Codescape — Code City Visualizer

Codescape transforms your Java and Python codebase into a living isometric 3D city right inside VS Code. Each building is a class or interface; its height reflects complexity (methods + fields). Watch the city update in real time as you edit your code.

Features

Area	Status
Java parsing (Tree-sitter)	Implemented — classes, interfaces, inner classes, methods, fields, constructors
Python parsing (Tree-sitter)	Implemented — classes, module nodes, methods, fields, inheritance, inner classes
Relationship graph	Implemented — extends/implements/field/constructor dependencies
Incremental live updates	Implemented — file watcher emits partial-state messages
Explorer sidebar view	Implemented — `Codescape City` in the Explorer panel
Panel views	Implemented — side panel, bottom panel, and editor tab
Pan/rotation controls	Planned — zoom-only camera controls in current release

Getting Started

Install Codescape from the VS Code Marketplace.
Open a Java or Python project folder.
Open the Codescape City view in the Explorer sidebar, or run one of the commands below from the Command Palette (Cmd/Ctrl+Shift+P).

The city renders automatically on first open and updates incrementally as you save files.

Commands

Command	Description
`Codescape: Open in Side Panel`	Open the city view in the side panel
`Codescape: Open in Bottom Panel`	Open the city view in the bottom panel
`Create Panel`	Open the city view in an editor tab
`Codescape Scan`	Manually trigger a workspace scan

Known Limitations

Pan and rotation are not yet implemented — use scroll to zoom.
Large workspaces with thousands of classes may affect rendering performance.

Documentation

Development

Clone the repo and build locally:

npm install
npm run compile

Launch the extension host with F5 in VS Code, then open one of the example workspaces:

examples/java-city
examples/python-city

Other dev commands:

npm run watch   # watch + rebuild on change
npm run lint    # ESLint
npm test        # compile + lint + VS Code extension tests
npm run package # produce a .vsix for local install

Contributing

Keep runtime message contracts synchronized between extension/watcher/frontend/types.
Prefer small, test-backed PRs — parser, relations, watcher, and layout all have existing test suites.
Update Usage Guide and Architecture Reference when behavior changes.

License

GNU GPL-3.0. See LICENSE.
