AgentMux

Seven agents. One terminal flow. Plus any tmux you already have.

Run Claude Code, OpenAI Codex CLI, OpenCode, Hermes (Nous Research), pi (Earendil), Google Antigravity (agy) and Devin (Cognition devin) in persistent tmux sessions, switch between them instantly, and hand work from one agent to another from a single VS Code side-bar view.

The extension is deliberately workspace-scoped:

• the Claude tab controls only tmux_claude_<folder>;
• the Codex tab controls only tmux_codex_<folder>;
• the OpenCode tab controls only tmux_opencode_<folder>;
• the Hermes tab controls only tmux_hermes_<folder>;
• the pi tab controls only tmux_pi_<folder>;
• the Antigravity tab controls only tmux_agy_<folder>;
• the Devin tab controls only tmux_devin_<folder>;
• every existing session is accepted only when its tmux session_path matches the current VS Code workspace root;
• projects with the same folder name receive a stable path hash when needed, so one project can never attach to another project's tmux session.

The single exception is free mode, below: a tab you point at a tmux session by name. You named it, so it is shown wherever it lives — and in exchange AgentMux never creates, restarts, resumes over or cleans up that session.

Every agent survives VS Code restarts, Remote-SSH drops and local disconnects.

What the view does

It mirrors the selected tmux pane instead of opening another VS Code terminal:

• a persistent tmux control-mode client drives everything by default: no fork/exec per refresh, and tmux pushes an output notification the moment the active pane changes (a pipe-pane tap and classic polling are automatic fallbacks — claudeTmux.transport);
• each refresh fuses the frame and its cursor/size metadata into one atomic call, and small changes travel to the view as per-line deltas;
• the refresh loop is adaptive: hot while you type or output streams, slow when the pane is static, watchdog-only when push notifications are live;
• one ordered input pump merges pending keystrokes under backpressure, while bracketed paste preserves large UTF-8 input; a precomputed byte table eliminates per-keystroke allocation overhead;
• hardware-accelerated GPU cursor placement (translate3d) and sub-pixel font smoothing (-webkit-font-smoothing) keep typing jitter-free and text razor-sharp;
• native editor selection styling (::selection), tactile file path hover feedback, glassmorphism popup overlays, and slim themed scrollbars fit natively into VS Code;
• a tab appears only while that workspace's matching tmux session exists, and only for agents whose CLI is installed; tabs carry live state dots with zero-cost GPU compositor animations;
• the + menu starts or resumes an absent agent (past conversations are listed per workspace for Claude, Codex, OpenCode, Hermes and pi);
• each tab carries its agent's colour on the underline it already had, and swaps its label for a two-glyph mark once the side bar is too narrow to show one;
• Shift+Enter breaks the line instead of submitting (each agent's encoding was measured in a live pane; no ~/.tmux.conf change is needed);
• Cmd/Ctrl+click a path/file.js:42 in agent output to open it in the editor;
• Alt+Up recalls previously submitted prompts (reconstructed locally from your keystrokes, never from agent output);
• mouse wheel, scrollbar and Shift+PageUp / Shift+PageDown navigate history; large history captures render virtualized, so scrolling up never hitches;
• new output follows automatically only while you are at the bottom;
• switching tabs recycles row elements in place, painting warm cached frames instantly with zero DOM recreation stutter.

Requirements

Install these on the machine where the extension runs. Under Remote-SSH that is normally the remote host.

tmux -V
claude --version
codex --version
opencode --version
hermes --version
pi --version

• tmux 2.9 or newer;
• at least one agent CLI on PATH — Claude Code, OpenAI Codex, OpenCode, Hermes (Nous Research), pi (Earendil) or Google Antigravity (agy) — for its tab.

You may use any tab when only one agent CLI is installed. A free mode tab needs no CLI at all: it mirrors a tmux session you already have.

Build and install

From this repository:

npm run check
npm run package
code --install-extension claude-tmux-sidebar-0.16.0.vsix --force

Alternatively use VS Code: Extensions → … → Install from VSIX…, select the generated file, then run Developer: Reload Window.

For Remote-SSH, install the VSIX in the remote extension host from the connected window. tmux, claude and codex must be available on that same remote host.

The AgentMux icon appears in the Activity Bar. You can drag its view to the Secondary Side Bar; VS Code remembers the layout.

