PGlite Explorer

Browse and manage PGlite databases directly inside VS Code and Cursor. A visual database GUI that auto-detects PGlite databases in your workspace and lets you perform CRUD operations, run SQL queries, and inspect schemas -- all without leaving your editor.

Features

• Auto-detect databases -- Scans your workspace for PGlite data directories (PG_VERSION files), parses source code for new PGlite('./path') patterns, and supports manual configuration
• Create databases -- Initialize new PGlite databases from the UI via a folder picker
• Create tables -- Visual form with column definitions and full constraint support (Primary Key, Foreign Key, Unique, Check, Indexes) with live SQL preview
• Edit table structure -- ALTER TABLE operations through a visual diff-based editor: rename tables/columns, add/drop columns, change types, toggle nullable, manage constraints and indexes
• Drop tables -- Remove tables with a confirmation prompt
• Spreadsheet-like data grid -- View rows and columns with sorting, filtering, and pagination
• Inline editing -- Double-click any cell to edit; Enter to save, Escape to cancel
• Add rows -- Click "+ Add Row" to insert new records via a form respecting constraints
• Delete rows -- Select rows via checkboxes and bulk-delete them
• SQL editor -- Write and execute raw SQL queries with syntax-highlighted CodeMirror editor and results table
• Schema viewer -- Inspect column types, nullability, defaults, primary keys, constraints, and indexes
• Export -- Export table data as CSV or JSON
• Activity Bar -- Dedicated sidebar icon with a tree view of databases and tables for quick navigation
• Theme integration -- Adapts to VS Code's light and dark themes automatically

Supported Environments

• VS Code >= 1.75.0
• Cursor
• VS Codium (via Open VSX)

Installation

From VS Code Marketplace

1. Open VS Code
2. Go to Extensions (Ctrl+Shift+X / Cmd+Shift+X)
3. Search for "PGlite Explorer"
4. Click Install

From Open VSX (Cursor / VS Codium)

1. Open the Extensions view
2. Search for "PGlite Explorer"
3. Click Install

Or install from the command line:

# Cursor
cursor --install-extension EchEmLabs.pglite-explorer

# VS Codium
codium --install-extension EchEmLabs.pglite-explorer

From VSIX

1. Download the .vsix file from the GitHub Releases page
2. Open the Command Palette (Ctrl+Shift+P) and run Extensions: Install from VSIX...
3. Select the downloaded .vsix file

Usage

Opening the Explorer

From the Activity Bar (recommended):

1. Click the PGlite Explorer database icon in the left Activity Bar
2. The sidebar shows detected databases -- expand one to see its tables
3. Click a database or table to open the full explorer panel

From the Command Palette:

1. Open the Command Palette (Ctrl+Shift+P)
2. Run PGlite Explorer: Open PGlite Explorer

The extension will automatically scan your workspace for PGlite databases. If none are found, you can:

• PGlite Explorer: Create New Database -- creates a fresh PGlite database in a folder you choose
• PGlite Explorer: Add Database Path -- opens a folder picker to add an existing database
• The Activity Bar welcome view also shows "Add Database" and "Refresh" buttons

Database Detection

The extension uses three strategies to find PGlite databases:

1. Auto-scan -- Finds PG_VERSION files in your workspace (excluding node_modules, .git, etc.)
2. Source parsing -- Scans .ts and .js files for new PGlite('./path') and PGlite.create('./path') constructor patterns
3. Manual config -- User-specified paths via the pgliteExplorer.databasePaths setting

Creating Databases

Click the + button next to the "Database" label in the sidebar, or run PGlite Explorer: Create New Database from the command palette. Select a parent folder and enter a name -- the extension initializes a new PGlite database directory automatically.

Creating Tables

Click the + button next to the "Tables" label in the sidebar. The Create Table dialog lets you:

• Define columns with name, type (grouped dropdown of PostgreSQL types), Primary Key, Not Null, Unique, and Default
• Add table-level constraints: composite primary keys, foreign keys (with ON DELETE/UPDATE actions), multi-column unique, check constraints
• Create indexes (regular and unique)
• Preview the generated SQL before creating

Editing Tables

Click the pencil icon next to any table in the sidebar to open the Edit Table dialog. You can:

• Rename the table or individual columns
• Add or drop columns
• Change column types, toggle nullable, modify defaults
• Add or drop constraints (Foreign Key, Unique, Check)
• Add or drop indexes
• Review all pending ALTER TABLE statements before applying

Dropping Tables

Click the x icon next to a table in the sidebar. A confirmation dialog appears before the table is dropped.

