JM Code Assistant

A Visual Studio Code extension to facilitate JaCaMo development, allowing users to create and run JaCaMo applications directly from the editor.

✨ Features

✅ Create a JaCaMo Application
→ Quickly generate a new JaCaMo project inside your workspace.

✅ Run a JaCaMo Application
→ Execute .jcm applications from VSCode with output displayed in an integrated panel.

✅ Stop MAS Execution
→ Instantly stop a running Multi-Agent System (MAS) from the sidebar.

✅ Web View Buttons
→ One-click access to Organization, Agent, and Environment dimension web viewers (localhost:3271-3273).

✅ Activity Bar Integration
→ Access commands via a dedicated JaCaMo Sidebar in VSCode.

✅ Syntax Highlighting
→ Supports .jcm, .asl, and .mas2j files for JaCaMo, Jason, and MAS2J syntax.

📌 Requirements

Before using this extension, ensure you have:

1. Command Line Interface (CLI) for JaCaMo – Install the appropriate version for your operating system:
   • Windows: Download and install from the JaCaMo for Windows
   • Linux: Execute the following commands in your terminal:

     echo "deb [trusted=yes] http://packages.chon.group/ chonos main" | sudo tee /etc/apt/sources.list.d/chonos.list
     sudo apt update
     sudo apt install jacamo-cli


2. Set the JaCaMo Path (Optional) – Only needed if jacamo is not in your PATH or you want to use a custom executable:
   • Open VSCode Settings (Ctrl + , or Cmd + ,).
   • Search for "JaCaMo Path".
   • Set it to the full path of jacamo.exe (e.g., C:\Users\YourUser\jacamo\jacamo.exe).
   • If left empty, the extension will use jacamo from your system PATH.

📂 Usage

1 - Create a JaCaMo Application

1. Click on the JaCaMo Sidebar icon in VSCode.
2. Click "Create JaCaMo App".
3. Enter the project name.
4. A new JaCaMo application with a standard project structure (src/agt, src/env, src/org) is created in your workspace.

2 - Run a JaCaMo Application

1. Click on the JaCaMo Sidebar icon.
2. Click "Run JaCaMo App".
3. If multiple .jcm files are found in your workspace, you will be prompted to select one.
4. The selected JaCaMo application runs, and the output appears in the JaCaMo Output panel.

3 - Stop MAS Execution

1. Click "Stop MAS Execution" in the sidebar to stop the currently running MAS.

4 - View MAOP Dimensions

1. Use the sidebar buttons to open the Organization, Agent, or Environment dimension web viewers in your browser.

🐞 Known Issues

• Ensure that the jacamo command is available in your PATH, or set the full path in VSCode settings if needed.
• If the extension doesn't execute, restart VSCode and try again.

📌 Release Notes

2.1.0

• Added buttons for Organization, Agent, and Environment dimension web viewers.
• Added Stop MAS Execution button.
• Improved JaCaMo path handling: now uses PATH by default, config is optional.
• Updated Linux install instructions.

1.0.1

• JaCaMo project creation
• Application execution
• Activity Bar integration
• Syntax highlighting for .jcm, .asl, and .mas2j

📚 Additional Resources

• JaCaMo Documentation
• JaCaMo Gold Miners Tutorial
• JaCaMo TDD Tutorial
• JaCaMo4Code Extension (For additional syntax support)

🌟 Enjoy coding with JaCaMo in VSCode! 🚀
