Dotnet Flow Tools (Beta)

Transform .NET code into clear, readable documentation

Dotnet Flow Tools is a Visual Studio Code extension that bridges the gap between technical .NET code and business understanding. It analyzes your .NET codebase and generates comprehensive documentation that explains what your code does in business terms, making it invaluable for developers, business analysts, and technical writers.

Dotnet Flow Tools

Why Not Just Use Copilot or Other Agentic Extensions?

Copilot analyzes code as intelligent text. This extension analyzes code as the compiler sees it.

While GitHub Copilot and similar AI tools excel at code generation and can answer questions across multiple files, they fundamentally treat your codebase as sophisticated text. This extension uses Microsoft.CodeAnalysis (Roslyn) to understand your code with true semantic analysis:

  • Precise Call Graphs: Traces exact execution paths through complex architectures, not text-based guesses
  • Runtime Pattern Resolution: Understands MediatR handlers, CQRS patterns, and polymorphic dispatch at the compiler level
  • Assembly-Aware Analysis: Focuses on your business logic, filtering out framework noise
  • Solution-Wide Compilation Context: Works with compiled semantic models, understanding cross-project dependencies that text analysis misses

The Result: Generate comprehensive business documentation that explains exactly what your technical processes do, with precision that's impossible from text-pattern analysis alone.

Features

Document Generation

Right-click any C# method → "Document This" to generate comprehensive business documentation with call chain analysis and domain-specific examples.

Code Flow Visualization

Right-click any C# method → "Trace This" to visualize execution flows:

  • All: Complete detailed flow including POCOs/DTOs
  • Methods Only: Filters to just method bodies
  • MediatR Only: Filters to only MediatR handlers

AI Model Support

Built-in VSCode models or AWS Bedrock with easy model switching.

Intelligent Processing

Smart chunking for large codebases, business context integration, and progress tracking.

Requirements

  • Mermaid: Install the Mermaid Chart extension to view the generated diagrams.
  • .NET 8+ Runtime or SDK: Required on all platforms to run the CLI via the dotnet host. Ensure dotnet is available in your PATH. Download: https://dotnet.microsoft.com/download/dotnet
  • .NET Solution: Your project must contain a .sln solution file
  • AI Provider: Either built-in VSCode language models or AWS Bedrock access

Multi-solution Workspaces

  • The extension scopes analysis to the workspace folder that contains your active file.
  • It resolves the correct solution by:
    1. Finding the nearest project file (.csproj/.fsproj) for the active file, then
    2. Matching that project to solution(s) within the same workspace folder.
  • If multiple solutions match (or no clear match is found), you’ll be prompted to select one. You can choose to remember your selection for that workspace folder.
  • Optional: Set dotnetFlow.defaultSolution (per workspace folder) to prefer a specific solution when multiple .sln files exist.
  • Generated documentation is saved under the matching workspace folder (e.g., .flowdocs/).

Getting Started

1. Install the Extension

Install "Dotnet Flow Tools" Extension

2. Configure AI Model

  1. Open the Command Palette (Ctrl+Shift+P / Cmd+Shift+P)
  2. Run DotnetFlowTools: Select AI Model
  3. Choose between built-in or Bedrock provider
  4. Select your preferred model
  • The above steps can also be done in the VS Code Settings UI

3. Set Business Context (Optional but Recommended)

  1. Open VS Code Settings (Ctrl+, / Cmd+,)
  2. Search for "dotnet flow"
  3. Add your business domain context in the Business Context field. This helps generate accurate examples in the docs.

4. Generate Your First Documentation

  1. Open a C# file in a .NET Core or .Net 6.0+ solution
  2. Place your cursor inside any method
  3. Right-click and select Dotnet Flow Tools > Document This
  4. Wait for the AI to generate comprehensive documentation

⚙️ Configuration

Extension Settings

Setting Description Default
dotnetFlow.model Combined provider and model (dropdown) (select)
dotnetFlow.businessContext Business domain context for better examples (empty)
dotnetFlow.awsProfile AWS profile for Bedrock provider default
dotnetFlow.awsRegion AWS region for Bedrock provider us-east-1
dotnetFlow.defaultSolution Preferred solution path or filename for this workspace folder when multiple .sln files exist (empty)

Business Context Examples

Provide context about your domain to get more relevant documentation:

E-commerce platform specializing in B2B wholesale operations.
Key concepts: purchase orders, supplier catalogs, bulk pricing,
inventory management, and multi-tier customer accounts.
Healthcare management system for clinics. Focus on patient
records, appointment scheduling, billing workflows, and
HIPAA compliance requirements.

