Azure IaC Guardrail

Review Azure Terraform security, compliance, architecture, and change impact before deployment.

Local static analysis, resolved plan assurance, architecture review, governed exceptions, and audit evidence inside Visual Studio Code.

Install · Quick start · Features · User guide · Contribute

Azure IaC Guardrail never runs terraform apply. Static scans are offline. Plan scans use your local Terraform executable and the authentication already configured for the selected workspace.

Public Preview: Guardrail is suitable for evaluation and guarded engineering review, not as the sole deployment approval control. The Cloud Canvas catalog contains 237 visual entries; 25 currently have executable controls, 48 have Terraform mappings, and only governance-approved services should be treated as supported generation targets.

From Terraform to Evidence

The workflow stays local and reviewable: open the Terraform root, choose the appropriate scan, inspect findings and remediation, then export evidence for the pull request or deployment approval.

Why Guardrail

Install

From a release VSIX

1. Download azure-iac-guardrail-<version>.vsix from the approved release.
2. In VS Code, open Extensions and select Views and More Actions (...) > Install from VSIX....
3. Select the downloaded package and reload VS Code when prompted.

The same installation can be performed from a terminal:

code --install-extension .\azure-iac-guardrail-<version>.vsix

For a managed rollout, distribute the approved VSIX through your software management platform or private extension gallery. Marketplace installation instructions will be added when the public publisher is configured.

Requirements

• Visual Studio Code 1.100.0 or later.
• Terraform only for plan-based workflows.
• Azure/provider authentication only when the selected Terraform workflow requires it.

See Installation and Quick Start for upgrades, uninstalling, and troubleshooting.

Quick Start

1. Open the folder containing your Terraform root module.
2. Press Ctrl+Shift+P.
3. Run Azure IaC Guardrail: Azure Pre-configuration and select the Terraform root, approved regions, required tags, and any governed exceptions.
4. Run Azure IaC Guardrail: Scan Terraform Files for immediate offline feedback.
5. Run Azure IaC Guardrail: Create and Scan Local Terraform Plan when you need resolved values, module instances, relationships, and change impact.
6. Review findings in Azure IaC Guardrail Results, apply only reviewed fixes, and export the required evidence.

For the complete operating guide, see USER_GUIDE.md.

Static feedback starts in the editor. A Terraform plan adds authoritative resolved values and relationships. Reviewers then use the same findings, architecture context, and exported evidence before approving deployment.

Product View

_{Illustrative product view. The extension evaluates Terraform; resource names and findings shown here are representative sample data.}

Features

Resource Cost and Cloud Canvas are Preview features. Their output requires human review and is not an Azure bill or deployment approval.

Scan Modes

Generated local plans are temporary by default. Terraform state, plans, tfvars, backend configuration, credentials, subscription IDs, and tenant IDs must not be committed.

Controls and Standards

Built-in service and control definitions live in:

catalog/services/<service-id>.json

Each service file owns its Cloud Canvas metadata, Terraform mapping, parameters, controls, assurances, remediation, and references. The generated azure-complete-catalog-vscode.json is consumed by scanning and Cloud Canvas; do not edit it directly.

To add or change a standard control:

1. Copy catalog/service-template.json.example when adding a service, or open the existing service file.

2. Define a unique control ID, exact Terraform resource type and attribute, supported operator, expected value, severity, remediation, and authoritative reference.

3. Add tests for compliant, non-compliant, and unresolved behavior. Add plan and related-resource cases when the control requires them.

4. Run:

   npm run catalog:validate
   npm run catalog:test
   npm run check
   npm run lint
   npm test
   npm run compile


5. Commit the service file and regenerated azure-complete-catalog-vscode.json.

Read CONTRIBUTING.md and the Control and Standard Contribution Guide before opening a pull request.

Develop

npm install
npm run check
npm run lint
npm test
npm run compile

Press F5 to launch an Extension Development Host. Maintained Terraform examples are under test/fixtures/, including storage-spa, three-tier-webapp, remote-module-static-scan, and intellisense-ux-demo.

Release

Pull requests and pushes to main run identifier checks, type checking, linting, unit tests, compilation, and VSIX packaging. A semantic version tag (vX.Y.Z) builds a checksummed release candidate and publishes it through the protected Marketplace environment.

Release prerequisites and rollback guidance are documented in Release Management and docs/RELEASING.md.

Security and Support

• Report vulnerabilities privately through GitHub Security Advisories.
• Use GitHub Issues for defects and feature requests without sensitive data.
• Review SECURITY.md and Security and Privacy before sharing logs or evidence.

License

Released under the MIT License.