Working with Data

• Select a database from the sidebar dropdown
• Click a table name to browse its data
• Sort: Click column headers
• Filter: Use the filter bar above the grid (column, operator, value)
• Edit: Double-click any cell to modify its value
• Add: Click "+ Add Row" and fill in the form
• Delete: Check rows and click "Delete Selected"

Running SQL Queries

Switch to the SQL Editor tab to write and execute custom queries:

SELECT u.name, COUNT(o.id) as order_count
FROM users u
LEFT JOIN orders o ON u.id = o.user_id
GROUP BY u.id
ORDER BY order_count DESC;

Results appear in a table below the editor with execution time.

Inspecting Schema

Switch to the Schema tab to view:

• Column names, types, nullability, and default values
• Primary key indicators
• Constraints (PRIMARY KEY, UNIQUE, FOREIGN KEY, CHECK)
• Indexes with their definitions

Configuration

All settings are under the pgliteExplorer namespace.

Example Settings

{
  "pgliteExplorer.databasePaths": ["./my-local-db"],
  "pgliteExplorer.pageSize": 100,
  "pgliteExplorer.excludePatterns": [
    "**/node_modules/**",
    "**/.git/**",
    "**/dist/**"
  ]
}

Development

Prerequisites

• Node.js >= 18
• VS Code >= 1.75.0

Setup

git clone https://github.com/hanzlamateen/pglite-explorer.git
cd pglite-explorer
npm install
npm run build

Running & Debugging

1. Open the project in VS Code
2. Seed the sample databases (first time only):

   npm run seed


3. Press F5 to launch the Extension Development Host -- it opens the test/fixtures/sample-workspace/ folder which contains two pre-built PGlite databases (ecommerce-db and blog-db) with realistic test data
4. The PGlite Explorer Activity Bar icon will appear with both databases detected

Three launch configurations are provided in .vscode/launch.json:

• Run Extension -- Opens the sample workspace with seeded databases
• Run Extension (Current Workspace) -- Opens with whatever workspace you have
• Extension Tests -- Runs the Mocha test suite

Build Scripts

Project Structure

src/
  extension/              Extension host (Node.js)
    index.ts              activate() / deactivate()
    commands.ts           Command registrations
    config.ts             Configuration reader
    database/
      discovery.ts        Auto-scan, source parsing, manual config
      connection.ts       PGlite connection manager
      query.ts            Query execution service
    views/
      databaseTree.ts     Activity Bar tree view provider
    webview/
      provider.ts         Webview panel provider
  webview/                React webview (browser)
    index.tsx             Entry point
    App.tsx               Main app component
    components/           UI components (Sidebar, DataGrid, SqlEditor, CreateTableDialog, EditTableDialog, etc.)
    hooks/                React hooks
    styles/               CSS
  shared/                 Shared between extension and webview
    protocol.ts           Message types
build/                    esbuild build scripts
media/
  icon.svg                Activity Bar icon
test/
  suite/                  Mocha test suite
  fixtures/
    seed-databases.mjs    Script to generate sample databases
    sample-workspace/     Sample workspace for F5 debugging
.vscode/
  launch.json             Debug launch configurations
  tasks.json              Build tasks

Publishing

This project uses GitHub Actions for automated publishing to both the VS Code Marketplace and the Open VSX Registry.

Creating a Release

npm version patch  # or minor/major
git push origin --tags

The Release workflow will automatically build, test, package, and publish the extension.

Required GitHub Secrets

Contributing

1. Fork the repository
2. Create a feature branch (git checkout -b feature/my-feature)
3. Make your changes
4. Run tests (npm test)
5. Commit your changes
6. Push to the branch
7. Open a Pull Request

Acknowledgments

• PGlite by ElectricSQL -- lightweight WASM Postgres
• markdown-mermaid-zoom -- project template

License

MIT
