OpenClaw Client for VS Code

AI chat sidebar for the OpenClaw gateway and VS Code node. The extension connects to an OpenClaw gateway over WebSocket, providing real-time AI chat, multi-agent and session management, workspace context, media display, Mermaid diagram rendering, and local tool execution from inside VS Code.

Features

• Log Level Control: Dynamically switch log output levels (None/Error/Warn/Info/Debug/Trace) via the command palette or settings. Logs are persisted across sessions and take effect immediately.

• Agent HUD: View connection status, model settings, server information, reliability settings, and sessions.

• Reconnect: Use the HUD button or the OpenClaw: Reconnect command when the gateway connection is lost.

• Multi-agent chat: Switch between agents. Each agent has its own chat tab and session pool.

• Session management: Create, switch, and delete sessions independently for each agent, with token usage shown in the HUD.

• Supervisor mode: Periodically inspect the current agent output with a configurable supervisor, reminder, inquiry method, and stop signal.

• Streaming responses: Render assistant Markdown as responses arrive, with a busy indicator for processing and queued messages.

• Media display: Display images and videos embedded in gateway replies as base64 data URLs.

• Mermaid diagrams: Render fenced Mermaid blocks as SVG, switch between Image and Source views, copy source or PNG, and export PNG files.

• Workspace context: Search workspace files with @, browse directories, and attach single-line or line-range references.

• Attachments: Add files by picker, paste, or drag and drop. Each file is limited to 10 MB. Files are labeled with a type tag such as [IMG], [VID], [AUD], [TXT], [PDF], [ZIP], or [FILE].

• Paired node tools: Expose exec, read, write, and edit to the agent through the paired VS Code node.

• Command approval: Approve local commands once, always for a working directory, or deny them.

• Device identity: Authenticate with an Ed25519 device identity compatible with OpenClaw pairing.

• Subagent activity: Show active subagent labels and waiting-for-subagent status in chat.

• Progress note panel: View and manage subagent progress notes in a resizable side panel with copy-as-Markdown support. Steps are rendered as readable text with status indicators.

• Internationalization: Localize extension UI strings through the VS Code localization system.

Installation

VS Code Marketplace

Search for nufeng1999 in the VS Code Extensions view, or open the Marketplace page.

From source

git clone https://github.com/nufeng/openclaw-vscode.git
cd openclaw-vscode
npm install
npm run build

Install the resulting extension folder in ~/.vscode/extensions/.

Usage

1. Start the OpenClaw gateway.
2. Open OpenClaw from the VS Code Activity Bar.
3. The extension connects to the gateway as an operator and node.
4. Select Chat in the tab bar and send a message.
5. Use the HUD agent buttons to switch agents, or use New Chat to start a session.

HUD and chat

Use the grid button in the tab bar to toggle the HUD. It contains the current agent card, connection state, reconnect control, agent switcher, settings, and sessions. In the chat panel, press Enter to send and Shift+Enter for a newline. Use Stop to abort a running response.

The attachment button opens a file picker. Files can also be pasted with Ctrl+V or dropped onto the input area. Attachments show a type label, name, and size; remove a file with its x control. Files over 10 MB are skipped. While a response is streaming, the attachment button is hidden until processing completes.

Slash commands

Type / to open the command menu. It contains /stop and /new under SESSION, /models and /status under MODEL & STATUS, and /help, /reset, and /compact under HELP. Use the arrow keys to navigate, Enter to select, and Escape to close the menu.

Workspace context

Type @ in the input to search workspace files and folders. Use @folder/ to browse a directory. A selected file is inserted as @path. Add #L123 for one line or #L100-#L200 for a line range; the reference is sent as structured context to the gateway.

Supervisor mode

Enable supervision with the checkbox in the HUD. The supervisor checks the current agent at the configured interval. If output is unchanged, the optional reminder is sent, then the supervisor is asked whether work should stop. Supervision stops when configured output content or the supervisor reply matches its stop signal, or when supervision is disabled.

