TPTP Editor

TPTP Editor is a VSCode extension that provides a streamlined development environment for working with the TPTP language, a standard format used extensively in automated theorem proving and formal logic research.

Built by Daniel Li in collaboration with Dr. Geoff Sutcliffe, the creator of the TPTP library, the extension features full syntax highlighting for both CNF, FOF, THF, etc. formats, enabling clear visual structuring of axioms, hypotheses, and conjectures. It recognizes '.p' & '.s' problem files, supports pretty-printing and safe character escaping, and integrates directly with the SystemOnTPTP + SystemOnTSTP service, allowing users to author, submit, and view solver results without leaving the editor.

Designed for researchers, students, and logic developers. TPTP Editor enhances productivity and readability in formal logic workflows within the comfort of VS Code.

Features

- TPTP Language Features

• Syntax highlighting for .p and .s files
• Support for:
  • Single-line % comments
  • Block comments /* ... */
  • Quoted strings
  • Logical operators and quantifiers
  • $-prefixed system constants
  • TPTP directives like fof, cnf, thf, etc.
  • Various special characters (~, |, &, etc.)
• Clean and consistent token coloring across themes
• Real-time error diagnostics and checking

TPTP Extension Functionality

• Pretty-prints TPTP problem content inside the webview for readability
• Custom file icons for '.p' & '.s' files inside VS Code
• Automatically parses and extracts content for submission to theorem provers
• Import problems and solutions directly from the TPTP library
• Provides download support for solution outputs directly from the Webview
• Enables side-by-side comparison of problems and their solutions in VS Code
• Supports multiple TPTP problem domains and systems

Theorem Proving & Solution Processing

• Seamless integration with the SystemOnTPTP & SystemOnTSTP services for remote automated proving
• Supports selection from dozens of available theorem provers (e.g. E, Vampire, CVC5, iProver, Z3, etc.)
• Allows users to choose between TPTP format and native system output for flexibility in results
• Displays the raw and formatted problem & solution returned from the prover inside a dedicated Webview
• All syntax highlighting, Webview styling, and UI accents automatically adjust to the active VS Code color theme, ensuring visual consistency and accessibility across light, dark, and high-contrast themes.

• TPTP: Prove Problem
• Submit the currently open TPTP problem file to a selected theorem prover for evaluation and view results in a rich Webview interface.

• TPTP: Prove Problem Using Multiple Provers
• Run the problem against multiple supported provers simultaneously (e.g. Vampire, E, CVC5) to compare solver behaviors, timings, and proof outputs side-by-side.

• TPTP: Process Solution
• Extract and format a single selected solution for the current problem, with support for downloading or viewing clean, readable output directly in the editor.

• TPTP: Process Solution Using Multiple Processors
• Automatically collect and process all available solution variants for a problem from SystemOnTPTP, allowing users to review results across different systems.

Requirements

No dependencies required — just install and start editing .p or .s files.

Design and Tradeoffs

• The extension needs an internet connection for integration with SystemOnTPTP but provides access to 50+ maintained provers and 500+ problems. Users do not need to install anything locally.
• Implemented TextMate grammar for syntax highlighting, but does not include go-to-definitions, but also file navigation in TPTP problems is not necessary since they are stand alone problems in single files.
• Chose webview panel for viewing instead of terminal to enhance user experience and it has an impact on side by side comparisons and also has downloadable results.

Extension Settings

This extension does not contribute any custom settings.

Release Notes

0.0.1

Initial release with base syntax support for TPTP problem files.

0.0.2

Updated logo and extension image. Changed README.

0.0.3

Added Change Log. Removed Known Issues.

0.0.4

Implemented Multiline reading. Added file icon.

0.0.5

Added pretty-printing. Fixed newline issue.

0.0.6

Implemented problem prover inside editor context menu.

0.0.7

Added continute to option for TPTP Format and IDV Image.

0.0.8

Added solving for problems using multiple provers.

0.0.9

Added processing solutions using multiple provers. Added importing problems and solutions.

0.1.0

Refined readme and fixed image path.

0.1.1

Added importing problems and solutions.

0.1.2

Edited description in package.json.

0.1.3

Changed the lists of tools/systems for each of the proving and solving interfaces.

0.1.4

Fixed issue where when invoked from the Command Palette, no URI is passed

0.1.5

Added dynamic loading of ATP systems from tptp.org by using fetch

For TPTP Language

The Thousands of Problems for Theorem Provers (TPTP) World is the established infrastructure used by the Automated Theorem Proving (ATP) community for research, development, and deployment of ATP systems. The TPTP format is widely used in logic and automated reasoning. Learn more at http://www.tptp.org

Development Notes

• Grammar implemented via a tmLanguage.json file
• Uses TextMate scopes compatible with popular VS Code themes
• Lexer/grammar derived from an existing BNF TPTP grammar
• Actively tested against a large sample of problems from the official TPTP problem library
• Webview-based prover runner panel implemented with custom form UI to prove theorems
• All is open-source! :)

Enjoy using TPTP Editor!