Daily workflow

1. Open a project folder in VS Code.
2. Open AgentMux. If no agent is running, choose one from the central launcher. Use + later to add the others.
3. Start or resume:
   • each agent lists its own past conversations for this folder, when its CLI exposes them (Claude, Codex, OpenCode, Hermes, pi);
4. Click the mirror and type. Switch visible tabs whenever you want; both tmux sessions continue running independently.
5. Scroll with the wheel or scrollbar. Use Shift+PageUp/PageDown from the keyboard. Plain PageUp/PageDown are still forwarded to the agent TUI.

The toolbar actions always target the selected tab:

Pair Mode

Pair Mode coordinates the agents sequentially and refuses a handoff while either side is detected as working:

1. Select the agent that currently owns the work and press ⇄.
2. Add optional details for the other agent. Nothing is sent until you press Create handoff.
3. If the other agent has no workspace tmux, the extension offers to start it.
4. AgentMux asks the source agent to author a standalone briefing specifically for the target: objective, completed work, files, decisions, tests, risks and the recommended next action.
5. Fresh Git facts are added separately. Choose Continue task, Review only or Review & Fix, then freely edit the complete message.
6. Only Send handoff delivers the reviewed message. By default the briefing is written to .claude/agentmux/handoff-<id>.md and only a short pointer is pasted into the target TUI; the target acknowledges by writing .claude/agentmux/ack-<id> (or printing the marker line if it cannot write files). On success it becomes the Pair Mode writer. If the best-effort acknowledgement is not observed, AgentMux offers manual acceptance or dismissal without ever resending. A delivered handoff even survives a VS Code restart (rehydrated from the workspace ledger as manual-accept only).
7. After a Review only / Review & Fix handoff completes, ↩ asks the reviewer to author a structured findings report and hands it back to the original author under the same acknowledgement rules.
8. Hand back with ⇄, release the lock with ◇, or audit everything in the ◷ Timeline.

Arbiter mode

⚖ (or AgentMux: Ask both agents) sends one question to two running agents in parallel — answers only, no file changes. Both replies are gathered through the .claude/agentmux channel and shown side by side; the answer you pick makes that agent the Pair Mode writer and tells it to proceed.

The briefing capsule now includes recent commits, capped real diff hunks, your task file (claudeTmux.handoffTodoFile), optional verify-command output (claudeTmux.handoffVerifyCommand, trust-gated) and best-effort conversation resume pointers, in addition to the Git status/stat facts.

The compact footer shows pane size, session uptime and agent state — plus, when available, token usage and turn count tailed from the CLI's own local transcript, the current tool while working, and the last turn's git delta (Δ3 +120−14). It also shows available history, attached tmux clients and capture lag when that lag is high enough to matter. All of it reuses existing snapshots and local file reads; nothing new runs on the live refresh path and nothing leaves your machine.

Agent state is no longer only a heuristic: managed launches install Claude Code lifecycle hooks, a Codex notify program and an OpenCode state plugin that stamp working / needs-input / done (and the current tool) into tmux pane options, which the extension already reads for free. A single consolidated status bar item mirrors the active agent everywhere in VS Code (every present agent in its tooltip, click to cycle focus), the view badge counts agents that finished or are waiting, and when a hidden agent asks a numbered question a notification offers its options as one-click answer buttons (explicit, identity-pinned, never automatic). Anyone attached to the tmux session from a real terminal sees the same facts on the tmux status line.

The lock coordinates input sent through this side bar; it cannot stop a turn that was launched outside the extension or prevent a user/process attached to the same tmux session elsewhere from editing files. Review only is an instruction to the agent, not an operating-system sandbox.

Shared .claude rules

With claudeTmux.codexReadClaudeRules enabled (the default), every Codex start, resume and restart receives a developer instruction to recursively discover and read all Markdown files below the workspace .claude directory before working. This includes .claude/CLAUDE.md and any other nested .md files. The extension does not copy or modify those rules, so .claude remains the single source of truth for both agents.

The bridge uses Codex's per-launch developer_instructions. If claudeTmux.codexArgs already defines that key, the bridge is skipped and the extension warns once instead of silently replacing the explicit value. An existing global Codex developer_instructions value is replaced for bridged launches; keep durable project constraints in .claude, or disable the bridge and compose the instruction yourself in codexArgs.

Codex is also started in Full Access by default. This was chosen for the requested workflow, but it disables Codex approvals and sandboxing. Turn off claudeTmux.codexFullAccess for repositories you do not fully trust.

Driving AgentMux from a script

Four commands take arguments and return values, so AgentMux can be driven from a keybinding, a task or another extension instead of only by hand:

Together they make send → wait for done → capture a three-line script. They obey exactly the rules the side bar does — the workspace check, the Pair Mode lock, the handoff freeze — and return the reason for a refusal (not-running, pair-locked, transaction-in-progress) rather than swallowing it.

