CodeVisualizer

Real-time interactive flowcharts and dependency visualization for your code with AI-powered insights

CodeVisualizer is a powerful VS Code extension that provides two main visualization capabilities: function-level flowcharts for understanding code control flow, and codebase-level dependency graphs for analyzing project structure and module relationships.

https://github.com/user-attachments/assets/60b544ed-5149-4b79-b187-35325a3c41fe

https://github.com/user-attachments/assets/b323bbc8-5c1d-4865-aa12-3235706a33fc

Main Features

1. Function-Level Flowchart Generation

Transform individual functions into interactive, visual flowcharts to understand control flow, decision points, and execution paths.

Supported Languages:

Python
TypeScript/JavaScript
Java
C++
C
Rust
Go

Capabilities:

Multi-language Support: Parse and visualize functions across 7 programming languages
Interactive Visualization: Click nodes to navigate to code, zoom and pan
Multiple Views: Sidebar view and detachable panel windows
Semantic Analysis: Understand control flow, loops, exceptions, and async operations
Export Options: Export flowcharts as PNG, SVG, or PDF (coming soon)

2. Codebase Dependency Visualization

Analyze and visualize the entire codebase structure, showing module dependencies, file relationships, and project architecture.

Supported Languages:

TypeScript/JavaScript (.js, .jsx, .ts, .tsx, .mjs, .cjs)
Python (.py)

Capabilities:

Dependency Graph: Visualize import/require relationships between modules
Color-Coded Categories: Automatic classification of files into categories:
- Core: Logic, extract, schema, enrich modules
- Report: Report, transform, graph operations
- Config: Validate, config, CLI, utilities
- Tool: Tools, cache, special interfaces
- Entry: Entry points, common utilities
VSCode Theme Integration: Node backgrounds adapt to your VSCode theme (dark/light)
High-Contrast Visualization: Color-coded edges and strokes for easy identification
Interactive Navigation: Zoom, pan, and explore large dependency graphs
Folder Hierarchy: Subgraphs organized by directory structure

Usage:

Right-click on a folder in the Explorer → "Visualize Codebase Flow"
Or use Command Palette: "Visualize Codebase Flow"

Customization

9 Beautiful Themes: Monokai, Catppuccin, GitHub, Solarized, One Dark Pro, Dracula, Material Theme, Nord, Tokyo Night
Auto-refresh: Automatically update flowcharts on code changes
Performance Optimized: Efficient parsing with Tree-sitter (WASM)

AI-Powered Features (Function Flowcharts Only)

Note: AI features are only available for function-level flowcharts, not for codebase dependency visualization.

Smart Labels: AI-generated human-friendly node labels for function flowcharts
Multiple Providers: OpenAI, Gemini, Groq, Ollama (local), Anthropic
Intelligent Caching: Efficient caching to minimize API calls
Customizable Style: Concise, explanatory, or technical label styles
Multi-language Support: Generate labels in your preferred language

When enabled, AI labels replace technical node labels (like variable names, condition expressions) with more readable descriptions, making flowcharts easier to understand at a glance.

Developer Experience

Auto-refresh: Automatically update flowcharts on code changes
Performance Optimized: Efficient parsing with Tree-sitter (WASM)
Keyboard Shortcuts: Quick access to all features

How It Works

Function-Level Flowchart Pipeline

Parsing: Uses Tree-sitter parsers (compiled to WASM) to parse source code into Abstract Syntax Trees (AST)
Analysis: Traverses the AST to identify:
- Control flow structures (if/else, switch, loops)
- Function boundaries
- Exception handling
- Async operations
- Data operations (assignments, function calls)
IR Generation: Converts AST into an Intermediate Representation (IR) with nodes and edges
Visualization: Generates Mermaid diagram code from IR
Rendering: Renders interactive flowchart using Mermaid.js in webview

Codebase Dependency Analysis Pipeline

File Discovery: Scans workspace for supported files (TypeScript/JavaScript, Python)
Dependency Extraction: Parses import/require statements to identify module dependencies
Path Resolution: Resolves relative and absolute import paths to actual file locations
Graph Building: Constructs dependency graph with nodes (files) and edges (dependencies)
Classification: Categorizes files based on path patterns and naming conventions
Visualization: Generates Mermaid flowchart with color-coded nodes and edges
Rendering: Displays interactive dependency graph with zoom/pan capabilities

AI Label Generation (Function Flowcharts Only)

Note: This feature is only available for function-level flowcharts. Codebase dependency visualization uses file names and paths directly without AI enhancement.