Progress note panel

A resizable side panel displays subagent progress notes (also called "进度备注") in real time. The panel header shows the current note title and provides two toolbar buttons: 📋 Copy all content copies the full note text to the clipboard, and 📝 Copy as Markdown copies the note formatted as Markdown. The panel can be toggled open/closed with the 进度备注 button and resized by dragging its handle.

Workspace commands

Right-click a folder in Explorer and select Switch working directory to this folder to make it the working directory, or select Analyze this project to ask the agent to analyze the folder's code structure, file organization, and technology stack.

Commands

Configuration

Open VS Code Settings and search for openclaw.

General settings

Supervisor settings

Example:

{
  "openclaw.gatewayUrl": "ws://127.0.0.1:18789",
  "openclaw.agentId": "main",
  "openclaw.supervisor.agentId": "manager",
  "openclaw.supervisor.intervalMinutes": 5,
  "openclaw.supervisor.reminderMessage": "Please continue your work.",
  "openclaw.supervisor.stopSignalContent": "done|finished|completed",
  "openclaw.supervisor.stopInquiryMethod": "Judge",
  "openclaw.supervisor.stopSignalReply": "yes"
}

How It Works

The extension uses the gateway as both an operator client and a paired node. The operator connection powers chat, agents, sessions, and model state. The node connection authorizes local tools such as exec, read, write, and edit.

On the first connection, the extension creates an Ed25519 device identity and stores it in VS Code global storage as nodeDeviceIdentityV2. The public identity is used to sign the gateway challenge. If pairing is required, approve the latest device with openclaw devices approve --latest or use OpenClaw: Approve Node Pairing. OpenClaw: Reset Device Identity clears the stored identity so the device can pair again.

After a successful connection, the extension loads agents, sessions, and model defaults. Chat messages use the chat.send RPC; streamed chat events update the UI from delta to final state. Agent-run failures are retried by sending Continue, up to three times. Disconnections trigger automatic reconnect with exponential backoff, and the HUD also provides manual reconnect.

Troubleshooting

Gateway connection fails

• Confirm that the gateway is running and that openclaw.gatewayUrl is the correct WebSocket URL.
• Check the OpenClaw channel in the VS Code Output panel.
• Check firewall and network access to the gateway port.
• Use OpenClaw: Reconnect or the HUD reconnect button after correcting the configuration.

Node pairing fails

• Run openclaw devices approve --latest on the gateway host.
• Use OpenClaw: Approve Node Pairing and inspect pairing messages in the Output panel.
• Use OpenClaw: Reset Device Identity, then reconnect and approve the new device.

Mermaid diagrams do not render

• Ensure the response contains a fenced block beginning with ```mermaid.
• Wait for streaming to finish; diagrams render when the response completes.
• Check the Output panel for rendering errors, and use Source view to inspect the generated Mermaid text.

Attachments fail

• Confirm that every file is below the 10 MB per-file limit.
• Check the file picker, paste, or drop operation and inspect the Output panel.
• Confirm that the gateway accepts the attachment payload and that the connection remains active.

Supervisor does not respond

• Confirm that openclaw.supervisor.intervalMinutes is greater than 0 and that the supervisor agent exists.
• Check the supervisor agent ID, stop inquiry method, and stop signal reply.
• Configure reminderMessage if unchanged output should trigger a reminder.
• Review supervisor entries in the OpenClaw Output channel.

Agent retries are exhausted

When an agent-run failure is reported, the extension sends Continue up to three times. If all retries fail, the error is displayed in chat. Inspect the gateway and OpenClaw Output logs for the original failure.

Development

npm install
npm run build
npm run watch

npm run build runs the repository's esbuild entry point once. npm run watch rebuilds when source files change. Reload the VS Code window or extension after rebuilding to test the result.

For diagnostics, inspect the OpenClaw output channel. Connection and protocol code is in src/gateway.ts; chat and webview behavior is in src/chatView.ts; extension commands and activation are in src/extension.ts.

License

MIT
