Cascade - Hierarchical Work Item Tracker

Visual tracking for hierarchical work items with automatic state propagation. Track projects, epics, features, stories, and tasks in a unified TreeView with real-time progress updates.

Perfect for AI-assisted development workflows, Agile planning, and complex project management.

Features

📊 Hierarchical Work Item Visualization

View your entire project structure at a glance with support for six levels of hierarchy:

Project → Epic → Feature → Story → Phase → Task

🔄 Automatic State Propagation

Child status updates automatically roll up to parent items. Update a task's progress, and watch it propagate through stories, features, epics, and projects instantly.

📈 Real-Time Progress Tracking

Visual progress percentages for all parent items
Color-coded status icons that adapt to your VSCode theme
Instant updates via file system watchers

🎯 Status-Based Workflow

Track items through their complete lifecycle:

Not Started → In Planning → Ready → In Progress → Completed → Archived
Support for Blocked status to identify bottlenecks

🔍 Registry-Based Organization

All work items are managed through a centralized work-item-registry.json file with individual state.json files for tracking progress and status.

🎨 Theme-Aware UI

Icons and progress indicators automatically adapt to your VSCode theme (Dark+, Light+, and custom themes).

Installation

From VS Code Marketplace

Open VSCode
Go to Extensions (Ctrl+Shift+X / Cmd+Shift+X)
Search for "Cascade"
Click Install

From VSIX File

code --install-extension cascade-[version].vsix

Then reload VSCode: Ctrl+Shift+P → "Developer: Reload Window"

Quick Start

1. Create Directory Structure

Create a .cascade/ directory in your workspace root:

mkdir .cascade

2. Create Work Item Registry

Create .cascade/work-item-registry.json:

{
  "version": "1.0.0",
  "last_updated": "2025-01-14T10:00:00Z",
  "work_items": {
    "P0001": {
      "id": "P0001",
      "type": "Project",
      "title": "My Awesome Project",
      "status": "in-progress",
      "parent": null,
      "path": "P0001.md",
      "created": "2025-01-14",
      "updated": "2025-01-14"
    },
    "E0001": {
      "id": "E0001",
      "type": "Epic",
      "title": "Core Features",
      "status": "in-progress",
      "parent": "P0001",
      "path": "E0001-core-features/E0001.md",
      "created": "2025-01-14",
      "updated": "2025-01-14"
    }
  }
}

3. Create Work Item Files

Create markdown files with optional content:

mkdir -p .cascade/E0001-core-features
echo "# Core Features Epic" > .cascade/E0001-core-features/E0001.md
echo "# My Awesome Project" > .cascade/P0001.md

4. View in Cascade

Click the Cascade icon in the Activity Bar (left sidebar) to see your work items!

Usage

Viewing Work Items

Click the Cascade icon in the Activity Bar
Expand/collapse hierarchy levels
Click any item to open its markdown file

Updating Progress

When using with CARL (Coding Assistant for Rapid Launch) or manually:

Edit state.json files for parent items (Stories, Features, Epics, Projects)

Update child status in the parent's state.json:

{
  "id": "S0001",
  "status": "in-progress",
  "children": {
    "T0001": {
      "status": "completed",
      "progress": 100
    }
  }
}

Cascade automatically propagates changes up the hierarchy

Commands

Cascade: Refresh - Manually refresh the TreeView
Cascade: Validate Hierarchy - Check for structural issues
Cascade: Toggle Archived Items - Show/hide archived items

Requirements

Visual Studio Code 1.80.0 or higher
A workspace with .cascade/ directory structure

Extension Settings

This extension contributes the following settings:

Setting	Default	Description
`cascade.refreshDebounceDelay`	300	Refresh delay in milliseconds
`cascade.enableGitOperationDetection`	true	Enable git operation detection
`cascade.gitOperationDebounceDelay`	500	Git operation debounce delay (ms)

Known Issues

File watchers may not detect changes in very large hierarchies (1000+ items)
State propagation can take a few seconds for deeply nested structures

See GitHub Issues for current bugs and feature requests.

Contributing

Contributions are welcome! This project is licensed under AGPL-3.0, which requires that any modifications shared publicly (especially as a service) must also be open-sourced.

Please see CONTRIBUTING.md for guidelines.

Roadmap

[ ] Visual drag-and-drop for status changes
[ ] Inline editing of work item titles
[ ] Search and filter functionality
[ ] Export to various formats (CSV, JSON, Markdown)
[ ] Integration with GitHub Issues
[ ] Customizable status workflows

Development

# Clone repository
git clone https://github.com/ClaytonHunt/cascade.git
cd cascade

# Install dependencies
npm install

# Compile TypeScript
npm run compile

# Watch mode (auto-compile on changes)
npm run watch

# Package extension
npm run package

# Install locally for testing
code --install-extension cascade-0.3.1.vsix --force

License

This project is licensed under the GNU Affero General Public License v3.0 (AGPL-3.0) - see the LICENSE file for details.

This program is free software: you can redistribute it and/or modify it under the terms of the GNU Affero General Public License as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.

Why AGPL-3.0?

AGPL-3.0 ensures that if anyone modifies and deploys this extension (especially as a service), they must share their modifications. This promotes community collaboration while protecting against proprietary forks.

Support

Acknowledgments

Built with:

VSCode Extension API
js-yaml for YAML parsing
TypeScript for robust type safety

Release Notes

0.3.1 (Latest)

✨ Enhanced file watchers for real-time updates
🔍 Added support for markdown file and registry changes
🐛 Improved structure change detection
📝 Better logging for debugging

0.3.0

🎉 Initial public release
📊 Hierarchical work item tracking
🔄 Automatic state propagation engine
🌳 TreeView visualization
📁 Support for .cascade/ directory structure

Enjoy tracking your work items with Cascade! ⚡
