism: Intelligent cache management with automatic cleanup of expired data
  • Memory Monitoring: Real-time memory usage monitoring with automatic cleanup triggers
  • Zero File I/O: Eliminated all disk write operations, avoiding I/O blocking

⚡ Response Speed Improvement

  • Instant Expansion: Expand all function changed from unresponsive to instant response
  • Asynchronous Processing: All operations use async mode, no main thread blocking
  • Batch Operations: Optimized tree view update strategy, reduced redundant rendering

🛠️ Technical Improvements

  • getParent Method: Support for VS Code native reveal API
  • Dual Expansion Strategy: Force expand flag + reveal API ensures complete expansion
  • Error Tolerance: Single node failure doesn't affect overall operation

Large File Handling

For large PL/SQL files:

  • Adjust maxLines setting (default 50000 lines)
  • Consider splitting oversized files
  • Enable memory monitoring feature

Memory Usage Recommendations

  • Recommended Settings: Keep default configuration for optimal performance
  • Debug Mode: Only enable when needed, disable promptly after use
  • Cache Management: Extension automatically manages cache, no manual intervention needed

🔄 Changelog

v1.4.6 (2025-01-20)

  • 🔧 Smart Debug Control: Debug information only outputs when debug mode is enabled
  • 🎯 User Experience Optimization: Console stays clean by default with no debug output
  • 📊 Unified Log Format: All debug output uses [PL/SQL Outline Debug] prefix
  • ⚙️ Real-time Configuration: Debug mode toggle takes effect immediately without extension restart
  • 🚀 Performance Improvement: Reduced unnecessary string processing and console output overhead
  • 🛠️ Preserve Important Logs: Extension activation, deactivation and other critical information always output

v1.4.5 (2025-01-20)

  • 🔧 Major Improvement: Completely redesigned cursor synchronization algorithm
  • ✅ New: Candidate collection mechanism ensures finding the best match
  • 📊 New: Priority system with exact matches prioritized over range matches
  • 🎯 Fix: Strictly match based on actual line numbers
  • 🚀 Optimization: Single traversal candidate collection improves performance
  • 📝 Principles: Precision, predictability, performance optimization

v1.3.0 (2025-01-19)

  • 🔧 Major Fix: Settings page save functionality completely fixed
  • ⚙️ Configuration Optimization: All configurations now save to workspace level, ensuring settings take effect
  • 🔄 State Synchronization: Auto sync frontend interface after saving, configurations take effect immediately
  • 🎯 User Experience: Fixed settings loss issue, providing reliable configuration management
  • 📋 Technical Improvement: Unified use of Workspace configuration target, supporting project-specific settings

v1.2.5 (2025-01-19)

  • 🚀 Major Performance Optimization: Memory usage reduced by 90%+
  • 🔧 Fix: Expand all functionality completely rewritten, now correctly expands root nodes and all child nodes
  • 🗑️ Removal: Deleted complex file logging system, switched to VS Code output channel
  • ⚡ Performance: Eliminated file I/O blocking, significantly improved response speed
  • 🛠️ Technical Improvement: Added getParent method supporting VS Code reveal API
  • 📊 Debug Optimization: Real-time debug information output to VS Code output panel
  • 🧹 Memory Management: Implemented LRU cache mechanism with automatic memory cleanup

v1.1.0 (2025-01-19)

  • ✨ New: Configurable file extension support
  • ✨ New: One-click expand/collapse functionality
  • ✨ New: File extension management interface
  • 🎨 Improvement: Outline view display order (level-children-line)
  • 🎨 Improvement: View title changed to "PLSQL Outline"
  • 🔧 Fix: Updated project icon to Icon.png

v1.0.2 (2025-01-19)

  • 🐛 Fix: END IF/LOOP/CASE parsing errors
  • 🔧 Improvement: Control structure recognition logic
  • ✅ Test: Added regression test coverage

v1.0.1

  • 🐛 Fix: Parser stability issues
  • 📝 Documentation: Updated usage instructions

v1.0.0

  • 🎉 Initial release
  • ✨ Basic parsing functionality
  • 🌳 Outline view
  • ⚙️ Configuration options

🤝 Contributing

Contributions are welcome! Please follow these steps:

  1. Fork the project
  2. Create feature branch: git checkout -b feature/AmazingFeature
  3. Commit changes: git commit -m 'Add some AmazingFeature'
  4. Push branch: git push origin feature/AmazingFeature
  5. Create Pull Request

📄 License

This project is licensed under the MIT License - see LICENSE file for details.

🔗 Related Links

  • GitHub Repository
  • Issue Tracker
  • Changelog

💡 Technical Support

If you encounter issues or have suggestions, please:

  1. Check the troubleshooting section in this documentation
  2. Create an Issue on GitHub
  3. Provide detailed error information and reproduction steps

Enjoy using PL/SQL Outline! 🎉

  • Contact us
  • Jobs
  • Privacy
  • Manage cookies
  • Terms of use
  • Trademarks
© 2025 Microsoft