Extraction: Extracts node labels from generated Mermaid code for function flowcharts
Caching: Checks cache for previously generated labels
Translation: Sends uncached labels to selected LLM provider
Replacement: Replaces technical labels with human-friendly descriptions
Storage: Caches results for future use

Privacy & Security

Data Handling

Code Analysis:

All code parsing happens locally on your machine
No code is sent to external servers for flowchart generation
AST parsing uses local Tree-sitter WASM parsers
Your source code never leaves your computer

AI Features (Optional):

When AI labels are enabled, only node labels (not full code) are sent to LLM providers
API keys are stored securely using VS Code's Secret Storage API
Caching minimizes API calls and reduces data transmission
You can use local models (Ollama) for complete privacy
All AI features are opt-in and disabled by default

What Data is Collected?

None. CodeVisualizer does not collect, store, or transmit:

Your source code
File contents
Personal information
Usage statistics
Telemetry data

Exception: Only when AI labels are explicitly enabled, minimal label text is sent to your chosen LLM provider (OpenAI, Gemini, etc.) for translation. This is completely optional and can be disabled at any time.

API Keys

API keys are stored using VS Code's secure Secret Storage
Keys are encrypted and stored locally
Never transmitted except to the selected LLM provider when making API calls
You can clear stored keys anytime via settings

Installation

From VS Code Marketplace

Open VS Code
Go to Extensions (Ctrl+Shift+X / Cmd+Shift+X)
Search for "CodeVisualizer"
Click Install

From Source

git clone https://github.com/DucPhamNgoc08/CodeVisualizer.git
cd CodeVisualizer
npm install
npm run compile

Then press F5 in VS Code to run the extension in a new window.

Usage

Generating Function Flowcharts

Open a file in your editor
Right-click → "CodeVisualizer: Open flowchart in new window"
- Or use Command Palette (Ctrl+Shift+P / Cmd+Shift+P)

Visualizing Codebase Dependencies

Right-click on a folder in the Explorer panel or use Command Palette: "CodeVisualizer: Visualize Codebase Flow"
Select "Visualize Codebase Flow"
The dependency graph will open in a new panel showing:
- All files in the selected folder and subfolders
- Import/require relationships between modules
- Color-coded file categories
- Interactive zoom and pan controls

Supported Languages

Function-Level Flowcharts

Language	Status
Python	Full Support
TypeScript/JavaScript	Full Support
Java	Full Support
C++	Full Support
C	Full Support
Rust	Full Support
Go	Full Support

Codebase Dependency Visualization

Language	Status	File Extensions
TypeScript/JavaScript	Full Support	`.js`, `.jsx`, `.ts`, `.tsx`, `.mjs`, `.cjs`
Python	Full Support	`.py`

Note: Codebase dependency analysis currently supports TypeScript/JavaScript and Python. Support for additional languages (Java, C++, C, Rust, Go) is planned for future releases.

Known Issues

Export functionality is currently in development
Large files (>10,000 lines) may take longer to parse
Codebase visualization is limited to TypeScript/JavaScript and Python projects

Contributing

Contributions are welcome! Please feel free to submit a Pull Request.

Fork the repository
Create your feature branch (git checkout -b feature/AmazingFeature)
Commit your changes (git commit -m 'Add some AmazingFeature')
Push to the branch (git push origin feature/AmazingFeature)
Open a Pull Request

License

This project is licensed under the MIT License - see the LICENSE file for details.

Support

Issues: GitHub Issues
Repository: GitHub

Made with dedication by Duc Pham Ngoc
