Calkit for VS Code

Turn a research or analytical project into a navigable, reproducible system.

Most projects where the output artifacts (figures, datasets, results, papers, presentations) are what matter accumulate a tangle of scripts, notebooks, environments, and data. Calkit gives that tangle a structure: every artifact is traceable to the pipeline stage that produced it, every stage to its code and environment. This extension is the integration layer on top—it surfaces the whole system in one place, lets you traverse between layers (artifact → stage → environment → source), and lets you make changes at any layer and re-run to keep everything in sync.

The Calkit activity-bar view presents the project as connected sections:

Questions: The research questions the project sets out to answer.
Environments: Every computational environment (uv, Pixi, venv, conda, renv, Docker, Julia, MATLAB, SSH, SLURM/PBS, and nested combinations).
Pipeline: The stages that produce the project's artifacts, each showing live status (up to date, stale, or running).
Notebooks: Jupyter notebooks and the environments/stages they belong to.
Figures, Datasets, Results, Publications, and Presentations: The output artifacts, each annotated with the stage (or import source) it came from.

Items are cross-linked, so you can traverse the system in any direction: expand a figure to jump to the stage that made it, jump from a stage to its environment, open the stage's script/notebook, or open an output file—then run the stage again. A badge and per-section warnings flag anything that needs attention (stale outputs, artifacts with no defined source, notebooks with no environment).

Use the toolbar to filter the tree across all sections, refresh status, hide/show sections, open calkit.yaml, or initialize a new Calkit project in a plain folder.

Provenance & traceability

Show Source: From an open figure, PDF, dataset, or other pipeline output, jump straight to the producing stage in the sidebar (and into its source).
Figure source links: In Quarto (.qmd) and LaTeX (.tex) documents, a "Source: <stage>" CodeLens appears above each ![](https://github.com/calkit/calkit/raw/HEAD/…) / \includegraphics{…} that references a pipeline output; right-click also offers Go to Figure Source. (From a compiled PDF, LaTeX Workshop's reverse-SyncTeX takes you to the \includegraphics line, where these actions take over.)
Stale-output awareness: Outputs whose stage needs re-running are flagged in the sidebar and in the file explorer.
File history: View a tracked file's history from the sidebar or explorer.
Scheduler logs: Stages that run under SLURM/PBS surface their log file in the tree so you can open it with a click.

Pipeline

Run the whole pipeline, an individual stage, or the stage for the file you're editing.
Define new stages graphically, including turning a notebook, script, or an existing artifact into a reproducible stage; edit existing stages.
Visualize the pipeline DAG.
Open the rendered PDF of a LaTeX/Quarto stage from its source.

Environments

Create and edit environments graphically (package lists, spec files, base images, etc.) for uv, Pixi, venv, conda, renv, Docker, Julia, MATLAB, SSH, and SLURM/PBS.
Select a notebook's environment and let the extension register/select the matching Jupyter kernel—or edit that environment right from the notebook toolbar.
Use nested environments like slurm:main for notebook jobs that need to, e.g., to reserve GPUs on a cluster.
Start, stop, and restart notebook server sessions for SLURM- and Docker-backed workflows from the notebook toolbar.

Figures & artifacts

Browse figures in a gallery and carousel, including interactive Plotly figures (.json), with per-figure provenance and a one-click jump to the producing stage.
Preview Plotly JSON files in a dedicated Plotly Preview editor.
Open a notebook's executed HTML output.

Getting started

Open a project folder. If it isn't a Calkit project yet, the sidebar offers Initialize Calkit Project.
Explore the Calkit sidebar to see environments, the pipeline, and artifacts.
From a notebook, run Calkit: Select Notebook Environment, pick or create an environment (providing SLURM options like --gpus/--time if needed), and the extension registers/selects the kernel and connects the session.

Requirements

VS Code with the Jupyter extension installed.
The Calkit CLI available on your PATH. If it's missing or too old, the extension prompts with install/upgrade options.

How environments are stored in `calkit.yaml`

Selecting an environment for a notebook writes it to calkit.yaml, updating either notebooks or pipeline.stages depending on whether the notebook is part of a pipeline stage.

# Standalone notebook
notebooks:
  - path: my-notebook.ipynb
    environment: my-env

# Notebook that is a pipeline stage
pipeline:
  stages:
    my-notebook:
      kind: jupyter-notebook
      notebook_path: my-notebook.ipynb
      environment: my-env

Settings

calkit.autoRefreshStatus: Automatically run calkit status to refresh pipeline staleness when project files change (disable if frequent status checks interfere with Git operations; you can still refresh manually).
calkit.notebook.defaultJupyterPort: Default port for Calkit-backed Jupyter servers.
calkit.sidebar.hiddenSections: Sidebar sections to hide (managed via the sidebar's Manage Sections action).

Commands

Most actions are available from the sidebar, notebook toolbar, and editor context menus. Highlights, all under the Calkit category in the command palette:

Project: Initialize Calkit Project, Open calkit.yaml, Save, Refresh, Filter / Clear Filter, Manage Sections
Pipeline: Run Pipeline, Run Stage, New Stage, Edit Stage, Show Pipeline DAG, Open Rendered PDF, Show Source, Go to Figure Source
Environments: Create Environment, Edit Environment, Select Notebook Environment, Edit Notebook Environment
Notebook sessions: Start Jupyter SLURM Job, Stop Jupyter SLURM Job, Restart Notebook Server, Open Executed HTML
Figures: Browse Figures, Open Plotly Preview
Artifacts: Define Pipeline Stage, Define Import, View File History
