IBM iAgentX

Extends IBM i resources into VS Code AI agents — GitHub Copilot Chat, Claude Code, and IBM Bob.

IBM iAgentX is a VS Code extension that bridges your IBM i system (AS/400, iSeries) to AI coding agents via the Model Context Protocol (MCP). It reuses the active SSH connection from Code for IBM i — no second connection, no credentials to manage.

Ask Claude Code, GitHub Copilot, or IBM Bob to read source members, browse IFS files, query DB2, pull job logs, and run CL commands — all directly from the AI chat.

Features

• Read source members from any library/SPF
• List source physical files and their members
• Read and browse IFS files and directories
• Run read-only SQL against DB2 for i
• Retrieve job log messages
• Run read-only CL commands (allowlisted prefixes)
• Auto-configures Claude Code and VS Code on first activation
• Status bar with one-click reconnect

Requirements

• VS Code 1.99 or later
• Code for IBM i — installed and connected to an IBM i system
• Claude Code CLI (for MCP tool use outside VS Code)
• IBM Bob — for IBM i COBOL/RPG modernisation workflows

Build from source

Prerequisites: Node.js 18+ and npm.

git clone https://github.com/Duvaragesh/ibm-iagentx.git
cd ibm-iagentx
npm install
npm run package

This produces ibm-iagentx-<version>.vsix in the project root.

Installation

Install the .vsix file directly:

Extensions view → ⋯ → Install from VSIX… → select ibm-iagentx-0.1.0.vsix

Or from the command line:

code --install-extension ibm-iagentx-0.1.0.vsix

Setup

Claude Code (automatic)

On first activation IBM iAgentX writes its MCP server URL into ~/.claude.json automatically:

{
  "mcpServers": {
    "ibm-iagentx": {
      "type": "sse",
      "url": "http://127.0.0.1:41927/sse"
    }
  }
}

After installing, start a new Claude Code session — the IBM i tools will be discovered automatically.

GitHub Copilot Chat (automatic)

The extension writes to %APPDATA%/Code/User/mcp.json (Windows) or the platform equivalent, and registers itself via VS Code's MCP provider API. Copilot Chat picks this up without any manual configuration.

IBM Bob (automatic)

IBM Bob also reads mcp.json for MCP server discovery. No additional configuration is required — the same entry written for Copilot is picked up by Bob automatically.

Port conflict

The server starts on port 41927 by default and automatically tries the next 4 ports (41928–41931) if busy. The status bar shows the actual port. If the port changes between VS Code restarts, click the status bar item to refresh config and restart your Claude Code session.

To pin a port permanently:

"ibm-iagentx.preferredPort": 41927

Status Bar

Click the status bar item (or run IBM iAgentX: Reconnect from the Command Palette) to re-write the config files with the current port.

Available Tools

ibmi_connection_status

Check whether an IBM i connection is active. Safe to call at any time.

Input:  (none)
Output: { connected: true, host: "my-ibmi", user: "MYUSER", port: 22, connectionName: "DEV" }
        { connected: false }

ibmi_get_source_member

Retrieve the full source code of a member.

Input:  library (string), spf (string), member (string)
Output: { library, spf, member, memberType, content, lines }
Example: ibmi_get_source_member("DK", "QCLLESRC", "BATCHFTP")

ibmi_list_source_members

List members in a source physical file.

Input:  library (string), spf (string), filter? (string, * wildcard)
Output: { library, spf, total, members: [{ name, type, description, lastModified, lines }] }
Example: ibmi_list_source_members("DK", "QCLLESRC", "BATCH*")

ibmi_list_source_files

List all source physical files in a library.

Input:  library (string)
Output: { library, total, files: [{ name, description }] }
Example: ibmi_list_source_files("DK")

ibmi_get_ifs_file

Read a file from the IFS.

Input:  path (string)
Output: { path, content, size }
Example: ibmi_get_ifs_file("/home/MYUSER/scripts/deploy.sh")

ibmi_list_ifs_directory

List contents of an IFS directory.

Input:  path (string)
Output: { path, total, entries: [{ name, type, path, size, lastModified, owner }] }
Example: ibmi_list_ifs_directory("/home/MYUSER")

ibmi_run_sql

Run a read-only SQL query against DB2 for i.

Input:  query (string), maxRows? (number, default 100, max 1000)
Output: { rows, columns, rowCount }
Note:   Only SELECT, WITH (CTEs), and VALUES statements are permitted.
Example: ibmi_run_sql("SELECT * FROM QSYS2.SYSTABLES WHERE TABLE_SCHEMA = 'DK'")

ibmi_get_job_log

Retrieve job log messages via QSYS2.JOBLOG_INFO.

Input:  job? (string — NUMBER/USER/NAME format, or omit for current job)
Output: { total, messages: [{ id, text, severity, type }] }
Example: ibmi_get_job_log()
         ibmi_get_job_log("123456/MYUSER/QZDASOINIT")

ibmi_run_cl_command

Run a read-only CL command.

Input:  command (string)
Output: { output, stderr, exitCode }
Allowed prefixes (configurable): DSP, LST, WRK, CHK, PRT, DMP, RTV, QRY
Example: ibmi_run_cl_command("DSPFD FILE(DK/QCLLESRC)")
         ibmi_run_cl_command("WRKACTJOB")

Settings

Troubleshooting

Claude Code doesn't see the IBM i tools

1. Check the status bar — must show ✓ iAgentX :NNNNN
2. Click the status bar item to trigger a reconnect
3. Start a new Claude Code session after reconnect

No active IBM i connection error

Open Code for IBM i and connect: Ctrl+Shift+P → IBM i: Connect.

Port changed / wrong URL in config

Click the status bar item — the extension re-writes the config files with the current port. Then restart Claude Code.

ibmi_run_sql rejects a statement

Only SELECT, WITH (CTEs), and VALUES are allowed. DML and DDL are blocked.

CL command rejected

Add the verb prefix to ibm-iagentx.clAllowedPrefixes in VS Code settings.

Architecture

Claude Code (CLI)  /  GitHub Copilot Chat  /  IBM Bob
        │
        │  MCP over HTTP+SSE
        │  GET /sse  →  opens event stream
        │  POST /message?sessionId=N  →  JSON-RPC messages
        ▼
VS Code Extension Host  (IBM iAgentX)
  HTTP server  127.0.0.1:41927  (loopback only)
        │
        │  Code for IBM i public API
        ▼
halcyontechltd.code-for-ibmi  (existing SSH session)
        │
        ▼
IBM i System

The HTTP server binds to 127.0.0.1 only — never reachable from outside your machine.

Security

• All tools are read-only — no write, delete, or compile operations
• ibmi_run_sql rejects anything that is not SELECT/WITH/VALUES
• ibmi_run_cl_command enforces a configurable verb-prefix allowlist
• No credentials stored — piggybacks on Code for IBM i's SSH session
• MCP HTTP server binds to loopback (127.0.0.1) only

License

MIT

GitHub: Duvaragesh/ibm-iagentx