Usage

Document This Command

  1. Navigate to any C# method in your solution
  2. Position your cursor inside the method
  3. Right-click and select Dotnet Flow Tools > Document This
  4. Review the generated markdown documentation that opens automatically

Trace Commands

Generate code execution traces for analysis:

  • Trace This: All - Complete detailed trace with all dependencies
  • Trace This: Methods Only - Simplified trace focusing on method calls
  • Trace This: MediatR Only - Specialized for MediatR request handlers

Context Menu Integration

When working with C# files, right-click anywhere to access:

Dotnet Flow Tools
├── Document This
└── Trace This
    ├── All
    ├── Methods Only
    └── MediatR Only

AI Model Provider Setup

Built-in Provider (Recommended for Getting Started)

  1. Run DotnetFlowTools: Select AI Model
  2. Choose "Built-in Provider"
  3. Select from available VSCode language models
  4. Start generating documentation immediately

⚠️ Token Usage with GitHub Copilot: This extension can consume significant tokens when using the "Document This" feature on methods which highly complex call chains. Here's what you need to know about GitHub Copilot's token usage:

For paid Copilot plans (Pro/Business/Enterprise): GPT-4o and GPT-4.1 have a 0× multiplier, so they don't consume premium requests from your budget. However, you're still subject to soft rate limits, token/throughput caps.

For Copilot Free tier: Every use still burns your limited premium requests, regardless of the model.

What this means in practice:

  • Copilot Pro/Business/Enterprise: Use GPT-4.1 or GPT-4o as much as you want without touching your premium request pool; you may just hit temporary rate limits if you hammer it.
  • Copilot Free: All requests still decrement your monthly allotment.
  • Org plans: There can also be org-wide throttles/policies.

When you need to worry: If you switch to models with a multiplier > 0 (e.g., Claude Sonnet/Opus, Gemini Pro), those will spend your premium requests. This is fine, just keep an eye on it.

💡 Tip: Set GPT-4.1 as your default, and only switch to the pricier models when you truly need their longer context or different reasoning style. Track your usage under Settings → GitHub Copilot → Usage & spending.

AWS Bedrock Provider

  1. Install AWS Toolkit: Install the AWS Toolkit for Visual Studio Code extension
  2. Configure AWS Credentials: Set up your AWS profile with Bedrock access
  3. Configure Extension:
    • Set dotnetFlow.awsProfile to your AWS profile name
    • Set dotnetFlow.awsRegion to your preferred region
  4. Select Model: Run DotnetFlowTools: Select AI Model and choose a Bedrock model

Supported Bedrock Models

  • Claude (Anthropic): Excellent for highly complex code

Troubleshooting

Common Issues

  • "No solution found": Ensure your workspace contains a .sln file
  • "Put cursor inside a method": Make sure your cursor is positioned within a C# method
  • "No AI provider available": Configure an AI model using the Select AI Model command
  • "AWS credentials not found": Set up AWS profile with Bedrock permissions

Getting Help

  • Check the VS Code Output panel for detailed error messages
  • Ensure your .NET solution builds successfully
  • Verify AI provider configuration and permissions

Output Examples

The extension generates markdown documentation that includes:

  • Business Purpose: What the method accomplishes in business terms
  • Process Flow: Step-by-step explanation of the business process
  • Key Dependencies: Important services and data sources involved
  • Business Rules: Logic and validation rules explained clearly
  • Example Scenarios: Real-world usage examples based on your business context

Changelog

See CHANGELOG.md for the full release history.

Enjoy transforming your .NET code into clear business documentation!
