WebFrame Plus

[!NOTE] WebFrame Plus is under active development. Updates, improvements, and bug fixes are released regularly as the extension continues to evolve.

Marketplace Notice: Due to Microsoft VS Code Marketplace limitations regarding deleted identifier reclamation, this extension is published under the name WebFrame Plus on the official VS Code Marketplace, and as WebFrame Plus on the Open VSX Registry. Both packages are built from the exact same codebase and receive identical feature updates.

If you encounter an issue or have a suggestion, please open an issue or submit a pull request on GitHub. Your feedback and contributions are always appreciated.

The Pain Point

As a modern web developer building responsive or mobile-first web applications, testing layouts on mobile viewports is filled with friction:

1. Heavy Emulators: Launching official simulators (iOS Xcode Simulator or Android Studio Emulator) requires gigabytes of SDK downloads, consumes massive system memory, takes minutes to boot, and drains laptop batteries.
2. Context Switching: Browser Developer Tools are helpful, but require constant window toggling (Alt+Tab), separating your preview canvas from your editor.
3. Lack of Hardware Realism: Standard browser viewport resizers fail to replicate true hardware characteristics—like safe-area notch/Dynamic Island offsets, physical aspect ratios, system status bars, and home gesture indicators.
4. Proxy & Frame Blockers: Directly iframe-embedding local servers often fails due to strict CORS boundaries, Content Security Policies (CSP), missing history navigation, and cookies/sessions getting lost on every reload or panel toggle.

The Solution: WebFrame Plus

WebFrame Plus brings pixel-perfect, high-fidelity physical device previews directly inside your IDE workspace.

By utilizing a lightweight local HTTP reverse proxy and an elegant vector-frame system, WebFrame Plus lets you preview your live web application inside true-to-life hardware mockups (e.g. iPhone 16 Pro, Google Pixel 9, iPad) with zero emulator overhead, instant startups, and complete session persistence.

Key Features

• Fidelity Vector Mockups: Renders web applications inside detailed device frames containing accurate status bars, home indicators, camera punch holes, and curved display edges.
• Auto-Discovery of Local Servers: Scans active development ports (Vite, Next.js, Webpack, Nuxt, etc. on ports 3000, 3001, 5173, 8080, etc.) automatically and lists active local servers for one-click previews.
• Persistent Session Proxying: Proxies traffic through a sandboxed local server that intercepts and rewrites cookies, allowing login credentials and authentication states to persist across extension reloads.
• Frosted Assistive Controls: A dark-frosted floating control panel overlay inside the iframe that snaps to viewport edges, providing Back, Forward, and Page Reload actions while avoiding iframe history-trapping.
• Auto-Rotating layouts: Instantly rotate between Portrait and Landscape orientations. Bezels, status bar texts, and home gesture overlays rotate dynamically.
• Dynamic Workbench Scaling: Zoom mockups to 50%, 75%, 100%, or select Fit mode to scale the entire device layout fluidly with your editor panel width.
• SPA & HMR-Resilient: Integrated DOM observers automatically re-append preview UI elements even during aggressive Hot Module Replacements (HMR) or React/Next client-side hydration transitions.

Supported Devices

Installation

WebFrame Plus is fully compatible with VS Code, Antigravity, VSCodium, Eclipse Theia, and any other IDE supporting VS Code extensions.

1. Open your IDE's Extensions panel (Ctrl+Shift+X or Cmd+Shift+X).
2. Search for "WebFrame Plus".
3. Click Install.

How to Use

1. Launching the Preview

• Click the WebFrame Plus icon in your IDE's Activity Bar.
• The preview workbench launches automatically inside the side panel or editor view, scans for running development servers, and immediately renders the device viewport!
• If multiple local servers are running, choose your active port or input a public live URL from the toolbar's configuration settings.

2. Mockup Controls & Tool Bar

The top workbench control bar lets you customize your preview:

• Device Selector: Swap the physical hardware mockup instantly.
• Scale Menu: Zoom the device frame. Select Fit to make the device scale dynamically as you split or resize your editor pane.
• Refresh Trigger: Manually reload the active web frame.
• Dark/Light Mode: Toggle the status bar and browser canvas color scheme.
• Orientation Toggle: Rotate the phone between Portrait and Landscape layout.

3. Assistive Navigation Panel

Inside the preview mockup, you will see a subtle, floating cog icon at the middle-left of the screen:

• Repositioning: Click and drag the cog to move the panel vertically. Upon release, it automatically snaps to the closest horizontal screen edge (left or right) to avoid blocking content.
• Expanding: Click the cog to grow the pill vertically, revealing Go Back (←), Go Forward (→), and Reload (⟳) buttons.
• Frosted Glass Design: Dark semi-transparent frosted styling ensures high contrast and visibility on both dark and light web pages.

Under The Hood

To bypass iframe security sandboxes and keep your local dev environment running cleanly, WebFrame Plus implements a lightweight proxy architecture:

[ IDE Preview Tab ] <---> [ Local HTTP Reverse Proxy ] <---> [ Your Local Dev Server ]
        |                              |
 (Injected Script)            (Cookie & Header Rewriting)
        |                              |
 [ Navigation Controls ]         [ Auth Cookies Persisted ]

1. Reverse Proxying: The extension runs a sandboxed local proxy server. When it loads your local web application, it rewrites request and response headers (stripping strict CSP frame block headers and modifying set-cookie domains).
2. Session Persistence: Login cookies are stored and re-mapped dynamically, meaning you stay signed in even when swapping mockups or reloading the extension.
3. Script Injection: A custom runtime script is injected into the HTML document. This script sets up a communication bridge to listen to history nav triggers, and runs a MutationObserver on the body to keep the Assistive Touch panel alive during client-side hydration or HMR.

Development

Prerequisites

• Node.js (version 18 or above)
• VS Code (version 1.90.0 or above)

Setup & Compilation

1. Clone the repository.
2. Install project dependencies:

   npm install


3. Compile TypeScript sources:

   npm run compile


4. Press F5 to launch the Extension Development Host to test your changes.

Open Source & Contributing

Thank you for choosing WebFrame Plus!

This project is completely open source and community-driven. If you encounter any bugs, have feature requests, or want to contribute to the codebase:

• Report Issues: Submit a bug report or request features on the GitHub Issues page.
• Contribute: Pull Requests (PRs) are highly encouraged! Feel free to fork the repository and submit your improvements.

Your support and contributions help make WebFrame Plus better for everyone.

Check Out My Other Extensions

If you like WebFrame Plus, check out:

• Comment Cleaner Pro - A high-performance extension powered by a Python engine to instantly find, analyze, and remove comments from your code across 33+ programming languages.

License

This project is licensed under the GPL-3.0 License.
