MD Viewer — VS Code Extension

Showcase

Monomer, ligand, solvent, and ions	Complexes, nucleotides, and multiple chains
Autoplay preview: monomeric system with a bound ligand, solvent/ion point-cloud rendering, and solvent visibility controls. Click for the full MP4.	Autoplay preview: larger structural systems with protein complexes, nucleotide traces, multiple chains, and local-context navigation. Click for the full MP4.

What it does

• Launch from Explorer on supported trajectory/topology files via Launch MD Viewer
• Resolve dataset pairings in a setup panel with override controls
• Render trajectories with residue-aware navigation and selection
• Show useful polymer traces for proteins and nucleic acids
• Support trajectories: .xyz, .xtc, .dcd, .trr, .nc, .rst7, .inpcrd, .mdcrd
• Support topologies: .pdb, .gro, .parm7, .prmtop
• Stream binary trajectories through metadata-first init + chunked frame requests

Molecular Semantics

• Protein traces use CA atoms.
• DNA/RNA traces use nucleotide backbone anchors, preferring P with sugar-backbone fallbacks such as C4', C3', and O3'.
• Residue selection highlights selected atoms, selected bonds/sticks, and nearby/local-context bonds when topology bond data is available.
• Ligands, ions, common solvent, and custom/nonstandard residues are routed separately so bulk solvent does not dominate navigation.

Amber-family notes:

• .parm7 and .prmtop are handled through the Amber topology bridge.
• .nc, .rst7, .inpcrd, and .mdcrd are handled through the Python bridge/runtime path.
• Topology and trajectory atom counts must match; the viewer rejects mismatched pairings rather than weakening topology semantics.

Install from VSIX

code --install-extension md-viewer-<version>.vsix

Install and First Run

After installing MD Viewer, the best first step is to check the runtime it will use.

1. Open the Command Palette with Ctrl+Shift+P.
2. Run MD Viewer: Run Dependency Diagnostics.
3. Review the result.
4. If runtime is not ready, run MD Viewer: Bootstrap Remote Python Runtime.
5. If needed, run MD Viewer: Select Python Interpreter.
6. Right-click a supported file and choose Launch MD Viewer.

What this means:

• The extension install adds commands/UI in VS Code.
• MD Viewer also needs a Python runtime for bridge/parsing tasks.
• In local windows, dependencies must exist locally.
• In Remote SSH windows, dependencies must exist on the remote host.

Diagnostics checks:

• selected Python interpreter
• required runtime packages (mdtraj, numpy, scipy, with netCDF4 recommended in some environments)
• runtime readiness in the current extension-host context

Bootstrap notes:

• MD Viewer: Bootstrap Remote Python Runtime prepares a dedicated Python environment (usually under ~/.venvs/mdviewer).
• Despite the name, it is most relevant for Remote SSH/HPC setup.
• It does not run simulations or modify your scientific data.
• If you already have a good interpreter, selecting it may be enough.

Success looks like:

• diagnostics pass
• a usable interpreter is selected
• you can launch supported files such as .pdb, .gro, .xtc, .dcd, .trr, .nc, .rst7, .inpcrd, .mdcrd, .parm7, .prmtop

If setup fails:

• re-run diagnostics and read the failing check
• select a different interpreter if needed
• run bootstrap in the same VS Code window/context where you will use MD Viewer
• on managed HPC, bootstrap may stop intentionally instead of forcing fragile source builds

Remote SSH / HPC Setup (Recommended)

1. Connect to your host with a Remote SSH VS Code window.
2. Run MD Viewer: Run Dependency Diagnostics.
3. If needed, run MD Viewer: Bootstrap Remote Python Runtime.
4. Run diagnostics again to confirm readiness.
5. If needed, run MD Viewer: Select Python Interpreter.
6. Launch a supported file from Explorer.

Notes:

• Prefer Python 3.10+ when available.
• Python 3.9 is legacy/best-effort on managed systems.
• Module/conda/mamba-based environments are fine; select the intended interpreter and rerun diagnostics.

See deployment guide:

• docs/INSTALLATION_LOCAL_REMOTE.md
• docs/REMOTE_UI_SMOKE_CHECKLIST.md
• docs/HPC_COMPUTECANADA_NIBI_TROUBLESHOOTING.md

Development Setup (Run from Source)

This section is only for developing MD Viewer from source. If you installed the extension from a VSIX or Marketplace package, use the installation and first-run steps above instead.

1. Install dependencies

cd vscode-md-viewer
npm install

2. Compile TypeScript

npm run compile

Or watch mode for iterative development:

npm run watch

3. Launch Extension Development Host

In VS Code:

• Open the vscode-md-viewer folder (or the repo root)
• Press F5 (or go to Run → Start Debugging)
• VS Code will open a new Extension Development Host window

4. Open a trajectory

In the Extension Development Host window:

1. Open a folder that contains one of your trajectory/topology datasets.
2. In the Explorer, right-click a supported file such as .xyz, .pdb, .gro, .xtc, .dcd, .trr, .nc, .rst7, .inpcrd, .mdcrd, .parm7, or .prmtop.
3. Click Launch MD Viewer.

The viewer panel opens and the trajectory begins at frame 1. Hit Play ▶ or press Space.

Controls

Extension file layout

vscode-md-viewer/
  package.json          VS Code extension manifest
  tsconfig.json         TypeScript config
  src/
    extension.ts        Activation & command registration
    commands/
      openMdViewer.ts   File read, parse, open webview
    parsing/
      xyz.ts            Multi-frame XYZ parser
    webview/
      getHtml.ts        Generates the webview HTML
  media/
    viewer.js           Three.js renderer & playback engine
    viewer.css          Dark-mode UI styles
  out/                  Compiled JS (created by tsc)

Current limitations

• Large systems may still require careful Python/runtime dependency setup
• Remote/HPC deployments require matching Python environment on remote extension host
• Marketplace publishing metadata may still evolve as release process stabilizes