A keybinding example:

{ "key": "ctrl+alt+t", "command": "claudeTmux.send",
  "args": { "agent": "claude", "text": "run the tests and summarize failures" } }

Agent CLI & MCP Bridge

AgentMux includes an embedded local IPC socket server and exposes a command-line interface and standard Model Context Protocol (MCP) server so that terminal scripts and agents themselves can inspect and drive neighboring agents across tmux panes:

CLI (agentmux)

The bundled agentmux binary communicates with the running AgentMux instance:

# List all active agents and their status
agentmux list

# Inspect detailed status, turns, and telemetry
agentmux status codex

# Read recent terminal output lines from an agent pane
agentmux read claude --lines 50

# Prompt an agent and atomically wait for completion. The wait also returns as
# soon as the agent stops to ask a question (reply carries "blocked": true);
# --until blocked waits for that dialog state only.
agentmux prompt codex "Run pytest and verify the test suite" --wait --until done

Model Context Protocol (MCP)

To let Claude Code, Codex, Cursor, or Antigravity interact with AgentMux as peers, add to your project's .mcp.json or global config:

{
  "mcpServers": {
    "agentmux": {
      "command": "node",
      "args": ["<path-to-agentmux>/bin/agentmux-mcp.js"]
    }
  }
}

Exposed MCP tools: list_agents, get_agent_status, read_agent_output, prompt_agent.

Git Worktree Isolation

When running multiple agents simultaneously on the same repository, enable claudeTmux.worktrees: true. Each agent will launch in its own isolated worktree (.agentmux/worktrees/<agent>) on branch agent/<agent>. Once an agent completes its feature, run AgentMux: Merge active agent Git worktree into current branch.

Native Agent Presets

Add first-class agent definitions for Aider, Goose, Cursor CLI, and Continue in one click via AgentMux: Add agent from preset… without writing custom regex or configuration.

Getting to the right agent

Clicking the status bar item goes to the agent that wants you when there is one, and only falls back to cycling.

Agent integrations

With claudeTmux.stateHooks on (the default), a managed launch wires each agent to report its true state instead of leaving it to screen heuristics: Claude Code lifecycle hooks, Codex's native hooks, an OpenCode plugin and a pi extension. Every one acts only on panes carrying AGENTMUX=1, so an agent you start yourself is untouched.

AgentMux: Agent integrations: show, install or remove… lists all of them — where each file lives, whether it is installed and up to date, and what it is for — with install, reinstall, remove and reveal. Content is compared, so a file left behind by an older version reads as out of date rather than silently doing the wrong thing. AgentMux: Remove agent integrations deletes them all in one step.

Codex is the one that needs a keypress: its hooks travel as -c launch arguments (never written to your config.toml) and Codex asks once to trust the command set — "N hooks need review before they can run", press t. Until you do, they stay inactive and Codex's notify program still reports done.

How AgentMux reads an agent's state

An agent that reports its own lifecycle is always believed first — that is what the integrations above are for. When there is no report, AgentMux reads the pane, and the question is never just does this phrase appear but where.

The pane is cut into regions, and every rule names the one it is matched against:

body is the one that matters most in daily use. Type "do you want to delete the old migrations?" at Claude and the phrase is in the tail — but it is in the prompt box, which body cuts out, so the tab does not claim the agent is asking you something when it is waiting for you.

A rule casts one of three verdicts. needs-input and working set the status; hold freezes it. Opening Claude's transcript with Ctrl+O covers the pane with chrome that describes itself and not the agent — before, the frame stopped changing and the decay timer walked a working agent down to idle behind it.

Rules are evaluated by priority, highest first (title 1100, hold 1000, needs-input 900, working 500), first match wins. An entry is one pattern, an array of patterns that must all match, or an object:

"claudeTmux.detectionRules": {
  "claude": {
    "working": [
      { "region": "foot", "match": "esc to interrupt" },
      { "region": "body", "match": "spinning", "not": ["· done \\d"] }
    ],
    "hold": [["select model", "esc to cancel"]],
    "title": { "working": ["^⠿"] }
  }
}

A provided list replaces the built-in one, so [] disables a noisy rule.

When the dot is wrong

AgentMux: Explain the active agent's state prints which signal won — the hook, a rule, or decay — the regions the current frame was cut into, and what every rule made of them: matched, missed by which pattern, vetoed by which guard, or matched but outranked.

