ElenixOS Toolkit

ElenixOS Toolkit is a VS Code extension for ElenixOS and embedded-device development. The current implementation focuses on the Native headless Simulator workflow.

The Simulator remains a normal desktop process while its LVGL output is displayed in a VS Code Webview.

Current capabilities

• Native ElenixOS Simulator in headless mode
• LVGL framebuffer display in a VS Code Webview
• Direct WebSocket framebuffer streaming with latest-frame replacement
• Pointer and hardware-button input forwarding
• Automatic Webview connection during Native debugging
• Webview reuse and reconnection after Simulator restart
• YMODEM sending of files and folders over UART
• An ESH-specific interactive terminal over UART
• macOS, Linux, and Windows support for the current Simulator workflow

Native Simulator Webview

Install/build this extension in VS Code, then open the tracked simulator.code-workspace from ElenixOS-Simulator. The Native debug configurations pass --headless and the Toolkit extension listens to VS Code's debug-session events. Pressing F5 therefore opens the Simulator Webview and waits for the Simulator's atomic .ready handshake; no manual command or fixed startup delay is needed.

ElenixOS: Open Simulator remains available for non-debug sessions. It starts the configured Native executable with a temporary IPC endpoint. Set elenixosToolkit.simulatorPath when the executable is outside the workspace.

The frame path is a direct connection:

Native Simulator WebSocket server -> Webview Canvas

The Simulator owns a loopback WebSocket server and advertises its ephemeral endpoint in the atomic .ready marker. Toolkit only manages the process/debug session and passes that tokenized URL to the Webview; framebuffer bytes do not pass through the Extension Host or Webview.postMessage(). The URL is bound to 127.0.0.1 and contains a per-session random token. The existing Native IPC endpoint remains available for compatibility and control, but is not used for Webview frame transport. This works on macOS, Linux, and Windows.

The first-version WebSocket frame packet is one binary message containing only the complete raw RGB565 framebuffer. The Webview dimensions are fixed by the document bootstrap:

width  = 390
height = 450
stride = width * 2
format = RGB565 little-endian
payload = stride * height raw bytes

This deliberately avoids copying the framebuffer just to prepend per-frame metadata.

The Webview sends presented only after the frame has been drawn. The Native server allows at most one frame in flight and replaces its pending frame with the newest one, so a slow Webview cannot create a latency queue. Pointer input is sent as small JSON control messages on the same WebSocket and is injected directly into the Simulator's existing LVGL input path.

YMODEM file transfer

Connect the target device's UART and run ElenixOS: Send File or Folder with YMODEM (UART) from the Command Palette. Toolkit asks for the device receive path, clears the current ESH command line, and automatically sends the command ymodem recv <path> before starting the transfer.

Toolkit selects the UART port and baud rate, then sends a CRC-16 YMODEM batch. For a folder or multiple files, use an existing directory as the ESH receive destination; the YMODEM header preserves each folder's relative path. The Previously selected files and folders are available from the YMODEM history list, where each entry shows its file name and full path. The Simulator is not used as the transport for this feature.

The default UART is 921600 baud, 8N1. YMODEM data packets use the standard 1K STX format. The host writes each complete packet without artificial chunk pacing and waits for the serial driver's drain completion before waiting for the receiver's ACK. Adjust elenixosToolkit.ymodemWriteChunkSize and elenixosToolkit.ymodemWriteChunkDelayMs; set both to 0 when the receiver has adequate buffering or hardware flow control.

The ESH terminal and YMODEM share one physical UART session inside Toolkit. Starting a transfer while the terminal is open does not require closing or reopening it. Toolkit temporarily disables terminal input and hides UART output while YMODEM owns the protocol, then restores the terminal automatically when the transfer finishes or fails. Input typed during this period is discarded rather than sent after the transfer.

The device UART must use the same 921600 8N1 settings. Toolkit cannot change a target firmware UART configured at another rate; keep the setting synchronized before starting a transfer.

The YMODEM progress notification shows the cumulative transfer rate and automatically formats it as B/s or KB/s.

On completion, Toolkit reports the file size, elapsed time, effective rate, data-block count, retransmissions, data-block NAKs, and timeouts. A standard YMODEM NAK has no reason code, so a data-block NAK is a CRC/block-validation rejection counter rather than proof of a CRC-only error.

While a transfer is active, the status bar provides Pause/Resume and Terminate controls. Pause takes effect at the next packet boundary; Terminate cancels the YMODEM session and releases the UART.

Toolkit does not query or estimate device filesystem capacity before sending; the receiver determines whether the destination has enough space.

ESH Serial Terminal

Connect the target device's debug UART and run ElenixOS: Open ESH Terminal from the Command Palette. Toolkit lists the available UART ports and uses elenixosToolkit.uartBaudRate (921600 by default). The terminal is a native VS Code pseudoterminal: ESH owns command editing, history, cursor movement, echo, and command execution, while VS Code handles ANSI/VT terminal rendering, scrollback, copy/paste, keyboard input, and resizing.

The last successfully connected UART port and baud rate are remembered according to elenixosToolkit.uartMemoryMode. window keeps the configuration only in the current VS Code window; persistent stores it across VS Code restarts and workspace reopenings. If the remembered port is unavailable, Toolkit returns to the normal UART selection flow.

Run ElenixOS: Switch ESH Terminal Port to reconnect the existing terminal to another device. The ESH terminal and YMODEM can use the same UART session. While YMODEM is active, Toolkit disables terminal input until the transfer completes. Closing the terminal or the extension releases the shared UART handle.

IPC format

The compatibility IPC stream uses a 16-byte big-endian header:

magic[4] = EOS1
version : u16 = 1
type    : u16 (HELLO=1, FRAME=2, INPUT=3, HELLO_ACK=4)
length  : u32
sequence: u32

FRAME contains width, height, stride, format (1 = rgb565-le) followed by raw RGB565 bytes. The WebSocket stream intentionally has no per-frame IPC header: each binary message is exactly one complete framebuffer. The first version sends the full 390x450 framebuffer. Both transports replace/drop old frames instead of accumulating latency.

Development

npm install
npm run compile
npm run test:ymodem
npm run benchmark:ymodem

The extension implementation is split across src/simulatorManager.ts, src/ipc.ts, src/simulatorWebview.ts, and src/debugIntegration.ts rather than being concentrated in extension.ts.
