StackScope

VS Code extension for debugger-backed memory inspection.

Overview

StackScope is a VS Code extension for memory inspection during debug sessions. It uses DAP to read memory and resolve expressions/addresses/registers, and renders a virtualized grid with hex/decoded columns. Built for low-level workflows like stack debugging, byte-change tracking, and navigation between memory and execution context.

Features

• Memory reads via DAP readMemory.
• Virtualized grid with hex/decoded columns.
• Workspace-persisted presets (save/delete).
• Quick targets for $pc, $sp, $lr.
• Read-only register panel.
• Configurable register sets.
• Call stack/disassembly navigation in editor-tab.
• Changed-byte highlighting across runs.
• Workspace-scoped view state persistence.

Tech Stack

• TypeScript 5.9
• React 18
• VS Code Extension API (^1.110.0)
• Esbuild (bundle)
• ESLint 9

Getting Started

Requirements:

• VS Code ^1.110.0
• Active debug session
• Adapter support for readMemory and evaluate

Basic flow:

1. Start debugging and pause execution.
2. Open StackScope: Open Memory View.
3. Enter target (e.g. 0x20000000, $sp, &myVar) and press Go.
4. Adjust columns, unit size, formats, and total size in Settings.
5. Use register panel and register set selector.
6. Open StackScope: Open Call Stack (Editor Tab) to navigate frames and disassembly.

Development Workflow

pnpm install
pnpm run compile

For local debugging, use Run Extension in .vscode/launch.json.

Available Scripts

Project Structure

.
├─ src/
│  ├─ debug/
│  ├─ domain/
│  ├─ host/
│  ├─ protocol/
│  ├─ shared/
│  ├─ test/
│  └─ webview/
├─ docs/
├─ .github/
├─ .vscode/
├─ dist/
├─ out/
├─ esbuild.js
├─ eslint.config.mjs
├─ tsconfig.json
└─ package.json

Documentation

• Start here: docs/README.md
• Quick usage: docs/getting-started.md
• Architecture: docs/architecture.md
• UI behavior: docs/ui-behavior.md
• Rendering internals: docs/rendering.md
• Protocol/API: docs/protocol-api.md
• Code structure: docs/code-structure.md
• Development: docs/development.md
• Known constraints: docs/known-constraints.md
• Contributing: docs/contributing.md
• Roadmap: docs/roadmap.md
• Changelog guide: docs/changelog-guide.md

Contributing

Read docs/contributing.md and docs/development.md before proposing changes.

License

MIT License. See LICENSE.

Documentation Update / Changelog

• README restructured and expanded with overview, real features, stack, scripts, and structure.
• Badges and analytics updated for repo PoncheDeFrutas/StackScope.
• Documentation links aligned with docs/.