A misfiring rule is usually gone by the time you look, so the same report runs offline:

tmux capture-pane -p -t '=tmux_claude_myproject:' > screen.txt

then AgentMux: Explain a captured screen against that file. It touches no tmux state, so it works on a screen captured on another machine or pasted into a bug report. The screens under test/screens/ are real captures used exactly this way by the test suite.

Free mode: any tmux, any agent, no release

The seven built-in agents are the ones AgentMux knows how to install, resume and introspect. Free mode covers everything else, through claudeTmux.customAgents, so a new CLI never has to wait for a new version of this extension. Two shapes:

"claudeTmux.customAgents": [
  // 1. A new agent AgentMux manages exactly like a built-in one.
  {
    "id": "aider",
    "label": "Aider",
    "command": "aider",
    "args": "--yes",
    "resume": { "latest": "aider --restore {args}" }
  },
  // 2. A tmux session YOU started, mirrored in a tab.
  { "id": "build", "label": "Build loop", "session": "my-build-loop" }
]

A launch entry (command) is a first-class agent: its own tmux session (tmux_<id>_<folder>, override with sessionPrefix), presence and status, input, handoffs, arbiter rounds, Pair Mode, preflight and cleanup. Add pane to adopt an instance you started outside AgentMux, detection for its TUI's prompts, resume templates ({args}, {id}) if its CLI can resume, accent and mark for its tab, and modEnter for the bytes it reads as a newline — "\\x1b[13;2u" or "\\x1b[27;2;13~", the two encodings the built-in agents use. Without one, Shift+Enter submits, as it did before.

A mirror entry (session) is the "free" one: the tab shows a tmux session AgentMux did not create. It is the only tab not tied to the workspace root — you named the session, so it is shown wherever it lives. In exchange, nothing destructive reaches it: AgentMux never creates, restarts or resumes over it, never offers it in bulk kill, and never lists it as a leftover to clean up. Killing it is possible from the single Kill command, which states plainly that AgentMux did not create it.

The easy path is the ＋ button at the end of the tab strip. Its menu lists the agents you can start or resume, then below a rule:

• Mirror a tmux session… — pick from your running tmux sessions and AgentMux writes the settings entry for you.
• Remove a custom agent… — shown only once you have one; removes the entry and leaves the tmux session running.

Both are in the command palette too, as AgentMux: Mirror an existing tmux session (free mode)… and AgentMux: Remove a custom agent…. The roster is built once at activation, so both offer a window reload.

If the mirror list comes back empty, there is genuinely nothing to add: sessions AgentMux already drives are filtered out, so a machine whose only tmux session is an agent tab has nothing left to offer. Start the session you want to mirror first, then run it again.

Settings

The existing claudeTmux.* namespace is retained so upgrades keep current user settings.

Scope and limits

• A workspace folder is required; the extension never falls back to $HOME.
• In a multi-root workspace, the first root is used.
• A free-mode mirror tab is the one exception to workspace scoping, by design; it is also the one tab AgentMux will not create, restart or clean up.
• The agent roster is assembled at activation, so a claudeTmux.customAgents edit takes effect after a window reload.
• With stateHooks off (or unmanaged launches), working, finished and needs input fall back to visual heuristics based on submitted input, pane changes and common prompts; they can occasionally be wrong.
• Codex's hooks stay inactive until you trust them once in the pane; the tab shows needs input while that prompt is up, and notify still reports done.
• A pane whose running command is an interpreter (node, python, …) is only recognised as an agent when its pane title identifies one, so an agent that neither names itself in the command nor sets a title — Hermes, measured — is not adopted unless AgentMux launched it.
• The control-mode client parks on a private _agentmux_ctl_<pid> session and rides along on the active agent session to receive push notifications; it is excluded from the footer's client count and cleans up after itself.
• Transcript telemetry parses the CLIs' local JSONL files, which are not a stable API; the chips silently disappear if a format changes.
• This is a terminal mirror, not a full PTY. Mouse input is not forwarded.
• Scrollback is bounded by claudeTmux.scrollbackLines and tmux's own history.
• Multi-line paste is sent raw and a newline may submit input.
• Pair Mode transfers a source-authored, target-specific snapshot and uses a best-effort terminal acknowledgement; it remains sequential and user-reviewed.
• A tab disappears when the agent TUI exits even if its tmux shell remains; the launcher can start the agent again in that workspace session.

See USER_GUIDE.md for troubleshooting and TESTING.md for the installation smoke test.
